porsche 1989 (928) brake lines parts diagram

604-005 - brake lines

Porsche 1989 (928) BRAKE LINES Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: 92835508102
                BRAKE HOSE - ALSO USE:
                front-00004430501
                brake hose - D - MJ 1993>> Genuine Porsche Part - New (to order)
                # 2
                MPN: 92835505301
                brake line
                lhd-left-front
                from £19.17
                from £19.17
                brake line Genuine Porsche Part - New (to order)
                # 2
                MPN: 92735505301
                brake line
                rhd-left-front
                from £33.98
                from £33.98
                brake line Genuine Porsche Part - New (to order)
                # 3
                MPN: 92835504900
                brake line
                LHD
                from £9.92
                from £9.92
                brake line Genuine Porsche Part - New (to order)
                # 3
                MPN: 92735504900
                brake line
                RHD
                from £1.98
                from £1.98
                brake line Genuine Porsche Part - New (to order)
                # 4
                MPN: 92835505102
                brake line
                lhd-front
                from £47.36
                from £47.36
                brake line Genuine Porsche Part - New (to order)
                # 4
                MPN: 92735505101
                brake line
                rhd-front
                from £20.77
                from £20.77
                brake line Genuine Porsche Part - New (to order)
                # 6
                MPN: 92835505704
                brake line
                left-rear
                from £70.35
                from £70.35
                Brake line - - D - MJ 1986>> - MJ 1986 Genuine Porsche Part - New (to order)
                # 7
                MPN: 92835505901
                brake line
                right-rear
                from £70.35
                from £70.35
                Brake line - - D - MJ 1986>> - MJ 1986 Genuine Porsche Part - New (to order)
                # 8
                MPN: 113611715A
                BRAKE HOSE BRACKET
                from £2.76
                from £2.76
                BRAKE HOSE BRACKET - D >>- MJ 1979 Genuine Porsche Part - New (to order)
                # 9
                MPN: 91435566700
                DISTRIBUTOR
                from £28.66
                from £28.66
                distributor - D - MJ 1992>> Genuine Porsche Part - New (to order)
                # 10
                MPN: 90007501702
                SCREW, HEX. HD. - M 6 X 25
                SCREW, HEX. HD. - M 6 X V25 - DISCONTINUED PART Genuine Porsche Part - New (to order)
                # 10
                MPN: 90007501703
                SCREW, HEX. HD. - M 6 X 25
                from £0.73
                from £0.73
                SCREW, HEX. HD. - M 6 X V25 Genuine Porsche Part - New (to order)
                # 11
                MPN: N 0122265
                SPRING WASHER - B 6
                from £0.70
                from £0.70
                spring washer - M6X16 Genuine Porsche Part - New In stock
                # 12
                MPN: 90007601002
                NUT - M 6 - DISCONTINUED PART
                nut - M6 - Discontinued part Genuine Porsche Part - New (to order)
                # 12
                MPN: 9000760100B
                NUT - M 6
                from £0.73
                from £0.73
                NUT - M6 Genuine Porsche Part - New In stock
                # 13
                MPN: 92835565100
                BRACKET
                LHD
                BRACKET Genuine Porsche Part - New (to order)
                # 13
                MPN: 92735565100
                BRACKET
                RHD
                BRACKET Genuine Porsche Part - New (to order)
                # 14
                MPN: N 0138062
                SEAL RING - A 10 X 14
                from £0.65
                from £0.65
                seal ring - F 92-DS841 330>> Genuine Porsche Part - New (to order)
                # 15
                MPN: 99913402702
                BANJO BOLT - M 10 X 1 - DISCONTINUED PART
                BANJO BOLT - M 10 X 1 - DISCONTINUED PART Genuine Porsche Part - New (to order)
                # 15
                MPN: 9991340270B
                banjo bolt - M 10 X 1
                from £9.62
                from £9.62
                banjo bolt - M 10 X 1 Genuine Porsche Part - New (to order)
