302-000 - REPLACEMENT TRANSMISSION - TRANSMISSION CASE - FOR - MANUAL GEARBOX
Porsche 1991 (944) REPLACEMENT TRANSMISSION - TRANSMISSION CASE - FOR - MANUAL GEARBOX Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# -
MPN: 016300049S
5 SPEED MANUAL TRANSMISSION
(ASG)
# -
MPN: 016300049T
5 SPEED MANUAL TRANSMISSION
(ASH)
# -
MPN: 016300049TX
5 SPEED MANUAL TRANSMISSION - WITH: - LIMITED SLIP DIFFERENTIAL
(ASH)
# -
MPN: 016300049P
5 SPEED MANUAL TRANSMISSION
(AOS)
# -
MPN: 016300049Q
5 SPEED MANUAL TRANSMISSION - WITH: - LIMITED SLIP DIFFERENTIAL
(AOT)
# -
MPN: 016300050D
5 SPEED MANUAL TRANSMISSION
(ASV \\CH.\\)
# -
MPN: 016300050E
5 SPEED MANUAL TRANSMISSION - WITH TRANSFER BOX AND TORSEN - DIFFERENTIAL - WITH: - LIMITED SLIP DIFFERENTIAL
(ASW \\CH.\\)
# -
MPN: 016300049R
5 SPEED MANUAL TRANSMISSION - WITH: - LIMITED SLIP DIFFERENTIAL
(AOR)
# -
MPN: 94438502500
CAPSULE
left (\\CH.\\)
from £212.46
from £212.46
# -
MPN: 94438502600
CAPSULE
right (\\CH.\\)
from £212.46
from £212.46
# -
MPN: 99959185202
CLAMP
(\\CH.\\)
# 1
MPN: 016301103BF
TRANSMISSION CASE
(ASG ASH)
from £265.53
from £265.53
# 1
MPN: 016301103AH
TRANSMISSION CASE
(AOR AOS AOT ASV ASW)
from £930.15
from £930.15
# 2
MPN: 111301127E
threaded plug - M 24 X 1,5 - Discontinued part
# 2
MPN: WHT001937
THREADED PLUG - M 24 X 1,5
from £6.88
from £6.88
# 3
MPN: 016301211M
END PLATE
(ASG ASH)
from £256.79
from £256.79
# 3
MPN: 016301211N
TRANSMISSION COVER
(AOR AOS AOT ASV ASW)
from £355.03
from £355.03
# 4
MPN: 014301473
sleeve - Discontinued part
# 4
MPN: 0A2301473
SLEEVE
from £5.33
from £5.33
# 5
MPN: N 0103324
SCREW, HEX. HD. - M 8 X 32
from £2.48
from £2.48
# 6
MPN: 016301231F
COVER
(ASG ASH AOS AOT ASV ASW 944/S/S2)
from £209.91
from £209.91
# 6
MPN: 016301231AA
COVER - ALSO USE: - 2X 019.301.115
(AOR TURBO)
from £209.91
from £209.91
# 7
MPN: 016301299
sleeve - Discontinued part
# 7
MPN: 016301299A
SLEEVE
from £2.29
from £2.29
# 8
MPN: 016301235C
GASKET
from £5.08
from £5.08
# 9
MPN: 084301143A
SHAPED MAGNET
from £5.26
from £5.26
# 10
MPN: N 0147151
bolt, with hex. socket - hd. - M 8 X 45
from £1.22
from £1.22
# 11
MPN: 90002500702
WASHER - 8,4 - DISCONTINUED PART
# 11
MPN: 90002500703
WASHER - 8,4
from £0.84
from £0.84
# 12
MPN: 088301467B
SEALING CAP - DISCONTINUED PART
(ASG ASH)
# 12
MPN: 088301467D
SEALING CAP - DISCONTINUED PART
(ASG ASH)
# 12
MPN: 0143014672
TRANSMISSION COVER
(ASG ASH)
from £31.28
from £31.28
# 12
MPN: 016301467
SEALING CAP
(AOR AOS AOT ASV ASW)
from £70.27
from £70.27
# 13
MPN: N 0133711
DOWEL PIN - 6 M 6 X 24
from £1.13
from £1.13
# 14
MPN: 019301115
SEALING CAP
from £1.04
from £1.04
# 15
MPN: 083311123
NEEDLE SLEEVE
# 16
MPN: 014301473
sleeve - Discontinued part
# 16
MPN: 0A2301473
SLEEVE
from £5.33
from £5.33
# 17
MPN: 014301485
CAP FOR TRANSMISSION BREATHER
from £3.36
from £3.36
# 18
MPN: 084941521
SWITCH
from £21.85
from £21.85
# 19
MPN: 477599181A
PROTECTIVE PLATE
from £10.97
from £10.97
# 20
MPN: 016301455A
GASKET
from £2.79
from £2.79
# 21
MPN: 016301453B
COVER FOR GEARSHIFT ROD
from £7.80
from £7.80
# 22
MPN: 92830312001
SEAL
from £10.03
from £10.03
# 25
MPN: 90007505702
SCREW, HEX. HD. - M 6 X 16
Supersession
Supersession
# 25
MPN: 90007505703
SCREW, HEX. HD. - M 6 X 16 - NO LONGER USE THE PART HERE
from £3.27
from £3.27
# 26
MPN: N 0122265
SPRING WASHER - B 6
from £0.70
from £0.70
# 31
MPN: 016311113C
RADIAL SHAFT SEAL
from £11.30
from £11.30
# 32
MPN: N 0901942
SCREW, HEX. HD. - M 7 X 16
# 33
MPN: 90006726802
SCREW, CHEESE HD. - M 12 X 80
from £8.34
from £8.34
# 34
MPN: 90002801402
SPRING WASHER - B 12 - DISCONTINUED PART
# 34
MPN: 90002801403
SPRING WASHER - B 12
from £1.32
from £1.32
# 35
MPN: N 0110208
HEX. NUT - M 12 - DISCONTINUED PART
# 35
MPN: 90003403601
hex. nut - M 12
from £1.64
from £1.64
# 37
MPN: 90002500902
WASHER - A 13
Supersession
Supersession
# 38
MPN: 90007406402
SCREW, HEX. HD. - M 10 X 60
# 38
MPN: 90007437701
SCREW, HEX. HD. - M 10 X 60
from £1.93
from £1.93
# 39
MPN: 90002500809
WASHER - A 10,5 - DISCONTINUED PART
# 39
MPN: 90002500804
Washer - A 10,5
from £0.80
from £0.80
This part replaces part number 90002500802
# 39
MPN: 9000250080E
Washer - A 10,5
Yellow
from £0.62
from £0.62
# 40
MPN: N 0122306
SPRING WASHER - B 10
# 41
MPN: N 01101013
hex. nut - M 10
from £1.48
from £1.48
# 42
MPN: N 0901911
BOLT, HEX. HD. (COMBI.) - M 8 X 35
from £5.08
from £5.08
# 43
MPN: 088409131C
COVER FOR FINAL DRIVE
(ASG ASH)
from £181.09
from £181.09
# 43
MPN: 016409131B
COVER FOR FINAL DRIVE
(AOR AOS AOT ASV ASW)
from £362.84
from £362.84
# 45
MPN: N 0132911
SPRING PIN - 4 X 28
from £0.54
from £0.54
# 46
MPN: 019301153
SLEEVE
from £23.64
from £23.64
# 47
MPN: 016301349
COVER PLATE
from £5.08
from £5.08
# 49
MPN: 088311123
NEEDLE SLEEVE
(ASG ASH)
from £14.69
from £14.69
# 49
MPN: 016311123B
NEEDLE SLEEVE
(AOR AOS AOT ASV ASW)
from £126.90
from £126.90
-part-diagram-302-010.webp "PORSCHE 1991 (944) OIL COOLING PARTS DIAGRAM")
-part-diagram-303-000.webp "PORSCHE 1991 (944) GEARS AND SHAFTS - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-303-005.webp "PORSCHE 1991 (944) GEARS AND SHAFTS - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-304-000.webp "PORSCHE 1991 (944) TRANSMISSION CONTROL - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-304-005.webp "PORSCHE 1991 (944) TRANSMISSION CONTROL - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-305-000.webp "PORSCHE 1991 (944) DIFFERENTIAL - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-305-005.webp "PORSCHE 1991 (944) LIMITED SLIP DIFFERENTIAL - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-306-000.webp "PORSCHE 1991 (944) TRANSMISSION SUSPENSION - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-307-000.webp "PORSCHE 1991 (944) CENTRAL TUBE - FOR - AUTOMATIC TRANSMISSION - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-308-000.webp "PORSCHE 1991 (944) REPLACEMENT TRANSMISSION - FINAL DRIVE HOUSING - FOR - AUTOMATIC TRANSMISSION - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-309-000.webp "PORSCHE 1991 (944) TRANSMISSION CASE - FOR - AUTOMATIC TRANSMISSION - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-309-005.webp "PORSCHE 1991 (944) OIL INLET - FOR - AUTOMATIC TRANSMISSION - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-309-010.webp "PORSCHE 1991 (944) OIL COOLING - FOR - AUTOMATIC TRANSMISSION - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-310-000.webp "PORSCHE 1991 (944) TRANSMISSION CONTROL - FOR - AUTOMATIC TRANSMISSION - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-310-005.webp "PORSCHE 1991 (944) VALVE BODY - OIL STRAINER - GOVERNOR - FOR - AUTOMATIC TRANSMISSION - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-311-000.webp "PORSCHE 1991 (944) DIFFERENTIAL - FOR - AUTOMATIC TRANSMISSION - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-312-000.webp "PORSCHE 1991 (944) TRANSMISSION SUSPENSION - FOR - AUTOMATIC TRANSMISSION - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-401-000.webp "PORSCHE 1991 (944) TRACK CONTROL ARM - CROSS MEMBER PARTS DIAGRAM")
-part-diagram-401-005.webp "PORSCHE 1991 (944) STEERING KNUCKLE - LUBRICANTS PARTS DIAGRAM")
-part-diagram-402-000.webp "PORSCHE 1991 (944) SUSPENSION - SHOCK ABSORBER PARTS DIAGRAM")
-part-diagram-402-005.webp "PORSCHE 1991 (944) STABILIZER PARTS DIAGRAM")
-part-diagram-403-000.webp "PORSCHE 1991 (944) POWER STEERING - STEERING GEAR - STEERING TRACK ROD PARTS DIAGRAM")
-part-diagram-403-002.webp "PORSCHE 1991 (944) POWER STEERING - POWER STEERING PUMP - LINES PARTS DIAGRAM")
-part-diagram-403-005.webp "PORSCHE 1991 (944) STEERING WHEEL - STEERING COLUMN - STEERING LOCK PARTS DIAGRAM")
-part-diagram-403-006.webp "PORSCHE 1991 (944) AIRBAG - FOR PARTS DIAGRAM")
-part-diagram-501-000.webp "PORSCHE 1991 (944) REAR AXLE CARRIER - REAR AXLE STEERING PARTS DIAGRAM")
-part-diagram-501-005.webp "PORSCHE 1991 (944) REAR WHEEL SHAFT - LUBRICANTS PARTS DIAGRAM")
-part-diagram-501-010.webp "PORSCHE 1991 (944) DRIVE SHAFT PARTS DIAGRAM")
-part-diagram-502-000.webp "PORSCHE 1991 (944) VIBRATION DAMPER - STABILIZER PARTS DIAGRAM")
-part-diagram-601-000.webp "PORSCHE 1991 (944) DISC WHEEL PARTS DIAGRAM")
-part-diagram-602-000.webp "PORSCHE 1991 (944) DISC BRAKES - FRONT AXLE - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-602-001.webp "PORSCHE 1991 (944) DISC BRAKES - FRONT AXLE PARTS DIAGRAM")
-part-diagram-603-000.webp "PORSCHE 1991 (944) DISC BRAKES - REAR AXLE - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-603-001.webp "PORSCHE 1991 (944) DISC BRAKES - REAR AXLE PARTS DIAGRAM")
-part-diagram-603-004.webp "PORSCHE 1991 (944) HANDBRAKE PARTS DIAGRAM")
-part-diagram-604-000.webp "PORSCHE 1991 (944) BRAKE MASTER CYLINDER - BRAKE BOOSTER - RESERVOIR - D >> - MJ 1990 PARTS DIAGRAM")
-part-diagram-604-001.webp "PORSCHE 1991 (944) BRAKE MASTER CYLINDER - BRAKE BOOSTER - RESERVOIR - ANTI-LOCKING BRAKE SYST. -ABS- PARTS DIAGRAM")
-part-diagram-604-005.webp "PORSCHE 1991 (944) BRAKE LINES PARTS DIAGRAM")
-part-diagram-605-000.webp "PORSCHE 1991 (944) BRAKE LINES - ANTI-LOCKING BRAKE SYST. -ABS- PARTS DIAGRAM")
-part-diagram-605-002.webp "PORSCHE 1991 (944) HYDRAULIC UNIT - ANTI-LOCKING BRAKE SYST. -ABS- PARTS DIAGRAM")
-part-diagram-698-005.webp "PORSCHE 1991 (944) BRAKE FLUID - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-701-000.webp "PORSCHE 1991 (944) ACTUATOR - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-701-005.webp "PORSCHE 1991 (944) ACTUATOR - FOR - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-701-010.webp "PORSCHE 1991 (944) HAND BRAKE LEVER PARTS DIAGRAM")
-part-diagram-702-000.webp "PORSCHE 1991 (944) BRAKE - CLUTCH - PEDALS PARTS DIAGRAM")
-part-diagram-702-005.webp "PORSCHE 1991 (944) BRAKE - CLUTCH - PEDALS PARTS DIAGRAM")
-part-diagram-702-010.webp "PORSCHE 1991 (944) ACCELERATOR PEDAL - ACCELERATOR CABLE - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-702-015.webp "PORSCHE 1991 (944) ACCELERATOR PEDAL - ACCELERATOR CABLE - FOR - AUTOMATIC TRANSMISSION PARTS DIAGRAM")
-part-diagram-801-000.webp "PORSCHE 1991 (944) CAR BODY PARTS DIAGRAM")
-part-diagram-801-007.webp "PORSCHE 1991 (944) FLOOR PAN - REINFORCEMENT PARTS DIAGRAM")
-part-diagram-801-010.webp "PORSCHE 1991 (944) BODY FRONT SECTION PARTS DIAGRAM")
-part-diagram-801-015.webp "PORSCHE 1991 (944) SIDE PANEL PARTS DIAGRAM")
-part-diagram-801-017.webp "PORSCHE 1991 (944) SIDE PANEL - WINDSHIELD FRAME - END PLATE PARTS DIAGRAM")
-part-diagram-801-025.webp "PORSCHE 1991 (944) FENDER PARTS DIAGRAM")
-part-diagram-802-000.webp "PORSCHE 1991 (944) BUMPER - WITHOUT: - BUFFER PARTS DIAGRAM")
-part-diagram-802-005.webp "PORSCHE 1991 (944) BUMPER - WITH: - BUFFER PARTS DIAGRAM")
-part-diagram-802-010.webp "PORSCHE 1991 (944) FRONT SPOILER - D >> - MJ 1989 PARTS DIAGRAM")
-part-diagram-802-015.webp "PORSCHE 1991 (944) COVER FOR BUMPER - BUMPER PARTS DIAGRAM")
-part-diagram-802-020.webp "PORSCHE 1991 (944) SIDE MEMBER TRIM - WINGED REAR APRON PARTS DIAGRAM")
-part-diagram-802-025.webp "PORSCHE 1991 (944) TRIMS PARTS DIAGRAM")
-part-diagram-803-000.webp "PORSCHE 1991 (944) COVER - ACTUATOR PARTS DIAGRAM")
-part-diagram-803-005.webp "PORSCHE 1991 (944) REAR TRUNK LID - REAR SPOILER - D >> - MJ 1990 PARTS DIAGRAM")
-part-diagram-803-007.webp "PORSCHE 1991 (944) REAR TRUNK LID - REAR SPOILER - D - MJ 1990>> PARTS DIAGRAM")
-part-diagram-803-010.webp "PORSCHE 1991 (944) REAR TRUNK LID PARTS DIAGRAM")
-part-diagram-804-000.webp "PORSCHE 1991 (944) DOOR PARTS DIAGRAM")
-part-diagram-804-005.webp "PORSCHE 1991 (944) DOOR HANDLE, OUTER - DOOR LATCH PARTS DIAGRAM")
-part-diagram-804-006.webp "PORSCHE 1991 (944) CENTRAL LOCKING SYSTEM PARTS DIAGRAM")
-part-diagram-804-010.webp "PORSCHE 1991 (944) WINDOW REGULATOR - GLASS CHANNEL PARTS DIAGRAM")
-part-diagram-804-015.webp "PORSCHE 1991 (944) WINDOW REGULATOR - GLASS CHANNEL PARTS DIAGRAM")
-part-diagram-805-000.webp "PORSCHE 1991 (944) WINDOW GLAZING PARTS DIAGRAM")
-part-diagram-806-000.webp "PORSCHE 1991 (944) POP-UP HEADLIGHT PARTS DIAGRAM")
-part-diagram-807-000.webp "PORSCHE 1991 (944) SOUND ABSORBER PARTS DIAGRAM")
-part-diagram-807-005.webp "PORSCHE 1991 (944) TRIMS PARTS DIAGRAM")
-part-diagram-807-010.webp "PORSCHE 1991 (944) DOOR PANEL - ROOF TRIM PANEL PARTS DIAGRAM")
-part-diagram-807-015.webp "PORSCHE 1991 (944) TRIMS PARTS DIAGRAM")
-part-diagram-808-000.webp "PORSCHE 1991 (944) SEAT - COMPLETE PARTS DIAGRAM")
-part-diagram-809-000.webp "PORSCHE 1991 (944) DASH PANEL TRIM PARTS DIAGRAM")
-part-diagram-809-001.webp "PORSCHE 1991 (944) CASSETTE HOLDER - CENTER CONSOLE PARTS DIAGRAM")
-part-diagram-809-005.webp "PORSCHE 1991 (944) SUN VIZOR - REAR VIEW MIRROR - REAR VIEW MIRROR INNER PARTS DIAGRAM")
-part-diagram-809-010.webp "PORSCHE 1991 (944) LUGGAGE COMPARTMENT COVER PARTS DIAGRAM")
-part-diagram-810-000.webp "PORSCHE 1991 (944) DECORATIVE MOULDING PARTS DIAGRAM")
-part-diagram-810-005.webp "PORSCHE 1991 (944) NAMEPLATES - STONE PROTECTION FOIL PARTS DIAGRAM")
-part-diagram-811-000.webp "PORSCHE 1991 (944) LIFTING ROOF PARTS DIAGRAM")
-part-diagram-811-005.webp "PORSCHE 1991 (944) LIFTING ROOF - DRIVING MECHANISM PARTS DIAGRAM")
-part-diagram-811-010.webp "PORSCHE 1991 (944) CONVERTIBLE TOP - CONVERTIBLE TOP COVERING PARTS DIAGRAM")
-part-diagram-811-020.webp "PORSCHE 1991 (944) TOP FRAME PARTS DIAGRAM")
-part-diagram-811-025.webp "PORSCHE 1991 (944) SEAL STRIP PARTS DIAGRAM")
-part-diagram-811-030.webp "PORSCHE 1991 (944) CONVERTIBLE TOP CONTROL - ELECTRIC PARTS DIAGRAM")
-part-diagram-811-035.webp "PORSCHE 1991 (944) BOOT COVER PARTS DIAGRAM")
-part-diagram-812-000.webp "PORSCHE 1991 (944) SEAT BELT PARTS DIAGRAM")
-part-diagram-812-005.webp "PORSCHE 1991 (944) SEAT BELT PARTS DIAGRAM")
-part-diagram-813-000.webp "PORSCHE 1991 (944) HEATER - AIR CONDITIONER PARTS DIAGRAM")
-part-diagram-813-005.webp "PORSCHE 1991 (944) FAN PARTS DIAGRAM")
-part-diagram-813-010.webp "PORSCHE 1991 (944) AIR DUCT PARTS DIAGRAM")
-part-diagram-813-015.webp "PORSCHE 1991 (944) REFRIGERANT CIRCUIT PARTS DIAGRAM")
-part-diagram-813-020.webp "PORSCHE 1991 (944) COMPRESSOR PARTS DIAGRAM")
-part-diagram-813-025.webp "PORSCHE 1991 (944) VACUUM CONTROL PARTS DIAGRAM")
-part-diagram-813-030.webp "PORSCHE 1991 (944) CONTROL SWITCH PARTS DIAGRAM")
-part-diagram-901-000.webp "PORSCHE 1991 (944) ENGINE ELECTRICS 1 PARTS DIAGRAM")
-part-diagram-901-001.webp "PORSCHE 1991 (944) ENGINE ELECTRICS 1 PARTS DIAGRAM")
-part-diagram-901-005.webp "PORSCHE 1991 (944) ENGINE ELECTRICS 2 PARTS DIAGRAM")
-part-diagram-902-000.webp "PORSCHE 1991 (944) ALTERNATOR - WITH: - FASTENERS PARTS DIAGRAM")
-part-diagram-902-010.webp "PORSCHE 1991 (944) BATTERY - STARTER - WIRING HARNESSES PARTS DIAGRAM")
-part-diagram-902-020.webp "PORSCHE 1991 (944) WIRING HARNESSES - ENGINE - HEATER - AIR CONDITIONER PARTS DIAGRAM")
-part-diagram-902-025.webp "PORSCHE 1991 (944) WIRING HARNESSES - PASSENGER COMPARTMENT PARTS DIAGRAM")
-part-diagram-902-026.webp "PORSCHE 1991 (944) WIRING HARNESSES - PASSENGER COMPARTMENT PARTS DIAGRAM")
-part-diagram-902-027.webp "PORSCHE 1991 (944) WIRING HARNESSES - DOORS PARTS DIAGRAM")
-part-diagram-902-030.webp "PORSCHE 1991 (944) WIRING HARNESSES - REAR END PARTS DIAGRAM")
-part-diagram-902-031.webp "PORSCHE 1991 (944) WIRING HARNESSES - ANTI-LOCKING BRAKE SYST. -ABS- - BRAKE PAD WEAR INDICATOR PARTS DIAGRAM")
-part-diagram-902-050.webp "PORSCHE 1991 (944) PIN (MALE) TERMINAL - CONTACT PIN - CABLE SHOE PARTS DIAGRAM")
-part-diagram-902-052.webp "PORSCHE 1991 (944) MALE BLADE TERMINAL - PUSH-ON CONNECTOR PARTS DIAGRAM")
-part-diagram-902-054.webp "PORSCHE 1991 (944) BUTT CONNECTOR - CONNECTOR HOUSING - SINGLE POLE PARTS DIAGRAM")
-part-diagram-902-056.webp "PORSCHE 1991 (944) CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-902-058.webp "PORSCHE 1991 (944) CONNECTOR HOUSING - 3-POLE PARTS DIAGRAM")
-part-diagram-902-060.webp "PORSCHE 1991 (944) CONNECTOR HOUSING - 4-POLE PARTS DIAGRAM")
-part-diagram-902-062.webp "PORSCHE 1991 (944) CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-902-064.webp "PORSCHE 1991 (944) CONNECTOR HOUSING - 8-POLE - 9-POLE PARTS DIAGRAM")
-part-diagram-902-066.webp "PORSCHE 1991 (944) CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-903-000.webp "PORSCHE 1991 (944) SWITCH - CLOCK PARTS DIAGRAM")
-part-diagram-903-002.webp "PORSCHE 1991 (944) STEERING COLUMN SWITCH PARTS DIAGRAM")
-part-diagram-903-005.webp "PORSCHE 1991 (944) FUSE BOX/RELAY PLATE PARTS DIAGRAM")
-part-diagram-903-006.webp "PORSCHE 1991 (944) RELAY - FOR - CONVERTIBLE TOP CONTROL PARTS DIAGRAM")
-part-diagram-903-010.webp "PORSCHE 1991 (944) HORN PARTS DIAGRAM")
-part-diagram-904-000.webp "PORSCHE 1991 (944) WINDSCREEN WIPER SYSTEM PARTS DIAGRAM")
-part-diagram-904-005.webp "PORSCHE 1991 (944) REAR WINDOW WIPER PARTS DIAGRAM")
-part-diagram-904-010.webp "PORSCHE 1991 (944) WINDSHIELD WASHER UNIT PARTS DIAGRAM")
-part-diagram-904-015.webp "PORSCHE 1991 (944) HEADLIGHT WASHER SYSTEM PARTS DIAGRAM")
-part-diagram-905-000.webp "PORSCHE 1991 (944) HEADLAMP - ELECTRIC MOTOR - POP-UP HEADLIGHT PARTS DIAGRAM")
-part-diagram-905-005.webp "PORSCHE 1991 (944) ADDITIONAL HEADLIGHT - FOG LIGHTS - TURN SIGNAL PARTS DIAGRAM")
-part-diagram-905-010.webp "PORSCHE 1991 (944) ADDITIONAL HEADLIGHT - TURN SIGNAL PARTS DIAGRAM")
-part-diagram-905-015.webp "PORSCHE 1991 (944) LICENSE PLATE LIGHT - REAR LIGHT - ADDITIONAL BRAKE LIGHT PARTS DIAGRAM")
-part-diagram-905-020.webp "PORSCHE 1991 (944) INTERIOR LIGHT - TURN SIGNAL REPEATER PARTS DIAGRAM")
-part-diagram-906-000.webp "PORSCHE 1991 (944) INSTRUMENT CLUSTER PARTS DIAGRAM")
-part-diagram-906-005.webp "PORSCHE 1991 (944) SWITCH - AND - SENSOR PARTS DIAGRAM")
-part-diagram-907-000.webp "PORSCHE 1991 (944) CRUISE CONTROL SYSTEM PARTS DIAGRAM")
-part-diagram-909-000.webp "PORSCHE 1991 (944) ALARM SYSTEM PARTS DIAGRAM")
-part-diagram-910-000.webp "PORSCHE 1991 (944) ELECTRIC FAN PARTS DIAGRAM")
-part-diagram-911-000.webp "PORSCHE 1991 (944) RADIO UNIT PARTS DIAGRAM")
-part-diagram-911-005.webp "PORSCHE 1991 (944) FOR - SOUNDSYSTEM PARTS DIAGRAM")
-part-diagram-001-000.webp "PORSCHE 1991 (944) ACCESSORIES - TOOL - FIRST AID KIT PARTS DIAGRAM")
-part-diagram-001-003.webp "PORSCHE 1991 (944) CLEANING AGENT - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-001-004.webp "PORSCHE 1991 (944) ACCESSORIES - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-001-005.webp "PORSCHE 1991 (944) SIGNS/NOTICES PARTS DIAGRAM")
-part-diagram-001-010.webp "PORSCHE 1991 (944) IDENTIFICATION PLATE PARTS DIAGRAM")
-part-diagram-002-000.webp "PORSCHE 1991 (944) ACCESSORIES PARTS DIAGRAM")
-part-diagram-002-006.webp "PORSCHE 1991 (944) ROOF TRANSPORT SYSTEM PARTS DIAGRAM")
-part-diagram-002-007.webp "PORSCHE 1991 (944) ROOF TRANSPORT SYSTEM PARTS DIAGRAM")
-part-diagram-002-010.webp "PORSCHE 1991 (944) ACCESSORIES PARTS DIAGRAM")
-part-diagram-004-000.webp "PORSCHE 1991 (944) PAINT TOUCH-UP STICK PARTS DIAGRAM")
-part-diagram-005-003.webp "PORSCHE 1991 (944) INSTRUCTION MANUAL - D - MJ 1989>> - MJ 1991 PARTS DIAGRAM")
-part-diagram-005-005.webp "PORSCHE 1991 (944) OWNER'S MANUAL - CARE PASS PARTS DIAGRAM")
-part-diagram-101-000.webp "PORSCHE 1991 (944) SHORT ENGINE - CRANKCASE PARTS DIAGRAM")
-part-diagram-101-005.webp "PORSCHE 1991 (944) UNDERSIDE PROTECTION PARTS DIAGRAM")
-part-diagram-101-015.webp "PORSCHE 1991 (944) CRANKCASE - FASTENERS - REPAIR SET FOR MAINTENANCE - SEE ILLUSTRATION: PARTS DIAGRAM")
-part-diagram-102-000.webp "PORSCHE 1991 (944) CRANKSHAFT - CONNECTING ROD PARTS DIAGRAM")
-part-diagram-102-005.webp "PORSCHE 1991 (944) PISTON - PISTON RINGS PARTS DIAGRAM")
-part-diagram-103-000.webp "PORSCHE 1991 (944) CYLINDER HEAD - VALVES PARTS DIAGRAM")
-part-diagram-103-003.webp "PORSCHE 1991 (944) CYLINDER HEAD - VALVES PARTS DIAGRAM")
-part-diagram-103-004.webp "PORSCHE 1991 (944) CYLINDER HEAD - VALVES PARTS DIAGRAM")
-part-diagram-103-005.webp "PORSCHE 1991 (944) CAMSHAFT HOUSING - CAMSHAFT PARTS DIAGRAM")
-part-diagram-103-007.webp "PORSCHE 1991 (944) CAMSHAFT PARTS DIAGRAM")
-part-diagram-103-012.webp "PORSCHE 1991 (944) DRIVING MECHANISM - CAMSHAFT PARTS DIAGRAM")
-part-diagram-103-015.webp "PORSCHE 1991 (944) DRIVING MECHANISM - SHAFT PARTS DIAGRAM")
-part-diagram-104-000.webp "PORSCHE 1991 (944) ENGINE LUBRICATION PARTS DIAGRAM")
-part-diagram-104-001.webp "PORSCHE 1991 (944) ENGINE LUBRICATION PARTS DIAGRAM")
-part-diagram-104-003.webp "PORSCHE 1991 (944) OIL COOLING PARTS DIAGRAM")
-part-diagram-104-004.webp "PORSCHE 1991 (944) OIL COOLING PARTS DIAGRAM")
-part-diagram-104-005.webp "PORSCHE 1991 (944) ENGINE LUBRICATION - EXHAUST GAS TURBOCHARGER PARTS DIAGRAM")
-part-diagram-105-000.webp "PORSCHE 1991 (944) WATER PUMP PARTS DIAGRAM")
-part-diagram-105-005.webp "PORSCHE 1991 (944) WATER COOLING PARTS DIAGRAM")
-part-diagram-105-007.webp "PORSCHE 1991 (944) WATER COOLING PARTS DIAGRAM")
-part-diagram-105-010.webp "PORSCHE 1991 (944) WATER COOLING PARTS DIAGRAM")
-part-diagram-106-000.webp "PORSCHE 1991 (944) AIR CLEANER SYSTEM PARTS DIAGRAM")
-part-diagram-106-005.webp "PORSCHE 1991 (944) AIR CLEANER SYSTEM PARTS DIAGRAM")
-part-diagram-106-010.webp "PORSCHE 1991 (944) AIR CLEANER SYSTEM PARTS DIAGRAM")
-part-diagram-107-000.webp "PORSCHE 1991 (944) L-JETRONIC - 1 PARTS DIAGRAM")
-part-diagram-107-005.webp "PORSCHE 1991 (944) L-JETRONIC - 2 PARTS DIAGRAM")
-part-diagram-107-010.webp "PORSCHE 1991 (944) L-JETRONIC - 3 PARTS DIAGRAM")
-part-diagram-107-015.webp "PORSCHE 1991 (944) L-JETRONIC - 1 PARTS DIAGRAM")
-part-diagram-107-020.webp "PORSCHE 1991 (944) L-JETRONIC - 2 PARTS DIAGRAM")
-part-diagram-107-027.webp "PORSCHE 1991 (944) L-JETRONIC - 3 PARTS DIAGRAM")
-part-diagram-107-030.webp "PORSCHE 1991 (944) L-JETRONIC - 4 PARTS DIAGRAM")
-part-diagram-107-035.webp "PORSCHE 1991 (944) CHARGE AIR COOLER PARTS DIAGRAM")
-part-diagram-107-040.webp "PORSCHE 1991 (944) L-JETRONIC - 1 PARTS DIAGRAM")
-part-diagram-107-045.webp "PORSCHE 1991 (944) L-JETRONIC - 2 PARTS DIAGRAM")
-part-diagram-107-050.webp "PORSCHE 1991 (944) L-JETRONIC - 3 PARTS DIAGRAM")
-part-diagram-109-000.webp "PORSCHE 1991 (944) ENGINE SUSPENSION PARTS DIAGRAM")
-part-diagram-109-005.webp "PORSCHE 1991 (944) ENGINE SUSPENSION PARTS DIAGRAM")
-part-diagram-198-005.webp "PORSCHE 1991 (944) ENGINE OIL - PORSCHE CLASSIC 10W50 PARTS DIAGRAM")
-part-diagram-201-000.webp "PORSCHE 1991 (944) FUEL TANK PARTS DIAGRAM")
-part-diagram-201-003.webp "PORSCHE 1991 (944) FILLER NECK PARTS DIAGRAM")
-part-diagram-201-004.webp "PORSCHE 1991 (944) FILLER NECK PARTS DIAGRAM")
-part-diagram-201-005.webp "PORSCHE 1991 (944) EVAPORATIVE EMISSION CANISTER PARTS DIAGRAM")
-part-diagram-201-007.webp "PORSCHE 1991 (944) EVAPORATIVE EMISSION CANISTER PARTS DIAGRAM")
-part-diagram-201-012.webp "PORSCHE 1991 (944) FUEL SYSTEM PARTS DIAGRAM")
-part-diagram-201-015.webp "PORSCHE 1991 (944) FUEL SYSTEM PARTS DIAGRAM")
-part-diagram-202-000.webp "PORSCHE 1991 (944) EXHAUST SYSTEM - EXHAUST SILENCER, FRONT PARTS DIAGRAM")
-part-diagram-202-005.webp "PORSCHE 1991 (944) EXHAUST SYSTEM - CATALYST PARTS DIAGRAM")
-part-diagram-202-010.webp "PORSCHE 1991 (944) EXHAUST SYSTEM - EXHAUST SILENCER, REAR PARTS DIAGRAM")
-part-diagram-202-015.webp "PORSCHE 1991 (944) EXHAUST SYSTEM - EXHAUST SILENCER, FRONT PARTS DIAGRAM")
-part-diagram-202-020.webp "PORSCHE 1991 (944) EXHAUST SYSTEM - CATALYST PARTS DIAGRAM")
-part-diagram-202-025.webp "PORSCHE 1991 (944) EXHAUST SYSTEM - EXHAUST SILENCER, REAR PARTS DIAGRAM")
-part-diagram-202-027.webp "PORSCHE 1991 (944) EXHAUST SYSTEM - EXHAUST SILENCER, FRONT PARTS DIAGRAM")
-part-diagram-202-028.webp "PORSCHE 1991 (944) EXHAUST SYSTEM - CATALYST PARTS DIAGRAM")
-part-diagram-202-029.webp "PORSCHE 1991 (944) EXHAUST SYSTEM - EXHAUST SILENCER, REAR PARTS DIAGRAM")
-part-diagram-202-030.webp "PORSCHE 1991 (944) EXHAUST GAS TURBOCHARGER PARTS DIAGRAM")
-part-diagram-298-005.webp "PORSCHE 1991 (944) PORSCHE CLASSIC - ADDITIVE - FOR FUEL PARTS DIAGRAM")
-part-diagram-301-000.webp "PORSCHE 1991 (944) CENTRAL TUBE - FOR - MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-301-005.webp "PORSCHE 1991 (944) CLUTCH PARTS DIAGRAM")
