porsche 1980 (928) installation parts - door parts diagram

804-005 - INSTALLATION PARTS - DOOR

Porsche 1980 (928) INSTALLATION PARTS - DOOR Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                                          #
                                                                                          Part number
                                                                                          Description
                                                                                          Price
                                                                                          # -
                                                                                          -
                                                                                          DIFFERING PARTS - FOR - ALARM SYSTEM - SEE GROUP - 8/04/20
                                                                                          # 1
                                                                                          MPN: 91153170300
                                                                                          CAP
                                                                                          from £4.57
                                                                                          from £4.57
                                                                                          # 2
                                                                                          MPN: 92853758502
                                                                                          COVER
                                                                                          # 5
                                                                                          MPN: 90015102703
                                                                                          WASHER - B 5,3
                                                                                          from £0.65
                                                                                          from £0.65
                                                                                          # 6
                                                                                          MPN: 92853709502
                                                                                          rotary knob - for - rotary knob - Driver's door
                                                                                          from £53.28
                                                                                          from £53.28
                                                                                          # 6
                                                                                          MPN: 92853709602
                                                                                          MOUNTING
                                                                                          from £64.74
                                                                                          from £64.74
                                                                                          # 7
                                                                                          MPN: 99353156300
                                                                                          LINKAGE CLIP
                                                                                          from £0.73
                                                                                          from £0.73
                                                                                          This part replaces part number 99353156301
                                                                                          # 8
                                                                                          MPN: 90014305802
                                                                                          TAPPING SCREW - BZ 4,5 X 9,5
                                                                                          from £0.65
                                                                                          from £0.65
                                                                                          # 9
                                                                                          MPN: 92853703304
                                                                                          DOOR SUPPORT
                                                                                          from £64.31
                                                                                          from £64.31
                                                                                          # 10
                                                                                          MPN: N 0115247
                                                                                          WASHER - 6,4 - DISCONTINUED PART
                                                                                          # 10
                                                                                          MPN: N 01152427
                                                                                          WASHER - 6,4
                                                                                          from £0.47
                                                                                          from £0.47
                                                                                          # 11
                                                                                          MPN: 92853745102
                                                                                          SCREW, CHEESE HD.
                                                                                          # 12
                                                                                          MPN: 92853737102
                                                                                          PACKING - FOR - DOOR SUPPORT
                                                                                          from £3.69
                                                                                          from £3.69
                                                                                          # 13
                                                                                          MPN: 90030903102
                                                                                          pin - 6 X 16 - D >> - MJ 1979
                                                                                          from £0.88
                                                                                          from £0.88
                                                                                          # 13
                                                                                          MPN: 92853741903
                                                                                          SCREW, CHEESE HD.
                                                                                          from £5.08
                                                                                          from £5.08
                                                                                          # 14
                                                                                          MPN: 92853741702
                                                                                          bracket - Discontinued part
                                                                                          LEFT
                                                                                          # 14
                                                                                          MPN: 92853741703
                                                                                          BRACKET
                                                                                          LEFT
                                                                                          from £12.97
                                                                                          from £12.97
                                                                                          # 14
                                                                                          MPN: 92853741802
                                                                                          BRACKET
                                                                                          RIGHT
                                                                                          from £9.62
                                                                                          from £9.62
                                                                                          # 15
                                                                                          MPN: 92853742502
                                                                                          PACKING
                                                                                          LEFT
                                                                                          from £6.95
                                                                                          from £6.95
                                                                                          # 15
                                                                                          MPN: 92853742602
                                                                                          PACKING
                                                                                          RIGHT
                                                                                          from £14.02
                                                                                          from £14.02
                                                                                          # 16
                                                                                          MPN: 92853745902
                                                                                          fillister hd. screw - M 6 X 25 - Discontinued part
                                                                                          # 16
                                                                                          MPN: 92853745903
                                                                                          fillister hd. screw - M 6 X 25
                                                                                          from £2.55
                                                                                          from £2.55
                                                                                          # 17
                                                                                          MPN: 92853790703
                                                                                          LOCK - INNER PART
                                                                                          LEFT
                                                                                          from £165.56
                                                                                          from £165.56
                                                                                          # 17
                                                                                          MPN: 92753790803
                                                                                          LOCK - INNER PART
                                                                                          RIGHT
                                                                                          from £165.56
                                                                                          from £165.56
                                                                                          # 18
                                                                                          MPN: 92853772102
                                                                                          FILLISTER HD. SCREW
                                                                                          Supersession
                                                                                          Supersession
                                                                                          # 19
                                                                                          MPN: 92853715303
                                                                                          DOOR LATCH - OUTER PART
                                                                                          LEFT
                                                                                          from £53.87
                                                                                          from £53.87
                                                                                          # 19
                                                                                          MPN: 92853715403
                                                                                          DOOR LATCH - OUTER PART
                                                                                          RIGHT
                                                                                          from £53.87
                                                                                          from £53.87
                                                                                          # 20
                                                                                          MPN: 92853703802
                                                                                          striker - D >> - MJ 1979
                                                                                          # 20
                                                                                          MPN: 92853713302
                                                                                          STRIKER
                                                                                          from £49.21
                                                                                          from £49.21
                                                                                          # 21
                                                                                          MPN: 92853713103
                                                                                          LOCK PIN
                                                                                          from £11.37
                                                                                          from £11.37
                                                                                          # 23
                                                                                          MPN: 90024902400
                                                                                          SCREW, CSK. HD. - M 8X25
                                                                                          from £8.04
                                                                                          from £8.04
                                                                                          # 24
                                                                                          MPN: 92853716004
                                                                                          LOCKING ROD
                                                                                          from £19.56
                                                                                          from £19.56
                                                                                          # 26
                                                                                          MPN: 92853733302
                                                                                          cover - lock - D >> - MJ 1980
                                                                                          LEFT
                                                                                          from £6.54
                                                                                          from £6.54
                                                                                          # 26
                                                                                          MPN: 92853733303
                                                                                          cover - lock - D - MJ 1981>>
                                                                                          LEFT
                                                                                          from £20.69
                                                                                          from £20.69
                                                                                          # 26
                                                                                          MPN: 92853733402
                                                                                          cover - lock - D >> - MJ 1980
                                                                                          RIGHT
                                                                                          from £5.81
                                                                                          from £5.81
                                                                                          # 26
                                                                                          MPN: 92853733403
                                                                                          cover - lock - D - MJ 1981>>
                                                                                          RIGHT
                                                                                          from £29.45
                                                                                          from £29.45
                                                                                          # 27
                                                                                          MPN: 99950703302
                                                                                          speed nut - B 4,8 - Discontinued part
                                                                                          # 27
                                                                                          MPN: 99950703301
                                                                                          SPEED NUT - B 4,8
                                                                                          from £0.47
                                                                                          from £0.47
                                                                                          # 28
                                                                                          MPN: 90014311802
                                                                                          TAPPING SCREW - B 4,8 X 13
                                                                                          # 29
                                                                                          MPN: 90007507802
                                                                                          SCREW, HEX. HD. - M 8 X 15 - DISCONTINUED PART
                                                                                          # 29
                                                                                          MPN: 90007507803
                                                                                          SCREW, HEX. HD. - M 8 X 15
                                                                                          from £1.84
                                                                                          from £1.84
                                                                                          # 30
                                                                                          MPN: 92853754502
                                                                                          BEZEL FOR HANDLE
                                                                                          LEFT
                                                                                          from £4.51
                                                                                          from £4.51
                                                                                          # 30
                                                                                          MPN: 92853754602
                                                                                          BEZEL FOR HANDLE
                                                                                          RIGHT
                                                                                          from £4.08
                                                                                          from £4.08
                                                                                          # 31
                                                                                          MPN: 90026900607
                                                                                          SCREW, CSK. HD. - M 4 X 8
                                                                                          # 33
                                                                                          MPN: 99959124201
                                                                                          SPEED NUT
                                                                                          from £0.65
                                                                                          from £0.65
                                                                                          # 34
                                                                                          MPN: 92853754702
                                                                                          INTERIOR HANDLE
                                                                                          LEFT
                                                                                          # 34
                                                                                          MPN: 92853754802
                                                                                          INTERIOR HANDLE
                                                                                          RIGHT
                                                                                          # 35
                                                                                          MPN: 92853755702
                                                                                          PIN
                                                                                          from £2.34
                                                                                          from £2.34
                                                                                          # 36
                                                                                          MPN: 90011600201
                                                                                          LOCK WASHER - 3,2
                                                                                          from £0.82
                                                                                          from £0.82
                                                                                          # 37
                                                                                          MPN: 92853715702
                                                                                          SPEED NUT
                                                                                          from £2.89
                                                                                          from £2.89
                                                                                          # 38
                                                                                          MPN: 90026901502
                                                                                          SCREW, CSK. HD. - M 5 X 10
                                                                                          from £0.50
                                                                                          from £0.50
                                                                                          # 39
                                                                                          MPN: 92853705502
                                                                                          BOWDEN CABLE
                                                                                          from £15.19
                                                                                          from £15.19
                                                                                          # 40
                                                                                          MPN: 92853766102
                                                                                          FINGER PLATE
                                                                                          from £14.81
                                                                                          from £14.81
                                                                                          # 41
                                                                                          MPN: 92853706304
                                                                                          Mounting - D >> - MJ 1980 - Discontinued part
                                                                                          LEFT
                                                                                          from £34.37
                                                                                          from £34.37
                                                                                          # 41
                                                                                          MPN: 92853706304
                                                                                          mounting - D - MJ 1981>> - Discontinued part
                                                                                          LEFT
                                                                                          from £34.37
                                                                                          from £34.37
                                                                                          # 41
                                                                                          MPN: 92853706304
                                                                                          MOUNTING
                                                                                          from £34.37
                                                                                          from £34.37
                                                                                          # 41
                                                                                          MPN: 92853706404
                                                                                          Mounting - D >> - MJ 1980 - Discontinued part
                                                                                          RIGHT
                                                                                          from £30.42
                                                                                          from £30.42
                                                                                          # 41
                                                                                          MPN: 92853706404
                                                                                          mounting - D - MJ 1981>> - Discontinued part
                                                                                          RIGHT
                                                                                          from £30.42
                                                                                          from £30.42
                                                                                          # 41
                                                                                          MPN: 92853706404
                                                                                          MOUNTING
                                                                                          from £30.42
                                                                                          from £30.42
                                                                                          # 42
                                                                                          MPN: 90007601002
                                                                                          NUT - M 6 - DISCONTINUED PART
                                                                                          # 42
                                                                                          MPN: 9000760100B
                                                                                          NUT - M 6
                                                                                          from £0.73
                                                                                          from £0.73
                                                                                          # 43
                                                                                          MPN: N 0120064
                                                                                          LOCK RING - B 6
                                                                                          from £0.70
                                                                                          from £0.70
                                                                                          # 44
                                                                                          MPN: N 0147612
                                                                                          bolt, with hex. socket - hd. - M 6 X 12 - Discontinued part
                                                                                          # 44
                                                                                          MPN: 90011912901
                                                                                          SCREW, CHEESE HD. - M 6 X 12
                                                                                          from £0.73
                                                                                          from £0.73
                                                                                          # 45
                                                                                          MPN: N 0122265
                                                                                          SPRING WASHER - B 6
                                                                                          from £0.70
                                                                                          from £0.70
                                                                                          # 46
                                                                                          MPN: 92853714002
                                                                                          connecting rod - D >> - MJ 1980
                                                                                          # 46
                                                                                          MPN: 92853714003
                                                                                          connecting rod - D - MJ 1981>>
                                                                                          # 47
                                                                                          MPN: 92853711102
                                                                                          operating rod - D - MJ 1978>> - MJ 1978
                                                                                          from £3.20
                                                                                          from £3.20
                                                                                          # 47
                                                                                          MPN: 92853711202
                                                                                          operating rod - D - MJ 1978>> - MJ 1978
                                                                                          from £13.91
                                                                                          from £13.91
                                                                                          # 47
                                                                                          MPN: 92853711103
                                                                                          operating rod - D >> - MJ 1980
                                                                                          # 47
                                                                                          MPN: 92853711104
                                                                                          operating rod - D - MJ 1981>>
                                                                                          from £3.20
                                                                                          from £3.20
                                                                                          # 48
                                                                                          MPN: 99970322440
                                                                                          CAP
                                                                                          from £1.25
                                                                                          from £1.25
                                                                                          # 49
                                                                                          MPN: 90011903502
                                                                                          screw, cheese hd. - M 6 X 8 - D >> - MJ 1980
                                                                                          from £1.12
                                                                                          from £1.12
                                                                                          # 49
                                                                                          MPN: 99921800302
                                                                                          screw, cheese hd. - M 6 X 18 - D - MJ 1981>>
                                                                                          from £4.08
                                                                                          from £4.08
                                                                                          # 50
                                                                                          MPN: N 0115247
                                                                                          WASHER - B 6,4 - DISCONTINUED PART
                                                                                          # 50
                                                                                          MPN: N 01152427
                                                                                          WASHER - B 6,4
                                                                                          from £0.47
                                                                                          from £0.47
                                                                                          # 51
                                                                                          MPN: N 0122265
                                                                                          SPRING WASHER - A 6 - D >> - MJ 1980
                                                                                          from £0.70
                                                                                          from £0.70
                                                                                          # 52
                                                                                          MPN: 92853711703
                                                                                          CARRIER
                                                                                          LEFT
                                                                                          # 52
                                                                                          MPN: 92853711803
                                                                                          CARRIER
                                                                                          RIGHT
                                                                                          # 53
                                                                                          MPN: 92853763305
                                                                                          DOOR LOCK CYLINDER - ESCUTCHEON - BLACK - WITHOUT KEY - STATE LOCK NUMBER - D - MJ 1979>>
                                                                                          from £356.77
                                                                                          from £356.77
                                                                                          # 53
                                                                                          MPN: 92853763306
                                                                                          Door lock cylinder - Escutcheon - Chrome plated - without key - State lock number - also use: - D - MJ 1978>> - MJ 1978
                                                                                          -----928 537 111 03
                                                                                          # 53
                                                                                          MPN: 92853790302
                                                                                          DOOR LOCK CYLINDER - ESCUTCHEON - BLACK - SECONDARY KEY - W/O STIPULATED LOCK NUMBER - D - MJ 1979>>
                                                                                          from £350.78
                                                                                          from £350.78
                                                                                          # 53
                                                                                          MPN: 92853790303
                                                                                          Door lock cylinder - D - MJ 1978>> - MJ 1978 - Discontinued part
                                                                                          # 53
                                                                                          MPN: 92853790304
                                                                                          DOOR LOCK CYLINDER - ESCUTCHEON - CHROME PLATED - SECONDARY KEY
                                                                                          from £91.83
                                                                                          from £91.83
                                                                                          # -
                                                                                          -
                                                                                          W/O STIPULATED LOCK NUMBER - ALSO USE:
                                                                                          -928 537 111 03
                                                                                          # 53
                                                                                          MPN: 92853701702
                                                                                          MAIN KEY - WITH: - KEY LAMP - STATE LOCK NUMBER
                                                                                          # -
                                                                                          -
                                                                                          COVER
                                                                                          # -
                                                                                          -
                                                                                          CONTACT PLATE
                                                                                          # -
                                                                                          -
                                                                                          CONNECTING LUG
                                                                                          # -
                                                                                          -
                                                                                          PRESSURE SPRING
                                                                                          # -
                                                                                          -
                                                                                          button
                                                                                          # -
                                                                                          -
                                                                                          BULB
                                                                                          # 53
                                                                                          MPN: 92853763910
                                                                                          BLANK KEY - (UNCUT)
                                                                                          from £40.51
                                                                                          from £40.51
                                                                                          # 54
                                                                                          MPN: 92853753102
                                                                                          PACKING - FOR LOCK CYLINDER
                                                                                          from £2.65
                                                                                          from £2.65
                                                                                          # 55
                                                                                          MPN: 92853757302
                                                                                          spacer sleeve - D - MJ 1981>>
                                                                                          from £2.27
                                                                                          from £2.27
