401-005 - STEERING KNUCKLE - LUBRICANTS
Porsche 1989 (928) STEERING KNUCKLE - LUBRICANTS Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# -
MPN: PCG04311000
GREASE - MOUNTING - 200 GR.
from £18.73
from £18.73
# 1
MPN: 92834105716
steering knuckle - D >> - MJ 1988
LEFT
# 1
MPN: 92834105717
steering knuckle - D - MJ 1989>>
LEFT
from £1,291.66
from £1,291.66
# 1
MPN: 92834105816
steering knuckle - D >> - MJ 1988
RIGHT
# 1
MPN: 92834105817
steering knuckle - D - MJ 1989>>
RIGHT
from £1,621.22
from £1,621.22
# 2
MPN: 92834106604
FRONT-WHEEL HUB - D >> - MJ 1988 - ALSO USE:
--PCG04311000-99905909000-99905908901-477405641
from £389.22
from £389.22
# 2
MPN: 92834106604
Front-wheel hub - D - MJ 1989>>
from £389.22
from £389.22
# 3
MPN: 92834167102
WHEEL BOLT
from £9.99
from £9.99
# 3
MPN: 92834167102
WHEEL BOLT - OVERSIZE
from £9.99
from £9.99
# 4
MPN: 99905909000
TAPER ROLLER BEARING - ALSO USE:
-PCG04311000-477405641
from £18.43
from £18.43
# 5
MPN: 99905908901
TAPER ROLLER BEARING - ALSO USE:
-PCG04311000
from £18.32
from £18.32
# 6
MPN: 477405641
RADIAL SHAFT SEAL
from £13.99
from £13.99
# 7
MPN: 91134166300
THRUST WASHER
from £4.70
from £4.70
# 8
MPN: 91134167300
CLAMPING NUT
from £31.46
from £31.46
# 9
MPN: 99911900101
SCREW, CHEESE HD. - M 7 X 18 - DISCONTINUED PART
# 9
MPN: 9991190010B
SCREW, CHEESE HD. - M 7 X 18
from £2.93
from £2.93
# 10
MPN: 91134168400
CAP
from £40.29
from £40.29
# 11
MPN: 90038001009
LOCK NUT - M 12 X 1,5
# 12
MPN: 92834307306
stabilizer - 28MM
from £242.59
from £242.59
# 13
MPN: 92834377700
BEARING CLAMP
from £41.72
from £41.72
# 14
MPN: 92834379304
Mount for stabilizer - 28MM
Supersession
Supersession
# 15
MPN: 90007504302
SCREW, HEX. HD. - M 10 X 30
RHD
Supersession
Supersession
# 15
MPN: N 0102753
SCREW, HEX. HD. - M 10 X 35 - DISCONTINUED PART
LHD
# 15
MPN: 90007546001
SCREW, HEX. HD. - M 10 X 35
LHD
Supersession
Supersession
# 15
MPN: 90007546002
SCREW, HEX. HD. - M 10 X 35
M10X35-yellow
from £1.58
from £1.58
This part replaces part number 90007546001
# 15
MPN: 90007504302
SCREW, HEX. HD. - M 10 X 30
LHD
Supersession
Supersession
# 16
MPN: 90002701602
LOCK RING - B 10 - DISCONTINUED PART
# 16
MPN: 90002701603
LOCK RING - B 10
from £0.65
from £0.65
# 17
MPN: 92834306901
CONNECTING LINK
# 17
MPN: 92834306991
CONNECTING LINK
from £142.93
from £142.93
# 18
MPN: N 0221411
NUT - M 12 X 1,5 - DISCONTINUED PART
Supersession
Supersession
# 18
MPN: 90036000201
lock nut - M 12 X 1,5 - Discontinued part
# 18
MPN: 9003600020B
LOCK NUT - M 12 X 1,5
Supersession
Supersession
# 19
MPN: N 0101543
SCREW, HEX. HD. - M 12 X 1,5 X 55
from £4.65
from £4.65
# 20
MPN: 92834108501
bracket - D - MJ 1989>>
(PR:482)
from £7.57
from £7.57
# 21
MPN: N 0102272
screw, hex. hd. - M 6 X 18 - D - MJ 1989>>
(PR:482)
from £1.09
from £1.09
# 22
MPN: N 0122265
spring washer - B 6 - D - MJ 1989>>
(PR:482)
from £0.70
from £0.70
