porsche 1992 (928) tire pressure control system - d >> - mj 1993 parts diagram

601-005 - TIRE PRESSURE CONTROL SYSTEM - D >> - MJ 1993

Porsche 1992 (928) TIRE PRESSURE CONTROL SYSTEM - D >> - MJ 1993 Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                  #
                  Part number
                  Description
                  Key
                  Price
                  # 1
                  MPN: 92861815001
                  electronic control module
                  from £583.70
                  from £583.70
                  electronic control module - D - MJ 1991>> Genuine Porsche Part - New (to order)
                  # 2
                  MPN: 92860641300
                  PRESSURE SENSOR
                  FRONT
                  from £353.95
                  from £353.95
                  PRESSURE SENSOR Genuine Porsche Part - New (to order)
                  # 3
                  MPN: 92860641400
                  PRESSURE SENSOR
                  rear
                  from £353.95
                  from £353.95
                  PRESSURE SENSOR Genuine Porsche Part - New (to order)
                  # 4
                  MPN: N 0447341
                  SCREW, CHEESE HD. - M 5 X 15 - DISCONTINUED PART
                  screw, cheese hd. - M 5 X15 - Discontinued part Genuine Porsche Part - New (to order)
                  # 4
                  MPN: 90006713701
                  SCREW, CHEESE HD. - M 5 X 15
                  from £0.99
                  from £0.99
                  SCREW, CHEESE HD. - M 5 X 16 Genuine Porsche Part - New (to order)
                  # 5
                  MPN: N 0122253
                  SPRING WASHER - B 5
                  from £0.59
                  from £0.59
                  SPRING WASHER - B 5 Genuine Porsche Part - New (to order)
                  # 6
                  MPN: 92836120301
                  NUT
                  from £24.60
                  from £24.60
                  NUT Genuine Porsche Part - New (to order)
                  # 7
                  MPN: 99970703540
                  O-RING - 30 X 1,5
                  from £2.34
                  from £2.34
                  O-RING - 30 X 1,5 Genuine Porsche Part - New (to order)
                  # 8
                  MPN: 92836102200
                  pressure switch - 2,5 BAR
                  from £456.27
                  from £456.27
                  pressure switch - 2,5 BAR Genuine Porsche Part - New (to order)
                  # 8
                  MPN: 92836102300
                  pressure switch - 3,0 BAR
                  from £322.49
                  from £322.49
                  pressure switch - 3,0 BAR Genuine Porsche Part - New (to order)
                  # 9
                  MPN: 92836120102
                  PROTECTIVE CAP
                  from £3.73
                  from £3.73
                  PROTECTIVE CAP - DISCONTINUED PART Genuine Porsche Part - New (to order)
                  # 10
                  MPN: 92870128710
                  STICKER - FOR - TYRE - ASSEMBLY
                  from £11.97
                  from £11.97
                  STICKER - FOR - TYRE - ASSEMBLY Genuine Porsche Part - New (to order)
