702-000 - Pedals
Porsche 1982 (944) PEDALS Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 477721141
BRAKE PEDAL
from £8.17
from £8.17
# 1
MPN: 477723141
BRAKE PEDAL
(AUT.)
from £9.85
from £9.85
# 2
MPN: 443721153A
BUSHING
from £2.46
from £2.46
# 3
MPN: 823721173
PAD FOR BRAKE AND - BRAKE AND CLUTCH PEDALS
from £5.02
from £5.02
# 3
MPN: 827723173
CAP
(AUT.)
from £4.85
from £4.85
# 4
MPN: 321721191
RETURN SPRING
from £3.79
from £3.79
# 4
MPN: 477721353A
COUPLING SERVO SPRING
# 5
MPN: 803721213
CLEVIS
# 6
MPN: N 0110106
HEX. NUT - M 10 - DISCONTINUED PART
# 6
MPN: N 10155210
hex. nut - M 10
from £0.88
from £0.88
# 7
MPN: 99970318340
JOUNCE BUMPER
# 8
MPN: 843721309
PIN - 12 X 185 X 180
from £29.99
from £29.99
# 8
MPN: N 0231512
BEARING PIN - 12 X 144 X 139
(AUT.)
from £1.68
from £1.68
# 9
MPN: N 0126531
LOCK WASHER
from £3.50
from £3.50
# 10
MPN: N 0234761
LOCKING PIN - 8 X 32
from £1.83
from £1.83
# 11
MPN: 477721315D
CLUTCH PEDAL SWITCH
from £99.08
from £99.08
# 12
MPN: 477721171
CLUTCH MASTER CYLINDER
from £173.14
from £173.14
# 13
MPN: 92842390800
BELLOWS
from £14.11
from £14.11
# 14
MPN: 92842351700
CLEVIS - DISCONTINUED PART
# 14
MPN: 92842351701
CLEVIS
from £10.76
from £10.76
# 15
MPN: 99992400240
BUSHING
from £2.44
from £2.44
# 16
MPN: 90002500809
WASHER - A 10,5 - DISCONTINUED PART
# 16
MPN: 90002500804
Washer - A 10,5
from £0.80
from £0.80
This part replaces part number 90002500802
# 16
MPN: 9000250080E
Washer - A 10,5
Yellow
from £0.62
from £0.62
# 17
MPN: 99916603402
RETAINER PLATE
from £3.54
from £3.54
# 18
MPN: 92842319100
GASKET
from £5.67
from £5.67
# 19
MPN: 90002701502
LOCK RING - B 8
# 19
MPN: 90002701503
LOCK RING - B 8
from £0.86
from £0.86
# 20
MPN: 90007602502
HEX. NUT - M 8 - DISCONTINUED PART
Supersession
Supersession
# 20
MPN: 90007606402
hex. nut - M 8
from £0.59
from £0.59
# -
-
HOSE - 12,5 X 7,5
# 21
-
SHORTEN TO:
220 MM
# 22
MPN: 477721189A
TUBE-/HOSE LINE - DISCONTINUED PART
# 22
MPN: 477721189B
TUBE-/HOSE LINE
from £126.03
from £126.03
# 23
MPN: 94442309100
HYDRAULIC CLUTCH PIPE
from £91.88
from £91.88
# 24
MPN: 99992400140
BUSHING
from £2.04
from £2.04
# 25
MPN: 90002500702
WASHER - A 8,4 - DISCONTINUED PART
# 25
MPN: 90002500703
Washer - A 8,4
from £0.84
from £0.84
# 26
MPN: N 90047001
LOCK WASHER
from £5.10
from £5.10
# 27
MPN: N 90006701
WASHER
from £0.79
from £0.79
# 28
MPN: N 0206801
CLAMP
from £2.75
from £2.75
# 29
MPN: N 0102644
SCREW, HEX. HD. - M 5 X 20
from £1.24
from £1.24
# 30
MPN: 94442319301
BRACKET
from £1.66
from £1.66
# 31
MPN: N 0102076
SCREW, HEX. HD. - M 5 X 12 - DISCONTINUED PART
# 31
MPN: N 01020717
SCREW, HEX. HD. - M 5 X 12
from £0.47
from £0.47
# 32
MPN: N 0122252
SPRING WASHER - B 5
from £0.92
from £0.92
# 33
MPN: N 01100514
HEX. NUT - M 5 - DISCONTINUED PART
# 33
MPN: 90007609101
hex. nut - M 5
from £1.00
from £1.00
# 34
MPN: N 01023911
SCREW, HEX. HD. - M 8 X 18 - DISCONTINUED PART
# 34
MPN: N 01023930
SCREW, HEX. HD. - M 8 X 18
from £1.49
from £1.49
# 35
MPN: 90002500702
Washer - Discontinued part
# 35
MPN: 90002500703
WASHER
from £0.84
from £0.84
# 36
MPN: 311955255
COVER WASHER
