porsche 1981 (924) air cleaner system parts diagram

106-000 - air cleaner system

Porsche 1981 (924) AIR CLEANER SYSTEM Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                              #
                                              Part number
                                              Description
                                              Key
                                              Price
                                              # -
                                              MPN: N 0201391
                                              TUBE IN COILS OF 5M - 'ORDER QTY. 5' - 4 X 1
                                              Supersession
                                              Supersession
                                              Genuine Porsche Part (no longer available to order)
                                              # 1
                                              -
                                              SHORTEN TO:
                                              700 MM
                                              # -
                                              -
                                              HOSE - 3,5 X 2 - DISCONTINUED PART
                                              # 2
                                              MPN: PCG0203535
                                              HOSE - 3,5 X 2 X 5000
                                              from £21.58
                                              from £21.58
                                              HOSE - 3,5 X 2 X 5000 Genuine Porsche Part - New (to order)
                                              # 3
                                              MPN: 047129545B
                                              BRACKET
                                              BRACKET Genuine Porsche Part - New (to order)
                                              # 4
                                              MPN: 99970323900
                                              BONDED RUBBER BUFFER
                                              Supersession
                                              Supersession
                                              Genuine Porsche Part (no longer available to order)
                                              # 5
                                              MPN: N 0122265
                                              SPRING WASHER - B 6
                                              from £0.70
                                              from £0.70
                                              spring washer - M6X16 Genuine Porsche Part - New In stock
                                              # 6
                                              MPN: 90007601002
                                              NUT - M 6 - DISCONTINUED PART
                                              nut - M6 - Discontinued part Genuine Porsche Part - New (to order)
                                              # 6
                                              MPN: 9000760100B
                                              NUT - M 6
                                              from £0.73
                                              from £0.73
                                              NUT - M6 Genuine Porsche Part - New In stock
                                              # 7
                                              MPN: N 0115247
                                              WASHER - A 6,4 - DISCONTINUED PART
                                              Washer - R 6,6 - Discontinued part Genuine Porsche Part - New (to order)
                                              # 7
                                              MPN: N 01152427
                                              Washer - A 6,4
                                              from £0.47
                                              from £0.47
                                              Washer - R 6,6 Genuine Porsche Part - New (to order)
                                              WASHER 6.4X12.5X1.6 Genuine Lamborghini - New In stock
                                              # 8
                                              MPN: N 01021513
                                              SCREW, HEX. HD. - M 6 X 15
                                              from £2.09
                                              from £2.09
                                              screw, hex. hd. - M6 X 15 Genuine Porsche Part - New (to order)
                                              # 9
                                              MPN: 047129547B
                                              BRACKET
                                              BRACKET Genuine Porsche Part - New (to order)
                                              # 10
                                              MPN: 477129611D
                                              AIR CLEANER - READY FOR INSTALLATION
                                              AIR CLEANER - READY FOR INSTALLATION Genuine Porsche Part - New (to order)
                                              # 10
                                              MPN: 477129615D
                                              AIR CLEANER COVER - WITHOUT: - RETAINING CLIP
                                              from £60.90
                                              from £60.90
                                              AIR CLEANER COVER - WITHOUT: - RETAINING CLIP Genuine Porsche Part - New (to order)
                                              # 10
                                              MPN: 055129635
                                              RETAINING CLIP - DISCONTINUED PART
                                              from £3.61
                                              from £3.61
                                              RETAINING CLIP - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                              # 10
                                              MPN: 055129635
                                              Retaining Clip
                                              from £3.61
                                              from £3.61
                                              RETAINING CLIP - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                              # 11
                                              MPN: 021129620
                                              AIR FILTER - REPAIR SET FOR MAINTENANCE - SEE ILLUSTRATION:
                                              --198-000
                                              from £11.27
                                              from £11.27
                                              AIR FILTER - REPAIR SET FOR MAINTENANCE - SEE ILLUSTRATION: Genuine Porsche Part - New (to order)
                                              # 12
                                              MPN: 047133083C
                                              INTAKE MANIFOLD
                                              from £63.00
                                              from £63.00
                                              INTAKE MANIFOLD Genuine Porsche Part - New (to order)
                                              # 12
                                              MPN: 047133083E
                                              Intake manifold - D - MJ 1982>>
                                              from £94.50
                                              from £94.50
                                              Intake manifold - D - MJ 1982>> Genuine Porsche Part - New (to order)
                                              # 12
                                              MPN: 047133083F
                                              INTAKE MANIFOLD
                                              (\\S..\\)
                                              from £94.50
                                              from £94.50
                                              INTAKE MANIFOLD Genuine Porsche Part - New (to order)
                                              # 12
                                              MPN: 047133083D
                                              Intake manifold - D - MJ 1982>>
                                              (\\S..\\,\\CH.\\)
                                              from £94.50
                                              from £94.50
                                              Intake manifold - D - MJ 1982>> Genuine Porsche Part - New (to order)
                                              # 12
                                              MPN: 047133083E
                                              Intake manifold - D - MJ 1982>>
                                              AUT. (\\S..\\)
                                              from £94.50
                                              from £94.50
                                              Intake manifold - D - MJ 1982>> Genuine Porsche Part - New (to order)
                                              # 12
                                              MPN: 047133083D
                                              INTAKE MANIFOLD
                                              (\\USA\\,\\CDN\\, \\J..\\,\\AUS\\)
                                              from £94.50
                                              from £94.50
                                              Intake manifold - D - MJ 1982>> Genuine Porsche Part - New (to order)
                                              # 13
                                              MPN: 99951235002
                                              HOSE CLAMP - 80 - 100
                                              from £5.17
                                              from £5.17
                                              Hose Clamp - SGL 80-100-9 - D - MJ 1985>> Genuine Porsche Part - New In stock
                                              # 14
                                              MPN: 047133367E
                                              HOSE
                                              from £74.05
                                              from £74.05
                                              Hose - also use: Genuine Porsche Part - New (to order)
                                              # 15
                                              MPN: N 0245211
                                              HOSE CLAMP - A 12 X 126
                                              HOSE CLAMP - A 12 X 126 Genuine Porsche Part - New (to order)
                                              # 16
                                              MPN: 90007501402
                                              SCREW, HEX. HD. - M 6 X 18 - DISCONTINUED PART
                                              screw, hex. hd. - M6 X 18 - Discontinued part Genuine Porsche Part - New (to order)
                                              # 16
                                              MPN: 90007501403
                                              SCREW, HEX. HD. - M 6 X 18
                                              from £2.04
                                              from £2.04
                                              screw, hex. hd. - M6 X 18 Genuine Porsche Part - New (to order)
                                              # 17
                                              MPN: 90015102902
                                              WASHER - B 6,4
                                              Washer - D >> - MJ 1978 Genuine Porsche Part - New (to order)
                                              # 18
                                              MPN: 047133367C
                                              HOSE
                                              from £44.31
                                              from £44.31
                                              HOSE Genuine Porsche Part - New (to order)
                                              # 18
                                              MPN: 047133367B
                                              HOSE
                                              (\\S..\\)
                                              HOSE Genuine Porsche Part - New (to order)
                                              # -
                                              -
                                              SCREWED SOCKET
                                              (\\S..\\)
                                              # -
                                              -
                                              Washer - 15
                                              (\\S..\\)
                                              # -
                                              -
                                              HEX. NUT - M 14 X 1,5 - DISCONTINUED PART
                                              (\\S..\\)
                                              # -
                                              -
                                              HEX. NUT - M 14 X 1,5
                                              (\\S..\\)
                                              # -
                                              -
                                              Hose in coils of 5M - 'Order qty. 5' - 18 X 2,5 MM
                                              # 19
                                              MPN: 93011025601
                                              CAP
                                              from £13.32
                                              from £13.32
                                              cap - D >> - MJ 1982 Genuine Porsche Part - New (to order)
                                              # 20
                                              MPN: 99951234600
                                              HOSE CLAMP - 16 - 25
                                              from £3.29
                                              from £3.29
                                              Hose Clamp - SGT 16-25 - Interior sensor Genuine Porsche Part - New (to order)
                                              # 21
                                              MPN: 049133379A
                                              GASKET
                                              from £11.60
                                              from £11.60
                                              GASKET Genuine Porsche Part - New (to order)
                                              # 22
                                              MPN: 90006700902
                                              SCREW, CHEESE HD. - M 6 X 15 - DISCONTINUED PART
                                              screw, cheese hd. - M6 X 15 - Discontinued part Genuine Porsche Part - New (to order)
                                              # 22
                                              MPN: 90006742901
                                              SCREW, CHEESE HD. - M 6 X 15
                                              from £3.54
                                              from £3.54
                                              screw, cheese hd. - M6 X 15 - Chrome plated Genuine Porsche Part - New (to order)
                                              # 23
                                              MPN: 477133523
                                              RETAINING SPRING
                                              RETAINING SPRING Genuine Porsche Part - New (to order)
                                              # 24
                                              MPN: 047133091
                                              SPACER BUSHING
                                              SPACER BUSHING Genuine Porsche Part - New (to order)
                                              # 25
                                              MPN: 047103221
                                              VENT HOSE
                                              VENT HOSE Genuine Porsche Part - New (to order)
                                              # 26
                                              MPN: 99951225202
                                              HOSE CLAMP - 23 - 35
                                              Supersession
                                              Supersession
                                              Genuine Porsche Part (no longer available to order)
