201-005 - FUEL SYSTEM
Porsche 1993 (928) FUEL SYSTEM Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 92860801300
IN-TANK FUEL PUMP - DISCONTINUED PART
Supersession
Supersession
# 1
MPN: 92860801301
IN-TANK FUEL PUMP
from £644.46
from £644.46
This part replaces part number 92860801300
# 3
MPN: 92820118702
SEAL RING
Supersession
Supersession
# 4
MPN: 92835655004
FUEL HOSE
from £23.54
from £23.54
# 5
MPN: 99951234600
HOSE CLAMP - A 20/9
from £3.29
from £3.29
# 7
MPN: 92860810403
fuel pump
Supersession
Supersession
# 8
MPN: 893906093
CHECK VALVE
from £40.10
from £40.10
# 9
MPN: 92835615101
BRACKET
# 10
MPN: 99951239400
HOSE CLAMP
from £2.73
from £2.73
# 11
MPN: 92811025304
FUEL FILTER
((AG)(SA))
Supersession
Supersession
# 11
MPN: 92811025306
FUEL FILTER
Supersession
Supersession
# 12
MPN: 99951227602
CLAMP - DISCONTINUED PART
# 12
MPN: 9995122760B
CLAMP
from £6.26
from £6.26
# 13
MPN: 92835606310
FUEL LINE - DISCONTINUED PART
Supersession
Supersession
# 13
MPN: 92835606311
FUEL LINE
Supersession
Supersession
# 14
MPN: 90012300520
SEAL RING - A 12 X 16
from £0.59
from £0.59
# 15
MPN: 92811047501
CAP NUT - DISCONTINUED PART
Supersession
Supersession
# 15
MPN: 92811047503
CAP NUT - DISCONTINUED PART
# 15
MPN: 92811047504
CAP NUT
Supersession
Supersession
# 16
MPN: 94461011500
BONDED RUBBER MOUNTING
from £26.85
from £26.85
# 17
MPN: N 0120064
LOCK RING - B 6
from £0.70
from £0.70
# 18
MPN: N 0116667
WASHER - B 6,4
# 19
MPN: 90007601002
NUT - M 6 - DISCONTINUED PART
# 19
MPN: 9000760100B
NUT - M 6
from £0.73
from £0.73
# 20
MPN: 92835605301
FUEL LINE
Supersession
Supersession
# 21
MPN: 92835605700
FUEL LINE - DISCONTINUED PART
# 21
MPN: 92835605703
FUEL LINE
from £331.15
from £331.15
# 22
MPN: 92835602910
FUEL LINE - TO ENGINE COMPARTMENT - DISCONTINUED PART
# 22
MPN: 92835602912
fuel line - To engine compartment
Supersession
Supersession
# 23
MPN: 92835603105
FUEL LINE - RETURN LINE TO TANK - DISCONTINUED PART
# 23
MPN: 92835603106
FUEL LINE - RETURN LINE TO TANK
from £146.03
from £146.03
# 24
MPN: N 0235692
HOSE CLAMP - AR 16/9 - DISCONTINUED PART
# 24
MPN: PCG0235692
HOSE CLAMP - AR 16/9
from £2.11
from £2.11
# 25
MPN: 92835655101
RUBBER ISOLATOR
from £4.08
from £4.08
# 26
MPN: 92835655300
BOW
from £4.08
from £4.08
# 27
MPN: 477209169
CONNECTING PIECE
from £19.27
from £19.27
# 28
MPN: 99959148702
SPEED NUT
# 29
MPN: 90018711502
BOLT WITH WASHER - DISCONTINUED PART
# 29
MPN: 90018711501
BOLT WITH WASHER
from £4.00
from £4.00
# 30
MPN: 99951108502
CLAMP
from £6.44
from £6.44
# 31
MPN: 92835655500
CLAMP
from £3.27
from £3.27
# 32
MPN: 92835652501
RUBBER ISOLATOR
from £13.32
from £13.32
