porsche 1982 (944) headlamp - electric motor - pop-up headlight parts diagram

905-000 - HEADLAMP - ELECTRIC MOTOR - POP-UP HEADLIGHT

Porsche 1982 (944) HEADLAMP - ELECTRIC MOTOR - POP-UP HEADLIGHT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                            #
                                            Part number
                                            Description
                                            Key
                                            Price
                                            # 2
                                            MPN: 321941133
                                            ADJUSTING PIECE
                                            from £5.27
                                            from £5.27
                                            adjusting piece - D >> - MJ 1987 Genuine Porsche Part - New (to order)
                                            # 3
                                            MPN: 321941135
                                            RETAINER PLATE - FOR - ADJUSTING PIECE
                                            from £4.26
                                            from £4.26
                                            retainer plate - for - adjusting piece - D >> - MJ 1987 Genuine Porsche Part - New In stock
                                            # 4
                                            MPN: 113941141
                                            ADJUSTING SCREW - WITH: - THREADED PIECE
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 6
                                            MPN: 111941160
                                            RETAINING RING FOR BULB
                                            (\\J..\\)
                                            RETAINING RING FOR BULB Genuine Porsche Part - New (to order)
                                            # 7
                                            MPN: 477941311
                                            REFLECTOR
                                            LEFT
                                            REFLECTOR Genuine Porsche Part - New (to order)
                                            # 7
                                            MPN: 477941311A
                                            REFLECTOR
                                            RIGHT
                                            REFLECTOR Genuine Porsche Part - New (to order)
                                            # 8
                                            MPN: 90063112690
                                            HALOGEN BULB - H 3
                                            from £22.70
                                            from £22.70
                                            halogen bulb - YC 12 V 55 W Genuine Porsche Part - New (to order)
                                            # 9
                                            MPN: 90063110390
                                            BULB - 12 V 4 W
                                            from £3.22
                                            from £3.22
                                            bulb - HL 12V, 4W Genuine Porsche Part - New (to order)
                                            # 10
                                            MPN: 94463140700
                                            ADDITIONAL HEADLIGHT - WITH: - RETAINING FRAME
                                            LEFT
                                            from £245.06
                                            from £245.06
                                            Additional headlight - white - D - MJ 1987>> Genuine Porsche Part - New (to order)
                                            # 10
                                            MPN: 94463140900
                                            ADDITIONAL HEADLIGHT - YELLOW - WITH: - RETAINING FRAME
                                            left (\\F..\\)
                                            from £245.06
                                            from £245.06
                                            Additional headlight - yellow - D - MJ 1987>> Genuine Porsche Part - New (to order)
                                            # 10
                                            MPN: 94463140800
                                            ADDITIONAL HEADLIGHT - WITH: - RETAINING FRAME
                                            RIGHT
                                            from £245.06
                                            from £245.06
                                            Additional headlight - white - D - MJ 1987>> Genuine Porsche Part - New (to order)
                                            # 10
                                            MPN: 94463141000
                                            ADDITIONAL HEADLIGHT - YELLOW - WITH: - RETAINING FRAME
                                            right (\\F..\\)
                                            from £245.06
                                            from £245.06
                                            Additional headlight - yellow - D - MJ 1987>> Genuine Porsche Part - New (to order)
                                            # 11
                                            MPN: N 0141228
                                            fillister hd. screw - M 4 X 8
                                            from £1.25
                                            from £1.25
                                            fillister hd. screw - M 4 X 8 Genuine Porsche Part - New (to order)
                                            # 11
                                            MPN: N 01412217
                                            fillister hd. screw - M 4 X 8
                                            from £0.89
                                            from £0.89
                                            FILLISTER HD. SCREW - M4 X 8 Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 90014605307
                                            FILLISTER HD. SCREW - AM 4 X 18
                                            from £1.49
                                            from £1.49
                                            FILLISTER HD. SCREW - M 4 X 18 - D >>- MJ 1986 Genuine Porsche Part - New (to order)
                                            # 13
                                            MPN: 477941379B
                                            ELECTRIC MOTOR - POP-UP HEADLIGHT
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 14
                                            MPN: 477941386
                                            PROTECTIVE CAP
                                            LOWER
                                            from £26.09
                                            from £26.09
                                            PROTECTIVE CAP Genuine Porsche Part - New (to order)
                                            # 15
                                            MPN: 477941387
                                            PROTECTIVE CAP
                                            UPPER
                                            from £20.87
                                            from £20.87
                                            PROTECTIVE CAP Genuine Porsche Part - New (to order)
                                            # 16
                                            MPN: 99908404902
                                            LOCK NUT
                                            from £1.04
                                            from £1.04
                                            LOCK NUT - M 8 Genuine Porsche Part - New (to order)
                                            # 17
                                            MPN: 99907200509
                                            HEX. NUT - M 6 X 12 - DISCONTINUED PART
                                            hex. nut - M6X12 - Discontinued part Genuine Porsche Part - New (to order)
                                            # 17
                                            MPN: 99907200501
                                            SCREW, HEX. HD. - M 6 X 12
                                            from £2.58
                                            from £2.58
                                            screw, hex. hd. - M6X12 Genuine Porsche Part - New In stock
                                            # 18
                                            MPN: N 0120072
                                            LOCK RING - B 6 - DISCONTINUED PART
                                            lock ring - M 6 - Discontinued part Genuine Porsche Part - New (to order)
                                            # 18
                                            MPN: 90002700403
                                            LOCK RING - B 6
                                            from £0.63
                                            from £0.63
                                            lock ring - M 6 Genuine Porsche Part - New In stock
                                            # 19
                                            MPN: 477941659A
                                            CAP - HEADLAMP UNIT
                                            from £24.03
                                            from £24.03
                                            CAP - HEADLAMP UNIT Genuine Porsche Part - New (to order)
                                            # 20
                                            MPN: 477941715
                                            GASKET
                                            from £14.98
                                            from £14.98
                                            gasket - D - MJ 1986>> - MJ 1986 Genuine Porsche Part - New (to order)
                                            # 21
                                            MPN: 477941751D
                                            HIGH-BEAM HEADLIGHT - WHITE
                                            LEFT
                                            High-beam headlight - white - D >> - MJ 1986 Genuine Porsche Part - New (to order)
                                            # 21
                                            MPN: 94463140900
                                            ADDITIONAL HEADLIGHT - YELLOW
                                            left (\\F..\\)
                                            from £245.06
                                            from £245.06
                                            Additional headlight - yellow - D - MJ 1987>> Genuine Porsche Part - New (to order)
                                            # 21
                                            MPN: 477941752D
                                            HIGH-BEAM HEADLIGHT - WHITE
                                            RIGHT
                                            High-beam headlight - white - D >> - MJ 1986 Genuine Porsche Part - New (to order)
                                            # 21
                                            MPN: 94463141000
                                            ADDITIONAL HEADLIGHT - YELLOW
                                            right (\\F..\\)
                                            from £245.06
                                            from £245.06
                                            Additional headlight - yellow - D - MJ 1987>> Genuine Porsche Part - New (to order)
                                            # 22
                                            MPN: 477941771B
                                            headlamp
                                            from £122.11
                                            from £122.11
                                            headlamp - D >> - MJ 1987 Genuine Porsche Part - New (to order)
                                            # 22
                                            MPN: 477941773
                                            headlamp
                                            (PR:492)
                                            from £181.31
                                            from £181.31
                                            headlamp - D >> - MJ 1987 Genuine Porsche Part - New (to order)
                                            # 22
                                            MPN: 477941775C
                                            headlamp
                                            (\\J..\\)
                                            from £123.95
                                            from £123.95
                                            headlamp - D >> - MJ 1986 Genuine Porsche Part - New (to order)
                                            # 23
                                            MPN: 111941341
                                            FLAT CONTACT HOUSING
                                            3 PIN
                                            from £1.78
                                            from £1.78
                                            flat contact housing - 6,3 Genuine Porsche Part - New (to order)
                                            # 25
                                            MPN: 111971986
                                            FLAT CONNECTOR WITH - RETAINING LUG - 6,3 X 0,8
                                            from £0.72
                                            from £0.72
                                            FLAT CONNECTOR WITH - RETAINING LUG - 6,3 X 2,5 Genuine Porsche Part - New (to order)
                                            # 26
                                            MPN: 90063110990
                                            BULB - 12 V 45/50 W
                                            (\\J..\\)
                                            from £3.59
                                            from £3.59
                                            bulb - headlamp - 12 V - 45 / 40 W Genuine Porsche Part - New (to order)
                                            # 27
                                            MPN: 99963120290
                                            BULB - H 4
                                            from £21.16
                                            from £21.16
                                            bulb - YD 12 V 60/55 W Genuine Porsche Part - New (to order)
                                            # 27
                                            MPN: 99963120291
                                            HALOGEN BULB - H 4
                                            (\\F..\\)
                                            halogen bulb - yellow Genuine Porsche Part - New (to order)
                                            # 28
                                            MPN: 90014304100
                                            TAPPING SCREW, FILL. HD. - B 3,9 X 19
                                            from £1.51
                                            from £1.51
                                            TAPPING SCREW, FILL. HD. - B 3,9 X 19 Genuine Porsche Part - New In stock
                                            # 30
                                            MPN: 477941543
                                            SPACER SLEEVE
                                            from £6.54
                                            from £6.54
                                            SPACER SLEEVE Genuine Porsche Part - New (to order)
                                            # 31
                                            MPN: 477857173
                                            CLIP
                                            from £2.29
                                            from £2.29
                                            CLIP Genuine Porsche Part - New (to order)
                                            # 32
                                            MPN: N 0439792
                                            tapping screw - BZ 4,2 X 45
                                            from £1.78
                                            from £1.78
                                            tapping screw - BZ 4,2 X 45 Genuine Porsche Part - New (to order)
