porsche 1982 (944) track control arm - cross member parts diagram

401-000 - TRACK CONTROL ARM - CROSS MEMBER

Porsche 1982 (944) TRACK CONTROL ARM - CROSS MEMBER Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                        #
                                        Part number
                                        Description
                                        Key
                                        Price
                                        # 1
                                        MPN: 94434110306
                                        CROSS MEMBER
                                        LHD
                                        from £791.74
                                        from £791.74
                                        CROSS MEMBER Genuine Porsche Part - New (to order)
                                        # 1
                                        MPN: 94534110304
                                        CROSS MEMBER
                                        RHD
                                        from £373.01
                                        from £373.01
                                        CROSS MEMBER - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                        # 2
                                        MPN: 171407153D
                                        TRACK CONTROL ARM - DISCONTINUED PART
                                        TRACK CONTROL ARM - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                        # 3
                                        MPN: 171407365G
                                        GUIDE JOINT - $ 17 MM
                                        from £65.11
                                        from £65.11
                                        Guide joint - 17 MM $ - D - MJ 1978>> Genuine Porsche Part - New (to order)
                                        # 4
                                        MPN: N 0420011
                                        LOCK RING - A 7
                                        from £1.38
                                        from £1.38
                                        LOCK RING - A 7 Genuine Porsche Part - New (to order)
                                        # 5
                                        MPN: N 0110077
                                        hex. nut - M 7
                                        from £1.59
                                        from £1.59
                                        hex. nut - M 7 Genuine Porsche Part - New (to order)
                                        # 6
                                        MPN: N 0402043
                                        SCREW, HEX. HD. - M 7 X 20
                                        from £2.06
                                        from £2.06
                                        SCREW, HEX. HD. - M 7 X 20 Genuine Porsche Part - New (to order)
                                        # 7
                                        MPN: 171407182D
                                        BONDED RUBBER MOUNTING
                                        from £33.05
                                        from £33.05
                                        BONDED RUBBER MOUNTING Genuine Porsche Part - New (to order)
                                        # 8
                                        MPN: 90002500902
                                        WASHER - A 13
                                        Supersession
                                        Supersession
                                        Genuine Porsche Part (no longer available to order)
                                        # 9
                                        MPN: 90008203902
                                        SCREW, HEX. HD. - M 12 X 1,5 X 100
                                        SCREW, HEX. HD. - M 12 X 1,5 X 100 Genuine Porsche Part - New (to order)
                                        # 10
                                        MPN: N 0211311
                                        HEX. NUT, SELF-LOCKING - M 12 X 1,5
                                        from £1.06
                                        from £1.06
                                        hex. nut, self-locking - VM 12 X 1,5 Genuine Porsche Part - New (to order)
                                        # 11
                                        MPN: 477407181A
                                        RUBBER ISOLATOR - DISCONTINUED PART
                                        RUBBER ISOLATOR - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                        # 11
                                        MPN: 477407181B
                                        RUBBER ISOLATOR
                                        from £77.89
                                        from £77.89
                                        rubber isolator - D - MJ 1979>> Genuine Porsche Part - New (to order)
                                        # 12
                                        MPN: 477407169
                                        CLAMP
                                        from £79.35
                                        from £79.35
                                        CLAMP Genuine Porsche Part - New (to order)
                                        # 13
                                        MPN: 477407425
                                        WASHER
                                        from £9.88
                                        from £9.88
                                        Washer - 30 X 5 Genuine Porsche Part - New (to order)
                                        # 14
                                        MPN: N 0403211
                                        SCREW, HEX. HD. - M 10 X 65
                                        from £2.64
                                        from £2.64
                                        SCREW, HEX. HD. - M 10 X 65 Genuine Porsche Part - New (to order)
                                        # 15
                                        MPN: N 0101831
                                        SCREW, HEX. HD. - M 12 X 75
                                        from £2.45
                                        from £2.45
                                        SCREW, HEX. HD. - M 12 X 75 Genuine Porsche Part - New (to order)
                                        # 16
                                        MPN: 99902507402
                                        WASHER
                                        Washer - See workshop manual - Discontinued part Genuine Porsche Part - New (to order)
                                        # 16
                                        MPN: 99902507401
                                        WASHER
                                        from £9.40
                                        from £9.40
                                        Washer - See workshop manual Genuine Porsche Part - New (to order)
                                        # 17
                                        MPN: N 0104456
                                        SCREW, HEX. HD. - M 10 X 45 - DISCONTINUED PART
                                        screw, hex. hd. - M 10 X 45 X 20 - Discontinued part Genuine Porsche Part - New (to order)
                                        # 17
                                        MPN: 90007437202
                                        SCREW, HEX. HD.
                                        from £1.86
                                        from £1.86
                                        screw, hex. hd. - M 10 X 45 X 20 Genuine Porsche Part - New In stock
                                        # 18
                                        MPN: N 0211302
                                        hex. nut, self-locking - M 10 - Discontinued part
                                        hex. nut, self-locking - VM 10 - Discontinued part Genuine Porsche Part - New (to order)
                                        # 18
                                        MPN: N 0221492
                                        HEX. NUT, SELF-LOCKING - M 10
                                        from £1.78
                                        from £1.78
                                        HEX. NUT, SELF-LOCKING - VM 10 Genuine Porsche Part - New In stock
                                        # 19
                                        MPN: 94434110701
                                        Heat protection plate - D >> - MJ 1984
                                        LHD
                                        from £19.83
                                        from £19.83
                                        Heat protection plate - D >> - MJ 1984 Genuine Porsche Part - New (to order)
                                        # 19
                                        MPN: 95134110802
                                        Heat protection plate - D - MJ 1985>>
                                        LHD
                                        from £51.83
                                        from £51.83
                                        Heat protection plate - D - MJ 1985>> Genuine Porsche Part - New (to order)
                                        # 19
                                        MPN: 94534110701
                                        Heat protection plate - D >> - MJ 1984
                                        RHD
                                        from £21.29
                                        from £21.29
                                        Heat protection plate - D >> - MJ 1984 Genuine Porsche Part - New (to order)
                                        # 19
                                        MPN: 95234110802
                                        Heat protection plate - D - MJ 1985>>
                                        RHD
                                        from £17.45
                                        from £17.45
                                        Heat protection plate - D - MJ 1986>> Genuine Porsche Part - New (to order)
                                        # 20
                                        MPN: N 0115247
                                        WASHER - A 6 - DISCONTINUED PART
                                        Washer - R 6,6 - Discontinued part Genuine Porsche Part - New (to order)
                                        # 20
                                        MPN: N 01152427
                                        WASHER - A 6
                                        from £0.47
                                        from £0.47
                                        Washer - R 6,6 Genuine Porsche Part - New (to order)
                                        WASHER 6.4X12.5X1.6 Genuine Lamborghini - New In stock
                                        # 21
                                        MPN: N 01021513
                                        SCREW, HEX. HD. - M 6 X 15
                                        from £2.09
                                        from £2.09
                                        screw, hex. hd. - M6 X 15 Genuine Porsche Part - New (to order)
