porsche 2016 (991-1) parking brake parts diagram

603-005 - PARKING BRAKE

Porsche 2016 (991-1) Parking brake Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Key
          Price
          # 1
          MPN: 97035299301
          1 SET: BRAKE SHOES WITH LININGS REPAIR SET COMPRISING: 4 X BRAKE SHOE WITH LINING ALSO USE: FASTENERS D >>- MJ 2012
          BRAKE SHOE Genuine Porsche Part - New (to order)
          # 1
          MPN: 97035299302
          1 set: brake shoes with linings repair set comprising: 4 X brake shoe with lining also use: Fasteners D - MJ 2013>>
          1 set: brake shoes with linings repair set comprising: 4 X brake shoe with lining also use: Fasteners D - MJ 2013>>
          BRAKE SHOE Genuine Porsche Part - New (to order)
          # 1
          MPN: 298698533
          1 SET: BRAKE SHOES WITH LININGS REPAIR SET COMPRISING: 4 X BRAKE SHOE WITH LINING ALSO USE: FASTENERS
          1 SET: BRAKE SHOES WITH LININGS REPAIR SET COMPRISING: 4 X BRAKE SHOE WITH LINING ALSO USE: FASTENERS
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 1
          MPN: 971698533C
          1 SET: BRAKE SHOES WITH LININGS REPAIR SET COMPRISING: 4 X BRAKE SHOE WITH LINING ALSO USE: FASTENERS
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 2
          MPN: 99335207100
          ADJUSTMENT SCREW
          ADJUSTMENT SCREW
          adjustment screw - Discontinued part Genuine Porsche Part - New (to order)
          # 2
          MPN: 298609723
          ADJUSTMENT SCREW
          from £5.73
          from £5.73
          adjustment screw - D - MJ 2000>> Genuine Porsche Part - New (to order)
          ADJUSTMENT SCREW Genuine Bentley Part - New (to order)
          # 3
          MPN: 99735272101
          TENSION SPRING
          TENSION SPRING
          TENSION SPRING Genuine Porsche Part - New (to order)
          # 3
          MPN: 298609717
          TENSION SPRING
          from £5.34
          from £5.34
          TENSION SPRING Genuine Porsche Part - New In stock
          TENSION SPRING Genuine Bentley Part - New (to order)
          TENSION SPRING Genuine Porsche Part - Used In stock
          # 4
          MPN: 97035272300
          TENSION SPRING
          TENSION SPRING Genuine Porsche Part - New (to order)
          # 5
          MPN: 97035274100
          PRESSURE SPRING
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 6
          MPN: 97035209105
          Servomotor left
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 6
          MPN: 97035209205
          Servomotor right
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 7
          MPN: 99907345201
          LOCATING BOLT M 8 X 38
          from £0.74
          from £0.74
          SCREW Genuine Porsche Part - New (to order)
