porsche 1991 (944) side panel - windshield frame - end plate parts diagram

801-017 - SIDE PANEL - WINDSHIELD FRAME - END PLATE

Porsche 1991 (944) SIDE PANEL - WINDSHIELD FRAME - END PLATE Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: 94120134110
                REINFORCEMENT FOR SIDE PANEL
                LEFT
                from £79.68
                from £79.68
                REINFORCEMENT FOR SIDE PANEL Genuine Porsche Part - New (to order)
                # 1
                MPN: 94120134210
                REINFORCEMENT FOR SIDE PANEL
                RIGHT
                from £100.29
                from £100.29
                REINFORCEMENT FOR SIDE PANEL Genuine Porsche Part - New (to order)
                # 2
                MPN: 94150232510
                REINFORCEMENT - WINDSHIELD FRAME
                LEFT
                from £40.22
                from £40.22
                REINFORCEMENT - WINDSHIELD FRAME Genuine Porsche Part - New (to order)
                # 2
                MPN: 94150232610
                REINFORCEMENT - WINDSHIELD FRAME
                RIGHT
                from £40.22
                from £40.22
                REINFORCEMENT - WINDSHIELD FRAME Genuine Porsche Part - New (to order)
                # 3
                MPN: 94120134710
                REINFORCEMENT - TANK FILLER NECK - LOWER PART
                RIGHT
                from £21.06
                from £21.06
                REINFORCEMENT - TANK FILLER NECK - LOWER PART Genuine Porsche Part - New (to order)
                # 4
                MPN: 94150331110
                sill
                LEFT
                sill Genuine Porsche Part - New (to order)
                # 4
                MPN: 94150331210
                sill
                RIGHT
                sill Genuine Porsche Part - New (to order)
                # 5
                MPN: 94150243310
                RIP PLATE
                LEFT
                from £14.53
                from £14.53
                RIP PLATE Genuine Porsche Part - New (to order)
                # 5
                MPN: 94150243410
                RIP PLATE
                RIGHT
                RIP PLATE Genuine Porsche Part - New (to order)
                # 6
                MPN: 94150239510
                HINGE PILLAR
                LEFT
                from £9.83
                from £9.83
                HINGE PILLAR Genuine Porsche Part - New (to order)
                # 6
                MPN: 94150239610
                HINGE PILLAR
                RIGHT
                from £9.83
                from £9.83
                HINGE PILLAR Genuine Porsche Part - New (to order)
                # 7
                MPN: 94150390110
                SIDE PANEL
                LEFT
                SIDE PANEL Genuine Porsche Part - New (to order)
                # 7
                MPN: 94150390210
                SIDE PANEL
                RIGHT
                from £758.57
                from £758.57
                SIDE PANEL Genuine Porsche Part - New (to order)
                # 8
                MPN: 94150190110
                SIDE PANEL
                LEFT
                SIDE PANEL Genuine Porsche Part - New (to order)
                # 8
                MPN: 94150190210
                SIDE PANEL
                RIGHT
                from £134.44
                from £134.44
                SIDE PANEL Genuine Porsche Part - New (to order)
                # 9
                MPN: 94150290710
                CONVERTIBLE TOP SUPPORT
                LEFT
                from £185.03
                from £185.03
                CONVERTIBLE TOP SUPPORT Genuine Porsche Part - New (to order)
                # 9
                MPN: 94150290810
                CONVERTIBLE TOP SUPPORT
                RIGHT
                from £47.21
                from £47.21
                CONVERTIBLE TOP SUPPORT Genuine Porsche Part - New (to order)
                # 10
                MPN: 94150290110
                CROSS MEMBER
                from £140.81
                from £140.81
                CROSS MEMBER Genuine Porsche Part - New (to order)
                # 11
                MPN: 94150291310
                END PLATE
                from £370.51
                from £370.51
                END PLATE Genuine Porsche Part - New (to order)
                # 12
                MPN: 94150290310
                END PLATE
                END PLATE Genuine Porsche Part - New (to order)
                # 13
                MPN: 94150290510
                windshield frame
                from £385.38
                from £385.38
                windshield frame Genuine Porsche Part - New (to order)
                # 14
                MPN: 94150244310
                BRACKET
                FRONT
                from £9.14
                from £9.14
                BRACKET Genuine Porsche Part - New (to order)
                # 15
                MPN: 94150244110
                BRACKET
                rear
                from £14.01
                from £14.01
                BRACKET Genuine Porsche Part - New (to order)
                # 16
                MPN: 94150470110
                JOUNCE BUMPER
                from £50.00
                from £50.00
                JOUNCE BUMPER Genuine Porsche Part - New (to order)
                # 17
                MPN: 94150410511
                VIBRATION DAMPER
                from £376.44
                from £376.44
                vibration damper - Discontinued part Genuine Porsche Part - New (to order)
                # 19
                MPN: 94150267310
                REINFORCEMENT PLATE
                from £22.27
                from £22.27
                REINFORCEMENT PLATE Genuine Porsche Part - New (to order)
                # 20
                MPN: 94150262110
                REINFORCEMENT PLATE
                LEFT
                from £9.41
                from £9.41
                REINFORCEMENT PLATE Genuine Porsche Part - New (to order)
                # 21
                MPN: 94150262210
                REINFORCEMENT PLATE
                RIGHT
                from £9.41
                from £9.41
                REINFORCEMENT PLATE Genuine Porsche Part - New (to order)
