porsche 1987 (924s) steering gear - steering track rod parts diagram

403-000 - STEERING GEAR - STEERING TRACK ROD

Porsche 1987 (924S) STEERING GEAR - STEERING TRACK ROD Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 1
                          MPN: 94434701100
                          STEERING GEAR - ALSO USE:
                          lhd-94434713700-94434713900-94434722301-90002500703-N 01036019
                          STEERING GEAR - ALSO USE: Genuine Porsche Part - New (to order)
                          # 1
                          MPN: 94534701100
                          STEERING GEAR - ALSO USE:
                          rhd-94434713700-94434713900-94534722300-90002500703-90007413402
                          from £745.61
                          from £745.61
                          STEERING GEAR - ALSO USE: Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 477419321
                          PROTECTIVE CAP
                          from £6.05
                          from £6.05
                          PROTECTIVE CAP Genuine Porsche Part - New (to order)
                          # 3
                          MPN: 477419115
                          SEALING CAP
                          from £17.66
                          from £17.66
                          SEALING CAP Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 171419831C
                          BOOT FOR STEERING GEAR ASSY. - DISCONTINUED PART
                          LEFT
                          BOOT FOR STEERING GEAR ASSEMBLY - DISCONTINUED PART Genuine Porsche Part - New (to order)
                          # 4
                          MPN: PCG419831C
                          BELLOWS
                          LEFT
                          from £6.38
                          from £6.38
                          BELLOWS Genuine Porsche Part - New In stock
                          # 5
                          MPN: 171419832C
                          BOOT FOR STEERING GEAR ASSY.
                          RIGHT
                          from £29.25
                          from £29.25
                          BOOT FOR STEERING GEAR ASSEMBLY Genuine Porsche Part - New (to order)
                          # 6
                          MPN: 823419843
                          CLIP FOR PROTECTIVE SLEEVE - $ 45 MM
                          from £3.22
                          from £3.22
                          clip for protective sleeve - 45 Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 94434722301
                          CLAMP
                          LHD
                          from £12.42
                          from £12.42
                          CLAMP Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 94534722300
                          CLAMP
                          RHD
                          from £16.27
                          from £16.27
                          CLAMP Genuine Porsche Part - New (to order)
                          # 8
                          MPN: 94434713700
                          RUBBER INSERT
                          LEFT
                          from £13.69
                          from £13.69
                          RUBBER INSERT Genuine Porsche Part - New (to order)
                          # 8
                          MPN: 94434713900
                          RUBBER INSERT
                          RIGHT
                          from £10.67
                          from £10.67
                          RUBBER INSERT Genuine Porsche Part - New (to order)
                          # 9
                          MPN: 90002500702
                          WASHER - A 8,4 - DISCONTINUED PART
                          Washer - M 8,4 - Discontinued part Genuine Porsche Part - New (to order)
                          # 9
                          MPN: 90002500703
                          Washer - A 8,4
                          from £0.84
                          from £0.84
                          Washer - M 8,4 Genuine Porsche Part - New In stock
                          # 10
                          MPN: N 0103606
                          SCREW, HEX. HD. - M 8 X 60 - DISCONTINUED PART
                          LHD
                          SCREW, HEX. HD. - M8 X 60 - D - MJ 1972>>- DISCONTINUED PART Genuine Porsche Part - New (to order)
                          # 10
                          MPN: N 01036019
                          SCREW, HEX. HD. - M 8 X 60
                          LHD
                          from £1.32
                          from £1.32
                          screw, hex. hd. - M8 X 60 - D - MJ 1972>> Genuine Porsche Part - New (to order)
                          # 10
                          MPN: 90007413402
                          SCREW, HEX. HD. - M 8 X 45
                          RHD
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 11
                          MPN: 94434703301
                          STEERING TRACK ROD - DISCONTINUED PART
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 11
                          MPN: 94434703307
                          STEERING TRACK ROD
                          from £85.99
                          from £85.99
                          This part replaces part number 94434703301
                          STEERING TRACK ROD - SEE TECHNICAL INFORMATION - NR. 22 - F 92-DN402 094>>- F 93-DN100 186>> Genuine Porsche Part - New (to order)
                          # 12
                          MPN: 477419827
                          STOP RING
                          from £37.09
                          from £37.09
                          STOP RING Genuine Porsche Part - New (to order)
                          # 13
                          MPN: 171419855
                          LOCK NUT - M 22 X 1,5
                          from £6.05
                          from £6.05
                          LOCK NUT - M 22 X 1,5 Genuine Porsche Part - New (to order)
                          # 15
                          MPN: N 0111633
                          HEX. NUT - DISCONTINUED PART
                          HEX. NUT - M 14 X 1,5 - DISCONTINUED PART Genuine Porsche Part - New (to order)
                          # 15
                          MPN: 90007800503
                          HEX. NUT
                          from £4.17
                          from £4.17
                          HEX. NUT - M 14 X 1,5 Genuine Porsche Part - New (to order)
                          # 16
                          MPN: N 0112122
                          nut, slotted
                          from £2.89
                          from £2.89
                          nut, slotted - M X 12 X 1,5 Genuine Porsche Part - New (to order)
                          # 16
                          MPN: 9003600020B
                          LOCK NUT
                          VM12X1,5
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 17
                          MPN: N 0125321
                          COTTER PIN - 3 X 25
                          from £0.69
                          from £0.69
                          cotter pin - D >> - MJ 1986 Genuine Porsche Part - New (to order)
                          # 18
                          MPN: 94434702701
                          DRIVE SHAFT
                          LHD
                          from £414.92
                          from £414.92
                          STEERING COLUMN DRIVE SHAFT LHD Genuine Porsche Part - New (to order)
                          # 18
                          MPN: 94534702700
                          DRIVE SHAFT
                          RHD
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 19
                          MPN: N 0103357
                          SCREW, HEX. HD. - M 8 X 35
                          from £1.02
                          from £1.02
                          SCREW, HEX. HD. - M 8 X 35 Genuine Porsche Part - New (to order)
                          # 20
                          MPN: 90091002209
                          LOCK NUT
                          lock nut - VM 8 Genuine Porsche Part - New (to order)
                          # 20
                          MPN: 90091002203
                          LOCK NUT
                          from £0.85
                          from £0.85
                          lock nut - VM 8 Genuine Porsche Part - New In stock
