porsche 1989 (944) evaporative emission canister parts diagram

201-005 - EVAPORATIVE EMISSION CANISTER

Porsche 1989 (944) EVAPORATIVE EMISSION CANISTER Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                #
                                                                Part number
                                                                Description
                                                                Key
                                                                Price
                                                                # 1
                                                                MPN: 92820101406
                                                                EVAPORATIVE EMISSION CANISTER
                                                                EVAPORATIVE EMISSION CANISTER Genuine Porsche Part - New (to order)
                                                                # 2
                                                                MPN: 477201279
                                                                SLEEVE
                                                                from £10.40
                                                                from £10.40
                                                                SLEEVE Genuine Porsche Part - New (to order)
                                                                # 4
                                                                MPN: N 0154491
                                                                SPEED NUT
                                                                from £0.93
                                                                from £0.93
                                                                SPEED NUT - B 6,3 Genuine Porsche Part - New (to order)
                                                                # 5
                                                                MPN: N 0901721
                                                                TAPPING SCREW, HEX. HD.(COMBI) - B 6,3 X 19
                                                                from £1.04
                                                                from £1.04
                                                                TAPPING SCREW, HEX. HD.(COMBI) - B6,3 X 19 Genuine Porsche Part - New (to order)
                                                                # 5
                                                                MPN: N 0901726
                                                                BOLT WITH WASHER - B 6,3 X 19
                                                                from £1.42
                                                                from £1.42
                                                                Bolt with washer - B 6,3 X 19 Z2 Genuine Porsche Part - New (to order)
                                                                # 6
                                                                MPN: 321201890A
                                                                end piece - 6,5 X 450
                                                                end piece - 6,5 X 450 Genuine Porsche Part - New (to order)
                                                                # 7
                                                                MPN: N 0235692
                                                                HOSE CLAMP - DISCONTINUED PART
                                                                Hose Clamp - S16/9ZY - Discontinued part Genuine Porsche Part - New (to order)
                                                                # 7
                                                                MPN: PCG0235692
                                                                HOSE CLAMP
                                                                from £2.11
                                                                from £2.11
                                                                Hose Clamp - S16/9ZY Genuine Porsche Part - New (to order)
                                                                # 8
                                                                MPN: 94420173700
                                                                breather line
                                                                from £36.16
                                                                from £36.16
                                                                breather line Genuine Porsche Part - New (to order)
                                                                # 9
                                                                MPN: 99918135340
                                                                HOSE
                                                                HOSE Genuine Porsche Part - New (to order)
                                                                # 10
                                                                MPN: 021119569A
                                                                RUBBER GROMMET
                                                                from £6.59
                                                                from £6.59
                                                                RUBBER GROMMET Genuine Porsche Part - New (to order)
                                                                # 11
                                                                MPN: 99951255400
                                                                HOSE CLAMP - 12 - 22
                                                                from £2.68
                                                                from £2.68
                                                                This part replaces part number 90027200302
                                                                Hose Clamp - SGT 12-22/9 Genuine Porsche Part - New In stock
                                                                # 12
                                                                MPN: 99951216002
                                                                Hose Clamp - S 13/9 - Discontinued part
                                                                Hose Clamp - SM 13/9 - Discontinued part Genuine Porsche Part - New (to order)
                                                                # 12
                                                                MPN: PCG51216002
                                                                Hose Clamp - S 13/9
                                                                Supersession
                                                                Supersession
                                                                Genuine Porsche Part (no longer available to order)
                                                                # 14
                                                                MPN: 99918135240
                                                                HOSE
                                                                from £12.86
                                                                from £12.86
                                                                HOSE Genuine Porsche Part - New (to order)
                                                                # 15
                                                                MPN: 92811042908
                                                                vacuum valve
                                                                from £23.79
                                                                from £23.79
                                                                vacuum valve Genuine Porsche Part - New (to order)
                                                                # 16
                                                                MPN: 94411018202
                                                                HOSE
                                                                (944/TURBO)
                                                                from £18.05
                                                                from £18.05
                                                                HOSE Genuine Porsche Part - New (to order)
                                                                # 16
                                                                MPN: 94411018204
                                                                MOLDED HOSE
                                                                (944S2)
                                                                from £11.96
                                                                from £11.96
                                                                MOLDED HOSE Genuine Porsche Part - New (to order)
                                                                # 17
                                                                MPN: 94411042900
                                                                CONTROL VALVE
                                                                (944/TURBO)
                                                                from £520.61
                                                                from £520.61
                                                                CONTROL VALVE Genuine Porsche Part - New (to order)
                                                                # 17
                                                                MPN: 94460524001
                                                                Bleed valve
                                                                (944S2)
                                                                Bleed valve Genuine Porsche Part - New (to order)
                                                                # 18
                                                                MPN: 94411036600
                                                                RETAINING BRACKET
                                                                from £13.34
                                                                from £13.34
                                                                RETAINING BRACKET Genuine Porsche Part - New (to order)
                                                                # 20
                                                                MPN: 92857372702
                                                                DISTRIBUTOR PIECE
                                                                from £10.85
                                                                from £10.85
                                                                DISTRIBUTOR PIECE Genuine Porsche Part - New (to order)
                                                                # 21
                                                                MPN: 058131851A
                                                                THERMO-PNEUMATIC VALVE
                                                                from £32.46
                                                                from £32.46
                                                                THERMO-PNEUMATIC VALVE Genuine Porsche Part - New (to order)
                                                                # -
                                                                -
                                                                FUEL HOSE - 7,5 X 13,5
                                                                # 22
                                                                -
                                                                SHORTEN TO:
                                                                730 MM (944)
                                                                # 22
                                                                -
                                                                SHORTEN TO:
                                                                600 MM (TURBO)
                                                                # 22
                                                                MPN: 94411018000
                                                                MOLDED HOSE
                                                                (944S2)
                                                                MOLDED HOSE Genuine Porsche Part - New (to order)
                                                                # -
                                                                -
                                                                TUBE IN COILS OF 5M - 'ORDER QTY. 5' - 4 X 1
                                                                # 23
                                                                -
                                                                SHORTEN TO:
                                                                850 MM
                                                                # 24
                                                                -
                                                                SHORTEN TO:
                                                                580 MM
                                                                # 25
                                                                -
                                                                SHORTEN TO:
                                                                480 MM
                                                                # 26
                                                                MPN: 94420177300
                                                                HOSE - DISCONTINUED PART
                                                                HOSE - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                                # 26
                                                                MPN: 94420177301
                                                                HOSE
                                                                from £6.45
                                                                from £6.45
                                                                HOSE Genuine Porsche Part - New (to order)
                                                                # 27
                                                                MPN: 94420115300
                                                                VENT TUBE
                                                                VENT TUBE Genuine Porsche Part - New (to order)
                                                                # 28
                                                                MPN: 94420177500
                                                                HOSE
                                                                from £23.44
                                                                from £23.44
                                                                HOSE Genuine Porsche Part - New (to order)
                                                                # 29
                                                                MPN: 477201743E
                                                                TUBE
                                                                from £36.89
                                                                from £36.89
                                                                TUBE Genuine Porsche Part - New (to order)
                                                                # 30
                                                                MPN: 94420115901
                                                                VENT HOSE
                                                                from £43.93
                                                                from £43.93
                                                                vent hose - to fit use workshop material Genuine Porsche Part - New (to order)
                                                                # 31
                                                                MPN: 92820108302
                                                                SHUT-OFF VALVE
                                                                from £34.08
                                                                from £34.08
                                                                SHUT-OFF VALVE Genuine Porsche Part - New (to order)
                                                                # 32
                                                                MPN: 99959171540
                                                                cable holder - Discontinued part
                                                                cable holder - Discontinued part Genuine Porsche Part - New (to order)
                                                                # 32
                                                                MPN: 9995917154A
                                                                CABLE HOLDER
                                                                from £2.18
                                                                from £2.18
                                                                CABLE HOLDER Genuine Porsche Part - New (to order)
                                                                # -
                                                                -
                                                                fasteners
                                                                # 33
                                                                MPN: 99950705440
                                                                CABLE HOLDER
                                                                from £1.47
                                                                from £1.47
                                                                CABLE HOLDER Genuine Porsche Part - New (to order)
                                                                # 34
                                                                MPN: 99951120040
                                                                CLAMP
                                                                CLAMP Genuine Porsche Part - New (to order)
                                                                # 35
                                                                MPN: 99904900840
                                                                PLASTIC NUT
                                                                from £1.06
                                                                from £1.06
                                                                PLASTIC NUT - T5/16 X 10 Genuine Porsche Part - New In stock
                                                                # 36
                                                                MPN: 431971848A
                                                                CLIP
                                                                from £1.47
                                                                from £1.47
                                                                CLIP Genuine Porsche Part - New (to order)
