porsche 1980 (928) starter - battery parts diagram

902-000 - STARTER - BATTERY

Porsche 1980 (928) STARTER - BATTERY Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                  #
                                  Part number
                                  Description
                                  Key
                                  Price
                                  # 1
                                  MPN: 92860410304
                                  STARTER - 1,5 KW
                                  STARTER - 1,5 KW Genuine Porsche Part - New (to order)
                                  # 1
                                  MPN: 928604103DX
                                  STARTER - 1,5 KW - DISCONTINUED PART
                                  STARTER Genuine Porsche Part - New (to order)
                                  # 1
                                  MPN: 928604103EX
                                  STARTER - 1,5 KW
                                  from £569.63
                                  from £569.63
                                  STARTER Genuine Porsche Part - New (to order)
                                  # 2
                                  MPN: 90006712402
                                  SCREW, CHEESE HD. - M 10 X 35
                                  from £1.40
                                  from £1.40
                                  screw, cheese hd. - M 10X35 Genuine Porsche Part - New (to order)
                                  # 3
                                  MPN: 90002701602
                                  LOCK RING - B 10 - DISCONTINUED PART
                                  LOCK RING - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                  # 3
                                  MPN: 90002701603
                                  LOCK RING - B 10
                                  from £0.65
                                  from £0.65
                                  LOCK RING - B 12 Genuine Porsche Part - New (to order)
                                  # 4
                                  MPN: 90007527502
                                  SCREW, CHEESE HD. - AM 4 X 8
                                  SCREW, CHEESE HD. - AM 4 X 8 Genuine Porsche Part - New (to order)
                                  # 5
                                  MPN: N 0120053
                                  LOCK RING
                                  from £0.66
                                  from £0.66
                                  LOCK RING Genuine Porsche Part - New (to order)
                                  # 8
                                  MPN: 90007602502
                                  HEX. NUT - DISCONTINUED PART
                                  Supersession
                                  Supersession
                                  Genuine Porsche Part (no longer available to order)
                                  # 8
                                  MPN: 90007606402
                                  HEX. NUT
                                  from £0.59
                                  from £0.59
                                  hex. nut - SW 13 M 8 Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 92861110100
                                  BATTERY - 12 V - 66 AH - DISCONTINUED PART
                                  BATTERY - 12 V 66 AH - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 92861110101
                                  BATTERY - 12 V - 66 AH - DISCONTINUED PART
                                  BATTERY - 12 V 66 AH - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 92861117502
                                  BATTERY - 12 V - 75 AH - DISCONTINUED PART
                                  BATTERY - 12 V 75 AH - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 99961107020
                                  BATTERY - 12 V - 70 AH - DISCONTINUED PART
                                  battery - 70 AH - Discontinued part Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 99961107021
                                  BATTERY - 12 V - 70 AH
                                  from £145.12
                                  from £145.12
                                  battery - 70 AH Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 99961108820
                                  BATTERY - 12 V - 88 AH
                                  battery - 12V - 88 AH Genuine Porsche Part - New (to order)
                                  # 10
                                  MPN: 92861101701
                                  battery box - D >> - MJ 1978
                                  from £336.68
                                  from £336.68
                                  battery box - D >> - MJ 1978 Genuine Porsche Part - New (to order)
                                  # 11
                                  MPN: 92861114701
                                  COVER FOR HOUSING - D >> - MJ 1978
                                  COVER FOR HOUSING - D >> - MJ 1978 Genuine Porsche Part - New (to order)
                                  # 12
                                  MPN: 92861115300
                                  Rubber strip - D >> - MJ 1978
                                  from £2.91
                                  from £2.91
                                  Rubber strip - D >> - MJ 1978 Genuine Porsche Part - New (to order)
                                  # 13
                                  MPN: 92861115301
                                  Rubber strip - D >> - MJ 1978
                                  from £4.08
                                  from £4.08
                                  Rubber strip - D >> - MJ 1978 Genuine Porsche Part - New (to order)
                                  # 14
                                  MPN: 92861115900
                                  Rubber plate - D >> - MJ 1978
                                  from £1.27
                                  from £1.27
                                  Rubber plate - D >> - MJ 1978 Genuine Porsche Part - New (to order)
                                  # 15
                                  MPN: 92861200700
                                  harness - D >> - MJ 1978
                                  LHD
                                  harness - D >> - MJ 1978 Genuine Porsche Part - New (to order)
                                  # 15
                                  MPN: 92861200701
                                  harness - D >> - MJ 1978
                                  RHD
                                  from £182.14
                                  from £182.14
                                  harness - D - MJ 1979>> Genuine Porsche Part - New (to order)
                                  # 15
                                  MPN: 92861200701
                                  harness - D - MJ 1979>>
                                  from £182.14
                                  from £182.14
                                  harness - D - MJ 1979>> Genuine Porsche Part - New (to order)
                                  # -
                                  -
                                  CABLE HOLDER
                                  # -
                                  -
                                  SPRING WASHER
                                  # -
                                  -
                                  TAPPING SCREW,HEX.HD. - 6,3 X 13
                                  # -
                                  -
                                  TIE WRAP
                                  # -
                                  -
                                  GROMMET - BATTERY STARTER CABLE
                                  # -
                                  -
                                  POLE COVERING - BATTERY
                                  # 16
                                  MPN: 92861200900
                                  ground strap - D >> - MJ 1978
                                  LHD
                                  ground strap - D >> - MJ 1978 Genuine Porsche Part - New (to order)
                                  # 16
                                  MPN: 92861200910
                                  ground strap - D >> - MJ 1978
                                  RHD
                                  ground strap - D >> - MJ 1981 Genuine Porsche Part - New (to order)
                                  # 16
                                  MPN: 92861200910
                                  ground strap - D >> - MJ 1981
                                  ground strap - D >> - MJ 1981 Genuine Porsche Part - New (to order)
                                  # 16
                                  MPN: 92861200913
                                  ground strap - D >> - MJ 1978
                                  rhd (PR:197)
                                  Supersession
                                  Supersession
                                  Genuine Porsche Part (no longer available to order)
                                  # 16
                                  MPN: 92861200913
                                  ground strap - D >> - MJ 1982
                                  (PR:197)
                                  Supersession
                                  Supersession
                                  Genuine Porsche Part (no longer available to order)
                                  # 17
                                  MPN: 90091001202
                                  LOCK NUT - D >> - MJ 1978 - DISCONTINUED PART
                                  lock nut - NM 6 - Discontinued part Genuine Porsche Part - New (to order)
                                  # 17
                                  MPN: 90091004709
                                  LOCK NUT
                                  from £3.80
                                  from £3.80
                                  lock nut - NM 6 Genuine Porsche Part - New (to order)
                                  # 18
                                  MPN: 92861290200
                                  CLAMP - BATTERY STARTER CABLE
                                  from £2.20
                                  from £2.20
                                  Clamp - bracket Genuine Porsche Part - New (to order)
                                  # -
                                  -
                                  WING NUT - FOR - GROUND CABLE
                                  # -
                                  -
                                  spring washer - for - Ground cable
                                  # -
                                  -
                                  WASHER
                                  # -
                                  -
                                  DUMMY GROMMET - FOR - MOUNT - GROUND CABLE
                                  # -
                                  -
                                  FASTENERS - BATTERY
                                  # -
                                  -
                                  bracket - D >> - MJ 1981
                                  # -
                                  -
                                  bracket - D >> - MJ 1981
                                  (PR:197)
                                  # -
                                  -
                                  bracket - D - MJ 1982>> - MJ 1982
                                  # -
                                  -
                                  WASHER - D - MJ 1979>> - DISCONTINUED PART
                                  # -
                                  -
                                  Washer - D - MJ 1979>>
                                  # -
                                  -
                                  LOCK RING - B 8 - D - MJ 1979>>
                                  # -
                                  -
                                  LOCK RING - B 8 - D - MJ 1979>>
                                  # -
                                  -
                                  SCREW, HEX. HD. - M 8 X 16 - D - MJ 1979>> - DISCONTINUED PART
                                  # -
                                  -
                                  screw, hex. hd. - M 8 X 16 - D - MJ 1979>>
                                  # -
                                  -
                                  SCREW, HEX. HD. - M 8 X 16
                                  M8X16-yellow
                                  This part replaces part number 90007508703
