811-005 - LIFTING ROOF - D - MJ 1984>>
Porsche 1982 (944) LIFTING ROOF - D - MJ 1984>> Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 94456402101
ROOF
# 2
MPN: 94456404700
LINING
# 3
MPN: 94462405500
ELECTRIC DRIVE
from £876.95
from £876.95
# 4
MPN: 94462401100
electric motor
from £572.65
from £572.65
# 5
MPN: 94456494100
ASSEMBLY KIT - SEE TPI - GROUP: - 8 - NR. 43
Supersession
Supersession
# 6
MPN: 94456411401
GASKET
from £95.65
from £95.65
# 7
MPN: 477871761
TENSIONING DEVICE
from £2.22
from £2.22
# 8
MPN: 477871789
SEALING STRIP
from £1.43
from £1.43
# 9
MPN: N 0122265
SPRING WASHER - B 6
from £0.70
from £0.70
# 10
MPN: 477871763A
THREADED BUSHING
from £4.60
from £4.60
# 11
MPN: 477871217
ROOF COVER
FRONT
from £96.81
from £96.81
# 12
MPN: 477871219
BRACKET
from £1.97
from £1.97
# 13
MPN: N 0331741
SCREW, CSK. HD. - M 3 X 6 - DISCONTINUED PART
# 13
MPN: 90026900101
SCREW, CSK. HD. - M 3 X 6
from £1.24
from £1.24
# 14
MPN: 477871665A
CENTRAL RETAINER
FRONT
# 15
MPN: N 0139644
TAPPING SCREW, FILL. HD. - B 4,2 X 16
Supersession
Supersession
# 16
MPN: N 0330181
SCREW, CSK. - M 5 X 12
from £0.60
from £0.60
# 17
MPN: 99970460507
CONE WASHER
from £0.82
from £0.82
# 18
MPN: 94456462100
PROTECTIVE EDGING - DISCONTINUED PART
# 18
MPN: 94456462302
PROTECTIVE EDGING
from £11.73
from £11.73
# 19
MPN: 477871053
RIVET
from £1.24
from £1.24
# 20
MPN: 311867167
TAPPING SCREW, FILL. HD.
from £0.88
from £0.88
# 21
MPN: 90015102802
Washer - Discontinued part
Supersession
Supersession
# 21
MPN: 90015102801
WASHER
from £1.64
from £1.64
This part replaces part number 90015102802
# 22
MPN: 311867169
CAP FOR SCREW
# 23
MPN: 94456409300
WIND DEFLECTOR
# 24
MPN: 94456468300
MOUNTING
# 25
MPN: N 0139644
tapping screw, fill. hd. - 4,2 X 16
Supersession
Supersession
# 26
MPN: 94456468500
flap
from £1.43
from £1.43
# 27
MPN: 94456422300
ATTACHMENT ELEMENT
center
# 28
MPN: 94456422400
ADJUSTING SCREW
from £4.97
from £4.97
# 29
MPN: N 0122224
spring washer - A 5
# 30
MPN: N 0141338
fillister hd. screw - M 5 X 12 - Discontinued part
# 30
MPN: N 014133I
fillister hd. screw - M 5 X 12
from £1.70
from £1.70
# 31
MPN: 94456423300
CAP
# 31
MPN: 91455223310
INSERT
# 32
MPN: 477871635A
HINGE
LEFT
from £15.92
from £15.92
# 32
MPN: 477871636A
HINGE
RIGHT
from £15.92
from £15.92
# 33
MPN: 477837959
FILL. HD. SELF-LOCKING SCREW
from £0.88
from £0.88
# 34
MPN: 477871701A
CAP NUT
from £3.97
from £3.97
# 35
MPN: 90014303102
TAPPING SCREW, FILL. HD. - B 4,2 X 9,5
from £0.82
from £0.82
# 36
MPN: 94456423500
WATER DRAIN HOSE
LEFT REAR
from £3.96
from £3.96
# 36
MPN: 94456406400
WATER DRAIN HOSE
RIGHT REAR
from £23.94
from £23.94
# 37
MPN: 94456423700
WATER DRAIN PIPE
LEFT REAR
# 37
MPN: 94456423800
WATER DRAIN PIPE
RIGHT REAR
# 38
MPN: 021119569
RUBBER GROMMET
from £9.88
from £9.88
# 39
MPN: 321877233C
WATER DRAIN HOSE
FRONT
# 40
MPN: 477871027
BAG
# 41
MPN: 94456416100
GUIDE
LEFT REAR
Supersession
Supersession
# 41
MPN: 94456416200
GUIDE
RIGHT REAR
# 41
MPN: 94456416202
GUIDE
RIGHT REAR
from £46.30
from £46.30
# 42
MPN: N 0141338
fillister hd. screw - M 5 X 12 - Discontinued part
# 42
MPN: N 014133I
fillister hd. screw - M 5 X 12
from £1.70
from £1.70
# 43
MPN: N 0142644
FILLISTER HD. SCREW - AM 5 X 10
from £0.60
from £0.60
# 44
MPN: 94461303300
MICRO SWITCH
from £48.98
from £48.98
# 45
MPN: 94461312700
MICRO SWITCH
from £11.18
from £11.18
# 46
MPN: N 10071801
SCREW, CHEESE HD. - M 5 X 70
# 47
MPN: 90002500302
Washer - A 5,3
# 48
MPN: N 0121042
SERRATED WASHER - 5,3
from £0.47
from £0.47
# 49
MPN: N 01100514
HEX. NUT - M 5 - DISCONTINUED PART
# 49
MPN: 90007609101
hex. nut - M 5
from £1.00
from £1.00
# 50
MPN: 99921800502
SCREW, CHEESE HD. - M 6 - DISCONTINUED PART
# 50
MPN: 99921800501
SCREW, CHEESE HD. - M 6
from £1.51
from £1.51
# 51
MPN: N 0115247
WASHER - A 6,4 - DISCONTINUED PART
# 51
MPN: N 01152427
Washer - A 6,4
from £0.47
from £0.47
# 52
MPN: 431951253D
CONTACT CLOSE RELAY - DISCONTINUED PART
from £40.05
from £40.05
# 52
MPN: 99965701690
RELAY
from £12.92
from £12.92
# 53
MPN: 94456452100
BRACKET
from £3.97
from £3.97
# 54
MPN: N 0139675
tapping screw - BZ 4,2 X 19
# 55
MPN: 94462441500
SPACER BUSHING
from £1.66
from £1.66
# 56
MPN: 94462441700
RUBBER GROMMET
from £1.20
from £1.20
# 57
MPN: N 90257701
SPEED NUT - B 4,2
from £0.47
from £0.47
# 58
MPN: 94456443300
BRACKET
from £8.60
from £8.60
# 59
MPN: N 0138844
tapping screw,hex.hd. - BZ 4,8 X 13
# 60
MPN: N 0122012
WASHER - 5,5
# 61
MPN: 99959172202
SPEED NUT - B 4,8 X 19
# 62
MPN: 94456451700
COVER
from £3.97
from £3.97
# 63
MPN: 94456442501
CARRIER
from £5.61
from £5.61
# 64
MPN: 94456442700
CLAMPING SLEEVE
# 65
MPN: 94456443700
PINION
from £45.28
from £45.28
# 66
MPN: 90011600302
lock washer - Discontinued part
# 66
MPN: 90011600309
LOCK WASHER
from £1.27
from £1.27
# 67
MPN: N 0147452
BOLT, WITH HEX. SOCKET - HD. - M 6 X 14 - MICRO-SELF-LOCKING
# 68
MPN: 94455644100
FELT STRIP
from £6.62
from £6.62
-part-diagram-812-000.webp "PORSCHE 1982 (944) SEAT BELT PARTS DIAGRAM")
-part-diagram-812-005.webp "PORSCHE 1982 (944) SEAT BELT PARTS DIAGRAM")
-part-diagram-813-000.webp "PORSCHE 1982 (944) HEATER - VENTILATION - HEATER CORE PARTS DIAGRAM")
-part-diagram-813-005.webp "PORSCHE 1982 (944) AIR VENT - TRIM - AIR HOSE PARTS DIAGRAM")
-part-diagram-813-010.webp "PORSCHE 1982 (944) AIR CONDITIONER PARTS DIAGRAM")
-part-diagram-813-015.webp "PORSCHE 1982 (944) VACUUM CONTROL PARTS DIAGRAM")
-part-diagram-813-020.webp "PORSCHE 1982 (944) AIR CONDITIONER PARTS DIAGRAM")
-part-diagram-813-025.webp "PORSCHE 1982 (944) AIR CONDITIONER PARTS DIAGRAM")
-part-diagram-813-030.webp "PORSCHE 1982 (944) COMPRESSOR PARTS DIAGRAM")
-part-diagram-901-000.webp "PORSCHE 1982 (944) ENGINE ELECTRICS 1 PARTS DIAGRAM")
-part-diagram-901-005.webp "PORSCHE 1982 (944) ENGINE ELECTRICS 2 PARTS DIAGRAM")
-part-diagram-902-000.webp "PORSCHE 1982 (944) ALTERNATOR - WITH: - FASTENERS PARTS DIAGRAM")
-part-diagram-902-010.webp "PORSCHE 1982 (944) STARTER - BATTERY - WIRING HARNESSES PARTS DIAGRAM")
-part-diagram-902-020.webp "PORSCHE 1982 (944) WIRING HARNESSES - ENGINE COMPARTMENT - - DME - - HEADLIGHT WASHER SYSTEM PARTS DIAGRAM")
-part-diagram-902-025.webp "PORSCHE 1982 (944) WIRING HARNESSES - DASHBOARD - CENTER CONSOLE PARTS DIAGRAM")
-part-diagram-902-030.webp "PORSCHE 1982 (944) WIRING HARNESSES - REAR END PARTS DIAGRAM")
-part-diagram-902-035.webp "PORSCHE 1982 (944) PUSH-ON CONNECTOR PARTS DIAGRAM")
-part-diagram-903-000.webp "PORSCHE 1982 (944) SWITCH - FUSE BOX - RELAY PARTS DIAGRAM")
-part-diagram-903-005.webp "PORSCHE 1982 (944) STEERING LOCK HOUSING - STEERING COLUMN SWITCH PARTS DIAGRAM")
-part-diagram-903-010.webp "PORSCHE 1982 (944) HORN PARTS DIAGRAM")
-part-diagram-904-000.webp "PORSCHE 1982 (944) WINDSCREEN WIPER SYSTEM PARTS DIAGRAM")
-part-diagram-904-005.webp "PORSCHE 1982 (944) REAR WINDOW WIPER PARTS DIAGRAM")
-part-diagram-904-010.webp "PORSCHE 1982 (944) WINDSHIELD WASHER UNIT PARTS DIAGRAM")
-part-diagram-904-015.webp "PORSCHE 1982 (944) HEADLIGHT WASHER SYSTEM PARTS DIAGRAM")
-part-diagram-905-000.webp "PORSCHE 1982 (944) HEADLAMP - ELECTRIC MOTOR - POP-UP HEADLIGHT PARTS DIAGRAM")
-part-diagram-905-006.webp "PORSCHE 1982 (944) FOG LIGHTS PARTS DIAGRAM")
-part-diagram-905-010.webp "PORSCHE 1982 (944) TURN SIGNAL PARTS DIAGRAM")
-part-diagram-905-015.webp "PORSCHE 1982 (944) LICENSE PLATE LIGHT - REAR LIGHT PARTS DIAGRAM")
-part-diagram-905-020.webp "PORSCHE 1982 (944) INTERIOR LIGHT - TURN SIGNAL REPEATER PARTS DIAGRAM")
-part-diagram-906-000.webp "PORSCHE 1982 (944) INSTRUMENTS PARTS DIAGRAM")
-part-diagram-906-005.webp "PORSCHE 1982 (944) SPEEDOMETER PARTS DIAGRAM")
-part-diagram-907-000.webp "PORSCHE 1982 (944) CRUISE CONTROL SYSTEM PARTS DIAGRAM")
-part-diagram-909-000.webp "PORSCHE 1982 (944) ALARM SYSTEM PARTS DIAGRAM")
-part-diagram-910-000.webp "PORSCHE 1982 (944) ELECTRIC FAN PARTS DIAGRAM")
-part-diagram-001-000.webp "PORSCHE 1982 (944) ACCESSORIES PARTS DIAGRAM")
-part-diagram-001-003.webp "PORSCHE 1982 (944) CLEANING AGENT - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-001-004.webp "PORSCHE 1982 (944) INSTRUCTION MANUAL - CARE PASS PARTS DIAGRAM")
-part-diagram-001-005.webp "PORSCHE 1982 (944) SIGNS/NOTICES PARTS DIAGRAM")
-part-diagram-001-007.webp "PORSCHE 1982 (944) IDENTIFICATION PLATE PARTS DIAGRAM")
-part-diagram-001-010.webp "PORSCHE 1982 (944) ACCESSORIES - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-001-015.webp "PORSCHE 1982 (944) FLOOR MAT PARTS DIAGRAM")
-part-diagram-002-000.webp "PORSCHE 1982 (944) ACCESSORIES PARTS DIAGRAM")
-part-diagram-002-006.webp "PORSCHE 1982 (944) ROOF TRANSPORT SYSTEM PARTS DIAGRAM")
-part-diagram-002-007.webp "PORSCHE 1982 (944) ROOF TRANSPORT SYSTEM PARTS DIAGRAM")
-part-diagram-002-010.webp "PORSCHE 1982 (944) ACCESSORIES PARTS DIAGRAM")
-part-diagram-003-000.webp "PORSCHE 1982 (944) RADIO UNIT - WITH: - 3 - LOUDSPEAKER - F >> 94-CN403 921 - F >> 94-DN400 108 PARTS DIAGRAM")
-part-diagram-003-005.webp "PORSCHE 1982 (944) RADIO UNIT - WITH: - 4 - LOUDSPEAKER - F 94-CN400 111>> - F 94-DN400 109>> PARTS DIAGRAM")
-part-diagram-004-000.webp "PORSCHE 1982 (944) LACQUERS - BASIC MATERIALS PARTS DIAGRAM")
-part-diagram-101-000.webp "PORSCHE 1982 (944) REPLACEMENT ENGINE PARTS DIAGRAM")
-part-diagram-101-005.webp "PORSCHE 1982 (944) SHORT ENGINE - CRANKCASE - PROTECTIVE PLATE F. ENGINE PARTS DIAGRAM")
-part-diagram-101-010.webp "PORSCHE 1982 (944) CRANKCASE PARTS DIAGRAM")
-part-diagram-102-000.webp "PORSCHE 1982 (944) CRANKSHAFT - CONNECTING ROD PARTS DIAGRAM")
-part-diagram-102-005.webp "PORSCHE 1982 (944) PISTON - PISTON RINGS PARTS DIAGRAM")
-part-diagram-103-000.webp "PORSCHE 1982 (944) CYLINDER HEAD - VALVES PARTS DIAGRAM")
-part-diagram-103-005.webp "PORSCHE 1982 (944) CAMSHAFT HOUSING - CAMSHAFT PARTS DIAGRAM")
-part-diagram-103-010.webp "PORSCHE 1982 (944) DRIVING MECHANISM - CAMSHAFT PARTS DIAGRAM")
-part-diagram-103-015.webp "PORSCHE 1982 (944) DRIVING MECHANISM - SHAFT PARTS DIAGRAM")
-part-diagram-104-000.webp "PORSCHE 1982 (944) ENGINE LUBRICATION - ATTENTION - TECHNICAL INFORMATION - GRUPPE 1 - NR. 6/84 PARTS DIAGRAM")
-part-diagram-105-000.webp "PORSCHE 1982 (944) WATER PUMP PARTS DIAGRAM")
-part-diagram-105-005.webp "PORSCHE 1982 (944) WATER COOLING PARTS DIAGRAM")
-part-diagram-106-000.webp "PORSCHE 1982 (944) AIR CLEANER SYSTEM PARTS DIAGRAM")
-part-diagram-107-000.webp "PORSCHE 1982 (944) L-JETRONIC - 1 PARTS DIAGRAM")
-part-diagram-107-005.webp "PORSCHE 1982 (944) L-JETRONIC - 2 PARTS DIAGRAM")
-part-diagram-107-010.webp "PORSCHE 1982 (944) L-JETRONIC - 3 PARTS DIAGRAM")
-part-diagram-109-000.webp "PORSCHE 1982 (944) ENGINE SUSPENSION PARTS DIAGRAM")
-part-diagram-198-000.webp "PORSCHE 1982 (944) MAINTENANCE SET - GASKET SET - REPAIR KIT PARTS DIAGRAM")
-part-diagram-198-005.webp "PORSCHE 1982 (944) ENGINE OIL - PORSCHE CLASSIC 10W50 PARTS DIAGRAM")
-part-diagram-201-000.webp "PORSCHE 1982 (944) FUEL TANK PARTS DIAGRAM")
-part-diagram-201-005.webp "PORSCHE 1982 (944) EVAPORATIVE EMISSION CANISTER - TANK VENTILATION - (AUS)(J) PARTS DIAGRAM")
-part-diagram-201-010.webp "PORSCHE 1982 (944) FUEL SYSTEM PARTS DIAGRAM")
-part-diagram-202-000.webp "PORSCHE 1982 (944) EXHAUST SYSTEM - EXHAUST SILENCER, FRONT PARTS DIAGRAM")
-part-diagram-202-005.webp "PORSCHE 1982 (944) EXHAUST SYSTEM - CATALYST - (J) PARTS DIAGRAM")
-part-diagram-202-010.webp "PORSCHE 1982 (944) EXHAUST SYSTEM - EXHAUST SILENCER, REAR PARTS DIAGRAM")
-part-diagram-298-005.webp "PORSCHE 1982 (944) PORSCHE CLASSIC - ADDITIVE - FOR FUEL PARTS DIAGRAM")
-part-diagram-301-000.webp "PORSCHE 1982 (944) CENTRAL TUBE - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-301-005.webp "PORSCHE 1982 (944) CLUTCH PARTS DIAGRAM")
-part-diagram-302-000.webp "PORSCHE 1982 (944) REPLACEMENT TRANSMISSION - TRANSMISSION CASE - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-303-000.webp "PORSCHE 1982 (944) GEARS AND SHAFTS - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-304-000.webp "PORSCHE 1982 (944) SHIFT RODS - SHIFT FORKS PARTS DIAGRAM")
-part-diagram-305-000.webp "PORSCHE 1982 (944) DIFFERENTIAL - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-305-005.webp "PORSCHE 1982 (944) LIMITED SLIP DIFFERENTIAL - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-306-000.webp "PORSCHE 1982 (944) TRANSMISSION SUSPENSION - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-307-000.webp "PORSCHE 1982 (944) CENTRAL TUBE - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-308-000.webp "PORSCHE 1982 (944) REPLACEMENT TRANSMISSION - FINAL DRIVE HOUSING - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-309-000.webp "PORSCHE 1982 (944) TRANSMISSION CASE - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-309-005.webp "PORSCHE 1982 (944) OIL INLET - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-309-010.webp "PORSCHE 1982 (944) GEAR OIL COOLER - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-310-000.webp "PORSCHE 1982 (944) TRANSMISSION PARTS - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-310-005.webp "PORSCHE 1982 (944) VALVE BODY - GOVERNOR - OIL STRAINER - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-311-000.webp "PORSCHE 1982 (944) DIFFERENTIAL - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-312-000.webp "PORSCHE 1982 (944) TRANSMISSION SUSPENSION - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-401-000.webp "PORSCHE 1982 (944) TRACK CONTROL ARM - CROSS MEMBER PARTS DIAGRAM")
-part-diagram-401-005.webp "PORSCHE 1982 (944) STEERING KNUCKLE - LUBRICANTS PARTS DIAGRAM")
-part-diagram-402-000.webp "PORSCHE 1982 (944) SUSPENSION - SHOCK ABSORBER PARTS DIAGRAM")
-part-diagram-402-005.webp "PORSCHE 1982 (944) STABILIZER PARTS DIAGRAM")
-part-diagram-403-000.webp "PORSCHE 1982 (944) STEERING GEAR - STEERING TRACK ROD PARTS DIAGRAM")
-part-diagram-403-002.webp "PORSCHE 1982 (944) POWER STEERING - STEERING GEAR - POWER STEERING PUMP - LINES PARTS DIAGRAM")
-part-diagram-403-005.webp "PORSCHE 1982 (944) STEERING WHEEL - STEERING COLUMN PARTS DIAGRAM")
-part-diagram-404-000.webp "PORSCHE 1982 (944) SPORTS SUSPENSION PARTS DIAGRAM")
-part-diagram-501-000.webp "PORSCHE 1982 (944) REAR AXLE CARRIER - TRAILING ARM PARTS DIAGRAM")
-part-diagram-501-005.webp "PORSCHE 1982 (944) REAR WHEEL SHAFT - LUBRICANTS PARTS DIAGRAM")
-part-diagram-501-010.webp "PORSCHE 1982 (944) DRIVE SHAFT PARTS DIAGRAM")
-part-diagram-502-000.webp "PORSCHE 1982 (944) VIBRATION DAMPER - STABILIZER PARTS DIAGRAM")
-part-diagram-601-000.webp "PORSCHE 1982 (944) DISC WHEEL PARTS DIAGRAM")
-part-diagram-602-000.webp "PORSCHE 1982 (944) DISC BRAKES - FRONT AXLE PARTS DIAGRAM")
-part-diagram-603-000.webp "PORSCHE 1982 (944) DISC BRAKES - REAR AXLE PARTS DIAGRAM")
-part-diagram-604-000.webp "PORSCHE 1982 (944) BRAKE MASTER CYLINDER - BRAKE BOOSTER - RESERVOIR PARTS DIAGRAM")
-part-diagram-604-005.webp "PORSCHE 1982 (944) BRAKE LINES PARTS DIAGRAM")
-part-diagram-698-005.webp "PORSCHE 1982 (944) BRAKE FLUID - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-701-000.webp "PORSCHE 1982 (944) SHIFT MECHANISM - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-701-005.webp "PORSCHE 1982 (944) SHIFT MECHANISM - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-701-010.webp "PORSCHE 1982 (944) HAND BRAKE LEVER PARTS DIAGRAM")
-part-diagram-702-000.webp "PORSCHE 1982 (944) PEDALS PARTS DIAGRAM")
-part-diagram-702-005.webp "PORSCHE 1982 (944) PEDALS PARTS DIAGRAM")
-part-diagram-702-010.webp "PORSCHE 1982 (944) ACCELERATOR PEDAL - ACCELERATOR CABLE - FOR VEHICLES WITH - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-702-015.webp "PORSCHE 1982 (944) ACCELERATOR PEDAL - ACCELERATOR CABLE - FOR VEHICLES WITH - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-801-000.webp "PORSCHE 1982 (944) CAR BODY - PRIMED - SEALED - WITH: - UNDERBODY PROTECTION - BODYSHELLS CAN ONLY - ONLY AVAILABLE FROM CURRENT - MODEL YEAR AVAILABLE PARTS DIAGRAM")
-part-diagram-801-010.webp "PORSCHE 1982 (944) BODY FRONT SECTION PARTS DIAGRAM")
-part-diagram-801-015.webp "PORSCHE 1982 (944) SIDE PANEL PARTS DIAGRAM")
-part-diagram-801-025.webp "PORSCHE 1982 (944) FENDER PARTS DIAGRAM")
-part-diagram-802-000.webp "PORSCHE 1982 (944) BUMPER - WITHOUT: - BUFFER PARTS DIAGRAM")
-part-diagram-802-005.webp "PORSCHE 1982 (944) BUMPER - WITH: - BUFFER PARTS DIAGRAM")
-part-diagram-802-010.webp "PORSCHE 1982 (944) FRONT SPOILER PARTS DIAGRAM")
-part-diagram-803-000.webp "PORSCHE 1982 (944) COVER - OPERATING MECHANISM - LID LOCK PARTS DIAGRAM")
-part-diagram-803-005.webp "PORSCHE 1982 (944) REAR TRUNK LID - WITH: - REAR WINDOW GLASS - REAR SPOILER PARTS DIAGRAM")
-part-diagram-803-010.webp "PORSCHE 1982 (944) REAR TRUNK LID - WITH: - REAR WINDOW GLASS - WITHOUT: - REAR SPOILER PARTS DIAGRAM")
-part-diagram-804-000.webp "PORSCHE 1982 (944) DOOR PARTS DIAGRAM")
-part-diagram-804-005.webp "PORSCHE 1982 (944) INSTALLATION PARTS - DOOR - DOOR LATCH PARTS DIAGRAM")
-part-diagram-804-010.webp "PORSCHE 1982 (944) INSTALLATION PARTS - DOOR WINDOW - WINDOW REGULATOR PARTS DIAGRAM")
-part-diagram-805-000.webp "PORSCHE 1982 (944) WINDOW GLAZING PARTS DIAGRAM")
-part-diagram-806-000.webp "PORSCHE 1982 (944) POP-UP HEADLIGHT PARTS DIAGRAM")
-part-diagram-807-000.webp "PORSCHE 1982 (944) SOUND ABSORBER PARTS DIAGRAM")
-part-diagram-807-005.webp "PORSCHE 1982 (944) TRIMS PARTS DIAGRAM")
-part-diagram-807-010.webp "PORSCHE 1982 (944) DOOR PANEL - ROOF TRIM PANEL PARTS DIAGRAM")
-part-diagram-808-000.webp "PORSCHE 1982 (944) FRONT SEAT - COMPLETE - SEAT COVER PARTS DIAGRAM")
-part-diagram-808-001.webp "PORSCHE 1982 (944) FRONT SEAT - SINGLE PARTS PARTS DIAGRAM")
-part-diagram-808-005.webp "PORSCHE 1982 (944) SPORTS SEAT - COMPLETE PARTS DIAGRAM")
-part-diagram-808-010.webp "PORSCHE 1982 (944) SPORTS SEAT - BACKREST - SINGLE PARTS PARTS DIAGRAM")
-part-diagram-808-015.webp "PORSCHE 1982 (944) SPORTS SEAT - SEAT CUSHION - SINGLE PARTS PARTS DIAGRAM")
-part-diagram-808-020.webp "PORSCHE 1982 (944) EMERGENCY SEAT - COMPLETE PARTS DIAGRAM")
-part-diagram-808-025.webp "PORSCHE 1982 (944) EMERGENCY SEAT - SINGLE PARTS PARTS DIAGRAM")
-part-diagram-809-000.webp "PORSCHE 1982 (944) DASHBOARD PARTS DIAGRAM")
-part-diagram-809-001.webp "PORSCHE 1982 (944) CASSETTE HOLDER PARTS DIAGRAM")
-part-diagram-809-005.webp "PORSCHE 1982 (944) REAR VIEW MIRROR INNER - REAR VIEW MIRROR - SUN VIZOR PARTS DIAGRAM")
-part-diagram-809-010.webp "PORSCHE 1982 (944) LUGGAGE COMPARTMENT COVER PARTS DIAGRAM")
-part-diagram-810-000.webp "PORSCHE 1982 (944) DECORATIVE FRAME PARTS DIAGRAM")
-part-diagram-810-005.webp "PORSCHE 1982 (944) NAMEPLATES - STONE PROTECTION FOIL PARTS DIAGRAM")
-part-diagram-811-000.webp "PORSCHE 1982 (944) LIFTING ROOF - D >> - MJ 1983 PARTS DIAGRAM")
