porsche 2014 (991-1 r/gt3/rs) secondary air pump parts diagram

108-000 - Secondary Air Pump

Porsche 2014 (991-1 R/GT3/RS) Secondary air pump Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                #
                                Part number
                                Description
                                Key
                                Price
                                # 1
                                MPN: 9A160510472
                                Secondary Air Pump
                                A175
                                Supersession
                                Supersession
                                Genuine Porsche Part (no longer available to order)
                                # 1
                                MPN: 95B959253
                                Secondary Air Pump
                                A176, DGGA, DGGB, DNS, DSD
                                from £748.89
                                from £748.89
                                Secondary Air Pump Genuine Porsche Part - New (to order)
                                # 2
                                MPN: 9A111318992
                                VALVE AIR LINE
                                A175, A176
                                VALVE Genuine Porsche Part - New (to order)
                                # 2
                                MPN: 9A111318993
                                VALVE AIR LINE
                                DGGA, DGGB, DNS, DSD
                                from £1,092.43
                                from £1,092.43
                                VALVE Genuine Porsche Part - New (to order)
                                # 3
                                -
                                HEAT INSULATION * SINGLE PARTS NO AVAILABLE * USE ITEM: 2
                                # 4
                                MPN: 99711324990
                                CUT-OFF VALVE
                                Supersession
                                Supersession
                                Genuine Porsche Part (no longer available to order)
                                # 5
                                MPN: 99311325851
                                SEAL
                                from £7.07
                                from £7.07
                                GASKET Genuine Porsche Part - New (to order)
                                # 6
                                MPN: 90038504102
                                HEXAGON HEAD BOLT M6X12
                                HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                # 7
                                MPN: 99907311001
                                flat round head bolt M6X30
                                from £2.29
                                from £2.29
                                screw, round hd. - M 6 X 30 Genuine Porsche Part - New (to order)
                                # 8
                                MPN: 99907318901
                                flat round head bolt M6X12
                                from £0.91
                                from £0.91
                                SCREW, ROUND HD Genuine Porsche Part - New (to order)
                                # 9
                                MPN: 7PP906270
                                Change-over valve
                                A175, A176
                                from £37.47
                                from £37.47
                                This part replaces part number 99660512301
                                Change-over valve Genuine Porsche Part - New (to order)
                                # 9
                                MPN: 7PP906283E
                                Change-over valve
                                DGGA, DGGB, DNS, DSD
                                from £44.40
                                from £44.40
                                Change-over valve Genuine Porsche Part - New (to order)
                                # 10
                                MPN: 9A111330590
                                BRACKET SECONDARY AIR PUMP
                                A175, A176
                                from £44.66
                                from £44.66
                                BRACKET Genuine Porsche Part - New (to order)
                                # 10
                                MPN: 9A111330595
                                BRACKET SECONDARY AIR PUMP
                                DGGA, DGGB
                                from £33.01
                                from £33.01
                                BRACKET Genuine Porsche Part - New (to order)
                                # 10
                                MPN: 9A111330596
                                BRACKET SECONDARY AIR PUMP
                                BRACKET SECONDARY AIR PUMP
                                from £24.56
                                from £24.56
                                BRACKET Genuine Porsche Part - New (to order)
                                # 10
                                MPN: 9GT131085
                                BRACKET SECONDARY AIR PUMP
                                BRACKET SECONDARY AIR PUMP
                                from £44.74
                                from £44.74
                                BRACKET Genuine Porsche Part - New (to order)
                                # 10
                                MPN: 9GT131085A
                                BRACKET SECONDARY AIR PUMP
                                DNS, DSD
                                from £44.74
                                from £44.74
                                BRACKET Genuine Porsche Part - New (to order)
                                # 11
                                MPN: 9A111333990
                                HOSE
                                A175
                                HOSE Genuine Porsche Part - New (to order)
                                # 11
                                MPN: 9A111323990
                                HOSE
                                A176
                                from £84.40
                                from £84.40
                                HOSE Genuine Porsche Part - New (to order)
                                # 11
                                MPN: 9A111323995
                                HOSE
                                DGGA, DGGB, DNS, DSD
                                from £132.51
                                from £132.51
                                HOSE Genuine Porsche Part - New (to order)
                                # 12
                                MPN: 99951234601
                                HOSE CLAMP 16 - 27
                                from £2.29
                                from £2.29
                                HOSE CLAMP Genuine Porsche Part - New (to order)
                                # 12
                                MPN: 99951276501
                                Spring band clamp 26X12
                                from £20.13
                                from £20.13
                                SPRING CLIP Genuine Porsche Part - New (to order)
                                # 13
                                MPN: 9A111338590
                                BRACKET
                                from £36.26
                                from £36.26
                                BRACKET Genuine Porsche Part - New (to order)
                                # 14
                                MPN: 99950708540
                                CLIP
                                from £0.59
                                from £0.59
                                CLIP Genuine Porsche Part - New (to order)
                                # 15
                                MPN: 99970231940
                                Grommet 10X16,8
                                Grommet 10X16,8
                                from £2.34
                                from £2.34
                                GROMMET Genuine Porsche Part - New (to order)
                                # 15
                                MPN: PAF912916
                                Grommet 10X16,8
                                DGGA, DGGB, DNS, DSD
                                from £12.59
                                from £12.59
                                GROMMET Genuine Porsche Part - New (to order)
                                # 16
                                MPN: 99150486790
                                SLEEVE
                                from £19.02
                                from £19.02
                                SLEEVE Genuine Porsche Part - New (to order)
                                # 17
                                MPN: 9A111325800
                                SEAL AIR LINE
                                from £6.50
                                from £6.50
                                GASKET Genuine Porsche Part - New (to order)
                                # 18
                                MPN: 90038501901
                                TORX SCREW M6X20
                                TORX SCREW M6X20
                                Supersession
                                Supersession
                                Genuine Porsche Part (no longer available to order)
                                # 18
                                MPN: PAF008126
                                HEXAGON HEAD BOLT BM6X20
                                from £0.85
                                from £0.85
                                This part replaces part number 90038501901
                                HEXAGON HEAD BOLT Genuine Porsche Part - New In stock
                                # 19
                                MPN: 90038507001
                                TORX SCREW M6X50
                                TORX SCREW Genuine Porsche Part - New (to order)
                                # 20
                                MPN: 9A111060890
                                AIR FILTER SECONDARY AIR PUMP
                                from £10.37
                                from £10.37
                                AIR CLEANER Genuine Porsche Part - New (to order)
                                # 21
                                MPN: 90038500901
                                HEXAGON HEAD BOLT M6X16
                                Supersession
                                Supersession
                                Genuine Porsche Part (no longer available to order)
                                # 22
                                MPN: 90038504101
                                HEXAGON HEAD BOLT M6X12
                                Supersession
                                Supersession
                                Genuine Porsche Part (no longer available to order)
                                # 22
                                MPN: PAF008124
                                HEXAGON HEAD BOLT M6X12
                                from £2.66
                                from £2.66
                                This part replaces part number 90038504101
                                HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                # 23
                                MPN: 9A111038196
                                VACUUM LINE D >>- 08.01.2018
                                DGGA
                                VACUUM LINE Genuine Porsche Part - New (to order)
                                # 23
                                MPN: 9A111038197
                                VACUUM LINE D - 09.01.2018>>
                                DGGA
                                from £53.20
                                from £53.20
                                VACUUM LINE Genuine Porsche Part - New (to order)
                                # 23
                                MPN: 9A111038197
                                VACUUM LINE
                                DGGB, DSD, DNS
                                from £53.20
                                from £53.20
                                VACUUM LINE Genuine Porsche Part - New (to order)
