CG190 (7C Gearbox with Transmission Code: CG190 and installed 05/13-05/17) | CG195 (7C Gearbox with Transmission Code: CG195 and installed 05/14-05/17) | CG192 (7C Gearbox with Transmission Code: CG192 and installed 05/17-12/20) | G9190 (6S Gearbox with Transmission Code: G9190 and installed 05/15-05/16)
porsche 2015 (991-1 r/gt3/rs) support frame transmission securing parts parts diagram

306-000 - Support frame transmission securing parts

Porsche 2015 (991-1 R/GT3/RS) Support frame transmission securing parts Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: 99137503903
              TRANSMISSION CARRIER
              CG190 (7C Gearbox with Transmission Code: CG190 and installed 05/13-05/17) | CG192 (7C Gearbox with Transmission Code: CG192 and installed 05/17-12/20) | CG195 (7C Gearbox with Transmission Code: CG195 and installed 05/14-05/17) | G9190 (6S Gearbox with Transmission Code: G9190 and installed 05/15-05/16)
              Supersession
              Supersession
              Genuine Porsche Part (no longer available to order)
              # 2
              MPN: 99137511403
              SIDE MEMBER
              from £177.74
              from £177.74
              SIDE MEMBER Genuine Porsche Part - New (to order)
              # 3
              MPN: 99137525580
              STOP GEARBOX MOUNTING
              from £15.79
              from £15.79
              STOP Genuine Porsche Part - New (to order)
              # 4
              MPN: 99137505581
              gearbox mounting
              from £50.13
              from £50.13
              gearbox mounting Genuine Porsche Part - New (to order)
              # 5
              MPN: 99907208301
              BOLT WITH WASHER M10X58
              from £2.68
              from £2.68
              BOLT WITH WASHER Genuine Porsche Part - New (to order)
              # 6
              MPN: 99906100901
              THREADED PIN M10X102,5
              CG190 (7C Gearbox with Transmission Code: CG190 and installed 05/13-05/17)
              from £2.47
              from £2.47
              STUD Genuine Porsche Part - New (to order)
              # 6
              MPN: 99906100902
              THREADED PIN M10X102,5
              CG195 (7C Gearbox with Transmission Code: CG195 and installed 05/14-05/17) | G9190 (6S Gearbox with Transmission Code: G9190 and installed 05/15-05/16)
              from £3.42
              from £3.42
              STUD Genuine Porsche Part - New (to order)
              # 7
              MPN: 99908464801
              HEXAGON NUT M10
              HEXAGON NUT M10
              Supersession
              Supersession
              Genuine Porsche Part (no longer available to order)
              # 7
              MPN: 99907605301
              HEXAGON NUT M10
              Supersession
              Supersession
              Genuine Porsche Part (no longer available to order)
              # 8
              MPN: 90038516401
              HEXAGON HEAD BOLT BM12X1,5X140
              from £5.95
              from £5.95
              HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
              # 9
              MPN: 99908600902
              Nut M12X1,5
              from £6.78
              from £6.78
              NUT Genuine Porsche Part - New (to order)
              # 10
              MPN: 99907206302
              HEXAGON BOLT AM10X40
              HEXAGON BOLT AM10X40
              from £1.39
              from £1.39
              SCREW, HEX. HD Genuine Porsche Part - New (to order)
              # 10
              MPN: PAF009267
              HEXAGON BOLT M10X40
              from £1.80
              from £1.80
              SCREW, HEX. HD Genuine Porsche Part - New (to order)
