304-000 - MANUAL GEARBOX - SHIFT RODS - SHIFT FORKS
Porsche 1987 (928) MANUAL GEARBOX - SHIFT RODS - SHIFT FORKS Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 92830310730
INNER SHIFT ROD
from £39.27
from £39.27
# 2
MPN: 92830310234
SELECTOR SHAFT - 4TH SPEED - 5TH GEAR
# 3
MPN: 92830310128
SELECTOR SHAFT - 2ND GEAR - 3RD GEAR
from £41.72
from £41.72
# 4
MPN: 92830310527
SELECTOR SHAFT - 1ST GEAR - REVERSE GEAR
from £11.14
from £11.14
# 5
MPN: 92830311327
SELECTOR FORK - 2ND GEAR - 3RD GEAR - 4TH SPEED - 5TH GEAR
# 6
MPN: 92830311541
SELECTOR FORK - 1ST GEAR - REVERSE GEAR
from £185.34
from £185.34
# 7
MPN: N 0133171
PIN
from £2.44
from £2.44
# 8
MPN: N 01152513
Washer - A 8,4
# 9
MPN: N 0103594
SCREW, HEX. HD. - M 8 X 40
from £1.47
from £1.47
# 10
MPN: 90030901300
PIN
from £0.88
from £0.88
# 11
MPN: 92830303206
Preselector lever - D - MJ 1987>> - MJ 1987 - Discontinued part
from £249.22
from £249.22
# 11
MPN: 92830303206
Preselector lever - D - MJ 1988>>
from £249.22
from £249.22
# 12
MPN: 92830330104
TRIP CAM
from £31.54
from £31.54
# 13
MPN: 92830303409
SPRING
# -
-
PIN
# 15
MPN: 92830333104
THREADED BOLT - M 14 X 1
# 16
MPN: N 0124101
LOCK RING - 10 X 1
from £0.47
from £0.47
# 17
MPN: 99907603202
HEX. NUT - M 14 X 1
from £1.57
from £1.57
# 18
MPN: 99907001202
CAP NUT - M 14 X 1
from £2.27
from £2.27
# 19
MPN: 92830303100
ROLLER LEVER
from £18.89
from £18.89
# 20
MPN: 92830330901
PRESSURE SPRING
from £2.34
from £2.34
# 22
MPN: 92830331102
GUIDE SLEEVE
from £16.53
from £16.53
# 23
MPN: 92830331300
GASKET
from £1.97
from £1.97
# 24
MPN: 92830311708
SHIFT FINGER
from £98.44
from £98.44
# 25
MPN: N 0115247
WASHER - A 6,4 - DISCONTINUED PART
# 25
MPN: N 01152427
Washer - A 6,4
from £0.47
from £0.47
# 26
MPN: 90007501602
SCREW, HEX. HD. - M 6 X 22 - DISCONTINUED PART
# 26
MPN: 90007501603
SCREW, HEX. HD. - M 6 X 22
from £0.86
from £0.86
# -
-
LOCK WASHER
