porsche 1986 (944) seat belt - lap belt - manually parts diagram

812-005 - seat belt - lap belt - manually

Porsche 1986 (944) SEAT BELT - LAP BELT - MANUALLY Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                  #
                                                  Part number
                                                  Description
                                                  Key
                                                  Price
                                                  # 2
                                                  MPN: 477857739A
                                                  PRESS BUTTON BUCKLE - DISCONTINUED PART
                                                  PRESS BUTTON BUCKLE - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                  # 2
                                                  MPN: 477857739B
                                                  PRESS BUTTON BUCKLE
                                                  press button buckle - D - MJ 1980>> Genuine Porsche Part - New (to order)
                                                  # 3
                                                  MPN: 803019811B
                                                  SCREW, HEX. HD. - D - MJ 1985>> - MJ 1985
                                                  from £11.78
                                                  from £11.78
                                                  screw, hex. hd. - Discontinued part Genuine Porsche Part - New (to order)
                                                  # 3
                                                  MPN: 111857793E
                                                  SCREW, HEX. HD. - D - MJ 1986>> - MJ 1986
                                                  from £7.74
                                                  from £7.74
                                                  SCREW, HEX. HD. - FOR - STANDARD TYPE LOCK - D >>- MJ 1984 Genuine Porsche Part - New In stock
                                                  # 4
                                                  MPN: 211857771
                                                  WASHER
                                                  from £1.77
                                                  from £1.77
                                                  Washer - for - flexible lock - Movable Genuine Porsche Part - New (to order)
                                                  # 5
                                                  MPN: 92880325902
                                                  SPACER BUSHING
                                                  from £2.29
                                                  from £2.29
                                                  spacer bushing - for - press button buckle - Movable Genuine Porsche Part - New (to order)
                                                  # 7
                                                  MPN: 477857643
                                                  SPACER SLEEVE - DISCONTINUED PART
                                                  SPACER SLEEVE - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                  # 7
                                                  MPN: 99920903302
                                                  SPACER SLEEVE
                                                  from £4.10
                                                  from £4.10
                                                  SPACER SLEEVE Genuine Porsche Part - New (to order)
                                                  # 8
                                                  MPN: 811857845
                                                  CAP
                                                  from £2.54
                                                  from £2.54
                                                  Genuine Porsche Part (no longer available to order)
                                                  SCREW HEAD CAP Genuine Lamborghini - New In stock
                                                  # 10
                                                  MPN: 90015102702
                                                  WASHER - B 5,3 X 15
                                                  Washer - F 92-A0411 806>> - F 93-A0140 314>> - Discontinued part Genuine Porsche Part - New (to order)
                                                  # 10
                                                  MPN: 90015102703
                                                  WASHER - B 5,3 X 15
                                                  from £0.65
                                                  from £0.65
                                                  Washer - F 92-A0411 806>> - F 93-A0140 314>> Genuine Porsche Part - New (to order)
                                                  # 11
                                                  MPN: 90014600302
                                                  fillister hd. screw - M 5 X 11
                                                  FILLISTER HD. SCREW - M5 X 10 Genuine Porsche Part - New (to order)
                                                  # -
                                                  -
                                                  THREE-POINT SEAT BELT WITH - INERTIA REEL
                                                  (PR:335)
                                                  # 12
                                                  MPN: 94580302101
                                                  three-point seat belt
                                                  LEFT
                                                  three-point seat belt - Automatic Genuine Porsche Part - New (to order)
                                                  # 12
                                                  MPN: 94580302201
                                                  THREE-POINT SEAT BELT WITH - INERTIA REEL
                                                  RIGHT
                                                  THREE-POINT SEAT BELT WITH - INERTIA REEL Genuine Porsche Part - New (to order)
                                                  # 13
                                                  MPN: 92880315102
                                                  CLIP - UPPER PART
                                                  from £4.02
                                                  from £4.02
                                                  Clip - Upper part - D - MJ 1990>> Genuine Porsche Part - New (to order)
                                                  # 14
                                                  MPN: 92880315302
                                                  CLIP - LOWER PART
                                                  from £4.02
                                                  from £4.02
                                                  Clip - Lower part - D - MJ 1990>> Genuine Porsche Part - New (to order)
                                                  # 15
                                                  MPN: 94480314100
                                                  COVER FOR - 3-POINT SEAT BELT
                                                  Cover for - 3-point seat belt - D - MJ 1986>> Genuine Porsche Part - New (to order)
                                                  # 16
                                                  MPN: 111857793E
                                                  SCREW, HEX. HD.
                                                  from £7.74
                                                  from £7.74
                                                  SCREW, HEX. HD. - FOR - STANDARD TYPE LOCK - D >>- MJ 1984 Genuine Porsche Part - New In stock
                                                  # 17
                                                  MPN: 94580331100
                                                  SPACER RING
                                                  from £10.38
                                                  from £10.38
                                                  SPACER RING Genuine Porsche Part - New (to order)
                                                  # 18
                                                  MPN: 811857845
                                                  CAP
                                                  from £2.54
                                                  from £2.54
                                                  Genuine Porsche Part (no longer available to order)
                                                  SCREW HEAD CAP Genuine Lamborghini - New In stock
                                                  # 19
                                                  MPN: 803019811B
                                                  SCREW, HEX. HD.
                                                  from £11.78
                                                  from £11.78
                                                  screw, hex. hd. - Discontinued part Genuine Porsche Part - New (to order)
                                                  # 20
                                                  MPN: 211857771
                                                  WASHER
                                                  from £1.77
                                                  from £1.77
                                                  Washer - for - flexible lock - Movable Genuine Porsche Part - New (to order)
                                                  # 21
                                                  MPN: 92880325902
                                                  SPACER BUSHING
                                                  from £2.29
                                                  from £2.29
                                                  spacer bushing - for - press button buckle - Movable Genuine Porsche Part - New (to order)
                                                  # 22
                                                  MPN: 477857739A
                                                  PRESS BUTTON BUCKLE - DISCONTINUED PART
                                                  PRESS BUTTON BUCKLE - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                  # 22
                                                  MPN: 477857739B
                                                  PRESS BUTTON BUCKLE
                                                  press button buckle - D - MJ 1980>> Genuine Porsche Part - New (to order)
                                                  # 24
                                                  MPN: 477857643
                                                  SPACER SLEEVE - DISCONTINUED PART
                                                  SPACER SLEEVE - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                  # 24
                                                  MPN: 99920903302
                                                  SPACER SLEEVE
                                                  from £4.10
                                                  from £4.10
                                                  SPACER SLEEVE Genuine Porsche Part - New (to order)
                                                  # 25
                                                  MPN: 91180315000
                                                  SCREW
                                                  Supersession
                                                  Supersession
                                                  Genuine Porsche Part (no longer available to order)
