porsche 2015 (991-1 turbo) secondary air pump parts diagram

108-000 - Secondary Air Pump

Porsche 2015 (991-1 Turbo) Secondary air pump Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 1
                          MPN: 9A111312370
                          CONNECTING LINE CYLINDERS 1-3 VALVE
                          A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016)
                          connecting line Genuine Porsche Part - New (to order)
                          # 1
                          MPN: 9A111312371
                          CONNECTING LINE CYLINDERS 1-3 VALVE
                          DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) | DBCB (3.8 Litre 6 Cyliner Engine (606 Horsepower / 446 Kilowatt with Engine Code: DBCB and installed 05/2017-05/2020) | DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020)
                          from £104.99
                          from £104.99
                          connecting line Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 9A111312470
                          CONNECTING LINE CYLINDERS 4-6 VALVE
                          A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016)
                          connecting line Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 9A111312471
                          CONNECTING LINE CYLINDERS 4-6 VALVE
                          DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) | DBCB (3.8 Litre 6 Cyliner Engine (606 Horsepower / 446 Kilowatt with Engine Code: DBCB and installed 05/2017-05/2020)
                          from £58.97
                          from £58.97
                          connecting line Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 9A111312480
                          CONNECTING LINE CYLINDERS 4-6 VALVE
                          GT2 RS, DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020)
                          from £158.38
                          from £158.38
                          connecting line Genuine Porsche Part - New (to order)
                          # 3
                          MPN: 9A111310677
                          BRACKET UPPER CYLINDERS 1-3
                          from £55.38
                          from £55.38
                          BRACKET Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 9A111334270
                          PRESSURE LINE SECONDARY AIR PUMP
                          A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016)
                          PRESSURE LINE Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 9A111334271
                          PRESSURE LINE SECONDARY AIR PUMP
                          DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) | DBCB (3.8 Litre 6 Cyliner Engine (606 Horsepower / 446 Kilowatt with Engine Code: DBCB and installed 05/2017-05/2020) | DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020)
                          from £106.00
                          from £106.00
                          PRESSURE LINE Genuine Porsche Part - New (to order)
                          # 5
                          MPN: 9A111310172
                          CONSOLE FAN
                          from £66.69
                          from £66.69
                          BRACKET Genuine Porsche Part - New (to order)
                          # 6
                          MPN: 97011323100
                          RUBBER BUSH CONSOLE
                          from £6.99
                          from £6.99
                          This part replaces part number 95811323100
                          RUBBER BUSH Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 9A160510472
                          Secondary Air Pump
                          A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016)
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 7
                          MPN: 95B959253
                          Secondary Air Pump
                          DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) | DBCB (3.8 Litre 6 Cyliner Engine (606 Horsepower / 446 Kilowatt with Engine Code: DBCB and installed 05/2017-05/2020) | DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020)
                          from £748.89
                          from £748.89
                          Secondary Air Pump Genuine Porsche Part - New (to order)
                          # 8
                          MPN: 90038500901
                          HEXAGON HEAD BOLT BM6X16
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 9
                          MPN: 90038504501
                          TORX SCREW BM6X40
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 10
                          MPN: 99311325851
                          SEAL
                          from £7.07
                          from £7.07
                          GASKET Genuine Porsche Part - New (to order)
                          # 11
                          MPN: 9A111325800
                          SEAL
                          from £6.50
                          from £6.50
                          GASKET Genuine Porsche Part - New (to order)
                          # 12
                          MPN: 99902526801
                          WASHER 6,4X18X1,2
                          from £1.73
                          from £1.73
                          WASHER Genuine Porsche Part - New (to order)
                          # 13
                          MPN: 99711320371
                          VALVE
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 15
                          MPN: 9A160516500
                          CHANGE-OVER VALVE INCLUDED BRACKET
                          from £67.04
                          from £67.04
                          Change-over valve Genuine Porsche Part - New (to order)
                          # 16
                          MPN: 90038504101
                          HEXAGON HEAD BOLT BM6X12
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 17
                          MPN: 90038501901
                          TORX SCREW BM6X20
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
