904-000 - WINDSCREEN WIPER SYSTEM
Porsche 1984 (928) WINDSCREEN WIPER SYSTEM Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 92862830302
wiper motor - D >> - MJ 1984
LHD
from £315.90
from £315.90
# 1
MPN: 92862830301
wiper motor - D - MJ 1983>> - MJ 1983
RHD
from £332.63
from £332.63
# 1
MPN: 92762830301
wiper motor - D - MJ 1984>> - MJ 1984
RHD
from £251.14
from £251.14
# 1
MPN: 94462830301
wiper motor - D - MJ 1985>>
LHD
from £474.95
from £474.95
# 1
MPN: 92762830303
wiper motor - D - MJ 1985>>
RHD
from £437.44
from £437.44
# 2
MPN: 92862893200
Crank drive - D >> - MJ 1984
LHD
from £66.94
from £66.94
# 2
MPN: 92762822100
Crank drive - D - MJ 1983>> - MJ 1983
RHD
from £153.97
from £153.97
# 2
MPN: 92762893200
Crank drive - D - MJ 1984>> - MJ 1984
RHD
from £111.56
from £111.56
# 2
MPN: 92862822101
Crank drive - D - MJ 1985>>
LHD
# 2
MPN: 92762822101
Crank drive - D - MJ 1985>>
RHD
# 3
MPN: N 0421213
SHAKE-PROOF WASHER - D >> - MJ 1984
LHD
from £0.63
from £0.63
# 4
MPN: 99907200509
HEX. NUT - M 6 X 12 - D >> - MJ 1984 - DISCONTINUED PART
# 4
MPN: 99907200501
SCREW, HEX. HD. - M 6 X 12
from £2.58
from £2.58
# 4
MPN: 90027800202
screw, hex. hd. - CM 6 X 16 - D - MJ 1985>>
# 5
MPN: 92862824301
lever - D >> - MJ 1984
LHD
from £7.59
from £7.59
# 5
MPN: 92862823302
lever - D - MJ 1983>> - MJ 1983
RHD
from £10.73
from £10.73
# 5
MPN: 92862824301
lever - D - MJ 1984>> - MJ 1984
RHD
from £7.59
from £7.59
# 5
MPN: 92862824302
lever - D - MJ 1985>>
from £6.98
from £6.98
# 6
MPN: 99908405502
LOCK NUT - M 8
# 7
MPN: 90162892400
rubber bush - D >> - MJ 1984
from £5.70
from £5.70
# 7
MPN: 94462812900
RUBBER BUSH - D - MJ 1985>>
# 8
MPN: 90162892301
rubber bush - D >> - MJ 1984
from £9.63
from £9.63
# 8
MPN: 94462812800
BUSH - D - MJ 1985>> - DISCONTINUED PART
# -
-
BUSH - SATZ BESTEHEND AUS - 2 X 94462812800 - 2 X 94462812900
# 9
MPN: 91162896300
Flange washer - Black - D >> - MJ 1984
from £12.80
from £12.80
# 9
MPN: 94462812500
Washer - D - MJ 1985>>
from £2.32
from £2.32
# 10
MPN: 92862871602
GROMMET
RIGHT
# 10
MPN: 92862871701
GROMMET
LEFT
# 11
MPN: 477955149
hex. nut - D >> - MJ 1984
from £2.04
from £2.04
# 11
MPN: 99903401302
HEX. NUT - D - MJ 1985>>
from £2.34
from £2.34
# 12
MPN: 92862821305
WIPER ARM - (PASSENGER SIDE)
LHD
# 12
MPN: 92762821302
WIPER ARM
RHD
# 12
MPN: 92862821306
WIPER ARM - (DRIVERS SIDE) - WITH SPOILER
LHD
from £151.32
from £151.32
# -
-
CAP
# 13
MPN: 803955437
SPRING WASHER
from £5.52
from £5.52
# 14
MPN: N 0111512
hex. nut - D >> - MJ 1984
from £0.77
from £0.77
# 14
MPN: 90007602502
HEX. NUT - D - MJ 1985>> - DISCONTINUED PART
Supersession
Supersession
# 14
MPN: 90007606402
HEX. NUT - D - MJ 1985>>
from £0.59
from £0.59
# 15
MPN: 478955425
WIPER BLADE
from £21.69
from £21.69
# 15
MPN: 478955425
WIPER BLADE - (PASSENGER SIDE) - D - MJ 1986>> - MJ 1986
RHD
from £21.69
from £21.69
# 15
MPN: 92862821703
WIPER BLADE - (DRIVERS SIDE) - WITH SPOILER - D - MJ 1986>> - MJ 1986
RHD
# 16
MPN: 90007501402
screw, hex. hd. - M 6 X 18 - D >> - MJ 1984 - Discontinued part
# 16
MPN: 90007501403
screw, hex. hd. - M 6 X 18 - D >> - MJ 1984
from £2.04
from £2.04
# 16
MPN: N 0102179
screw, hex. hd. - M 6 X 20 - D - MJ 1985>>
Supersession
Supersession
# 17
MPN: N 0116667
Washer - D >> - MJ 1984
# 17
MPN: N 90270701
Washer - 6,1 X 18 X 1,5 - D - MJ 1985>>
from £1.08
from £1.08
# 18
MPN: 92862828700
GROMMET
# 19
MPN: 92862828900
BUSHING
from £1.47
from £1.47
# 20
MPN: 92862875900
Rubber strap - D - MJ 1983>> - MJ 1983
RHD
# 21
MPN: 99951237102
HOSE CLAMP - D - MJ 1983>> - MJ 1983
RHD
# -
-
SPEED NUT - M 6 - DISCONTINUED PART
# -
-
SPEED NUT - M 6
# 22
MPN: 92862891500
ROD - FOR - WIPER MOTOR - F 92 ES0524 - F 92 ES0525 - F 92 ES0527 - F 92 ES0528 - F 92 ES0536 - F 92 ES0540 - F 92 ES0544 - F 92 ES0545 - F 92 ES0546
rhd-right
from £43.59
from £43.59
# 23
MPN: 91161286702
Connector housing - D - MJ 1985>>
from £15.95
from £15.95
