P288 (Headlamp washer)
porsche 2015 (991-1 r/gt3/rs) headlight washer system parts diagram

904-020 - HEADLIGHT WASHER SYSTEM

Porsche 2015 (991-1 R/GT3/RS) headlight washer system Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 1
                      MPN: 95862450200
                      PUMP FOR HEADLIGHT- WASHER SYSTEM
                      from £66.42
                      from £66.42
                      PUMP FOR HEADLIGHT- Genuine Porsche Part - New (to order)
                      PUMP FOR HEADLIGHT- Genuine Porsche Part - Used In stock
                      # 2
                      MPN: 431955465A
                      SEAL
                      from £2.30
                      from £2.30
                      GASKET Genuine Porsche Part - New (to order)
                      GASKET Genuine Lamborghini - New (to order)
                      # 2
                      MPN: 00004320479
                      HOSE 8X3
                      from £11.55
                      from £11.55
                      HOSE - 8 X 3 Genuine Porsche Part - New (to order)
                      # 3
                      -
                      SHORTEN TO: 905 MM
                      # 4
                      MPN: 8E0955665
                      ELBOW FITTING
                      from £8.17
                      from £8.17
                      elbow connector Genuine Porsche Part - New (to order)
                      # 5
                      MPN: 99762820500
                      COUPLING
                      from £11.59
                      from £11.59
                      clutch Genuine Porsche Part - New (to order)
                      # 6
                      MPN: 99162820801
                      HOSE CONNECTOR
                      from £13.02
                      from £13.02
                      HOSE CONNECTOR Genuine Porsche Part - New (to order)
                      # 6
                      MPN: 00004320479
                      HOSE 8X3
                      from £11.55
                      from £11.55
                      HOSE - 8 X 3 Genuine Porsche Part - New (to order)
                      # 7
                      -
                      SHORTEN TO: 620 MM
                      # 8
                      -
                      SHORTEN TO: 1225 MM
                      # 9
                      -
                      SHORTEN TO: 65 MM
                      # 10
                      MPN: 113955975B
                      T-PIECE
                      from £6.89
                      from £6.89
                      T-PIECE Genuine Porsche Part - New In stock
                      # 11
                      MPN: 99762816301
                      JET CHROMED INCLUDED NOZZLE HEAD
                      P without 011
                      from £61.36
                      from £61.36
                      jet chromed with: Nozzle head Genuine Porsche Part - New In stock
                      # 11
                      MPN: 99162816700
                      JET MATT BLACK INCLUDED NOZZLE HEAD
                      P011 (Special model GTS (981/991))
                      Supersession
                      Supersession
                      Genuine Porsche Part (no longer available to order)
                      # 12
                      MPN: 99762826300
                      NOZZLE HEAD CHROMED
                      P without 011
                      from £15.52
                      from £15.52
                      NOZZLE HEAD Genuine Porsche Part - New (to order)
                      # 12
                      MPN: 99162826500
                      NOZZLE HEAD MATT BLACK
                      P011 (Special model GTS (981/991))
                      NOZZLE HEAD Genuine Porsche Part - New (to order)
                      # 13
                      MPN: 99950716401
                      CABLE FASTENER
                      from £2.70
                      from £2.70
                      CABLE FASTENER Genuine Porsche Part - New (to order)
                      # 13
                      MPN: 99762898102
                      CAP PRIMED TO BE USED FOR ITEM: 11, 12
                      PXUB (Cover on headlight cleaning system, painted)
                      from £23.98
                      from £23.98
                      CAP Genuine Porsche Part - New (to order)
