porsche 2016 (991-1) wiring looms rear assembly frame additional brake light trim engine rear axle parts diagram

902-020 - Wiring looms rear Assembly frame Additional brake light Trim Engine Rear axle

Porsche 2016 (991-1) Wiring looms rear Assembly frame Additional brake light Trim Engine Rear axle Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: 99161288000
            WIRE SET ASSEMBLY FRAME
            Coupe, P without XAA, P without XAT
            harness Genuine Porsche Part - New (to order)
            # 1
            MPN: 99161288400
            WIRE SET ASSEMBLY FRAME
            COUPE, PXAA (Aerokit Cup) | PXAT (SportDesign package)
            harness Genuine Porsche Part - New (to order)
            # 1
            MPN: 99161288050
            WIRE SET ASSEMBLY FRAME
            Cabrio, P without XAT
            harness Genuine Porsche Part - New (to order)
            # 1
            MPN: 99161288450
            WIRE SET ASSEMBLY FRAME
            CABRIO, PXAT (SportDesign package)
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 1
            MPN: 99161288500
            WIRE SET ADDITIONAL BRAKE LIGHT
            PXAA (Aerokit Cup) | PXAT (SportDesign package)
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 1
            MPN: 99161024100
            CABLE GUIDE WIRE SET ASSEMBLY FRAME
            from £15.04
            from £15.04
            WIRING CONDUIT Genuine Porsche Part - New (to order)
            # 2
            MPN: 99161289602
            WIRE SET REAR TRIM
            CARRERA 2/2S, P635 (Park distance control) | P636 (Park distance control in front and rear)
            harness Genuine Porsche Part - New (to order)
            # 2
            MPN: 99161289803
            WIRE SET REAR TRIM
            CARRERA 4/4S, P635 (Park distance control) | P636 (Park distance control in front and rear)
            from £126.38
            from £126.38
            harness Genuine Porsche Part - New (to order)
            # 2
            MPN: 99161289502
            WIRE SET REAR TRIM
            CARRERA 2/2S, P without 635, P without 636
            harness Genuine Porsche Part - New (to order)
            # 2
            MPN: 99161289703
            WIRE SET REAR TRIM
            CARRERA 4/4S, P without 635, P without 636
            from £40.06
            from £40.06
            harness Genuine Porsche Part - New (to order)
            # 2
            MPN: 99161289650
            WIRE SET REAR TRIM D - MJ 2015>>
            CARRERA 2/2S, P638 (ParkAssist, front, rear and reversing camera)
            from £229.93
            from £229.93
            harness Genuine Porsche Part - New (to order)
            # 2
            MPN: 99161289850
            WIRE SET REAR TRIM D - MJ 2015>>
            CARRERA 4/4S, P638 (ParkAssist, front, rear and reversing camera)
            from £243.79
            from £243.79
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709002
            Wire set Engine D >>- MJ 2012
            A104 (3.4 Litre 6 Cyliner Engine (349 Horsepower / 257 Kilowatt with Engine Code: A104 and installed 05/2011-05/2016)
            from £1,107.68
            from £1,107.68
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709003
            WIRE SET ENGINE D - MJ 2013>>
            A104 (3.4 Litre 6 Cyliner Engine (349 Horsepower / 257 Kilowatt with Engine Code: A104 and installed 05/2011-05/2016)
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709006
            WIRE SET ENGINE D - MJ 2015>>
            A104 (3.4 Litre 6 Cyliner Engine (349 Horsepower / 257 Kilowatt with Engine Code: A104 and installed 05/2011-05/2016) with, PIY2 (Model year period from week 45 to week 22)
            from £1,056.47
            from £1,056.47
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709022
            Wire set Engine D >>- MJ 2012
            A103 (3.8 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: A103 and installed 05/2011-05/2016) with, P030 (Sports suspension) | P475 (PASM electronic damper control)
            from £1,107.68
            from £1,107.68
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709023
            WIRE SET ENGINE D - MJ 2013>>
            A103 (3.8 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: A103 and installed 05/2011-05/2016) with, P030 (Sports suspension) | P475 (PASM electronic damper control) | P477 (PASM w/o lowering) | P without X51
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709026
            WIRE SET ENGINE D - MJ 2015>>
            A103 (3.8 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: A103 and installed 05/2011-05/2016) with, P030 (Sports suspension) | P475 (PASM electronic damper control) | P477 (PASM w/o lowering) | P without X51, PIY2 (Model year period from week 45 to week 22)
            from £1,056.47
            from £1,056.47
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709042
            Wire set Engine D >>- MJ 2012
            A103 (3.8 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: A103 and installed 05/2011-05/2016) with, P031 (Sports chassis with PASM and PDCC) | P352 (Electronic damper control for PASM and PDCC)
            from £1,107.68
            from £1,107.68
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709043
            WIRE SET ENGINE D - MJ 2013>>
            A103 (3.8 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: A103 and installed 05/2011-05/2016) with, P031 (Sports chassis with PASM and PDCC) | P352 (Electronic damper control for PASM and PDCC) | P without X51
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709046
            WIRE SET ENGINE D - MJ 2015>>
            A103 (3.8 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: A103 and installed 05/2011-05/2016) with, P031 (Sports chassis with PASM and PDCC) | P352 (Electronic damper control for PASM and PDCC) | P without X51, PIY2 (Model year period from week 45 to week 22)
            from £1,056.47
            from £1,056.47
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709100
            WIRE SET ENGINE USE IF REQUIRED: D - MJ 2013>>
            A103 (3.8 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: A103 and installed 05/2011-05/2016) with, PX51 (Powerkit 250 kW)
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A160709104
            WIRE SET ENGINE D - MJ 2015>>
            A103 (3.8 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: A103 and installed 05/2011-05/2016) with, PX51 (Powerkit 250 kW) | PIY2 (Model year period from week 45 to week 22)
            harness Genuine Porsche Part - New (to order)
            # 3
            MPN: 99161295700
            ADAPTER 6 PIN D - MJ 2013>>
            A103 (3.8 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: A103 and installed 05/2011-05/2016) with, PX51 (Powerkit 250 kW)
            from £29.25
            from £29.25
            ADAPTER Genuine Porsche Part - New (to order)
            # 4
            MPN: 9A160711000
            CABLE GUIDE CRANKCASE HOUSING
            P without X51
            from £16.35
            from £16.35
            WIRING CONDUIT Genuine Porsche Part - New (to order)
            # 5
            MPN: 9A160712001
            COVER CABLE GUIDE
            P without X51
            from £8.06
            from £8.06
            COVER Genuine Porsche Part - New (to order)
            # 6
            MPN: 9A160711102
            CABLE GUIDE CYLINDERS 1-3
            P without X51
            from £16.35
            from £16.35
            WIRING CONDUIT Genuine Porsche Part - New (to order)
            # 6
            MPN: 9A160716346
            CABLE HOLDER CYLINDERS 1-3
            PX51 (Powerkit 250 kW)
            from £68.96
            from £68.96
            CABLE HOLDER Genuine Porsche Part - New (to order)
            # 7
            MPN: 9A160712101
            COVER CABLE GUIDE
            P without X51
            from £5.58
            from £5.58
            COVER Genuine Porsche Part - New (to order)
            # 8
            MPN: 9A160717400
            CABLE GUIDE CYLINDERS 4-6
            P without X51
            from £16.35
            from £16.35
            WIRING CONDUIT Genuine Porsche Part - New (to order)
            # 8
            MPN: 9A160716145
            CABLE HOLDER CYLINDERS 4-6
            PX51 (Powerkit 250 kW)
            from £63.15
            from £63.15
            CABLE HOLDER Genuine Porsche Part - New (to order)
            # 9
            MPN: 9A160718400
            COVER CABLE GUIDE
            P without X51
            from £9.73
            from £9.73
            COVER Genuine Porsche Part - New (to order)
            # 10
            MPN: 9A160711300
            CABLE GUIDE FUEL COLLECTION PIPE
            from £3.81
            from £3.81
            WIRING CONDUIT Genuine Porsche Part - New (to order)
            # 11
            MPN: 90038500103
            TORX SCREW BM 8 X 20
            from £1.17
            from £1.17
            TORX SCREW Genuine Porsche Part - New (to order)
            # 12
            MPN: 90038500901
            HEXAGON HEAD BOLT BM 6 X 16
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 13
            MPN: 99161013900
            BRACKET CONNECTION POINT WIRE SET ENGINE
            from £7.28
            from £7.28
            BRACKET Genuine Porsche Part - New (to order)
            # 14
            MPN: 99161013500
            COVER CONNECTION POINT WIRE SET REAR AXLE
            from £5.39
            from £5.39
            COVER Genuine Porsche Part - New (to order)
            # 14
            MPN: 99904903340
            PLASTIC NUT T 6
            PLASTIC NUT Genuine Porsche Part - New (to order)
            # 15
            MPN: 99160913301
            WIRE SET LEFT REAR REAR AXLE LEFT
            P029 (Standard chassis)
            from £124.91
            from £124.91
            harness Genuine Porsche Part - New (to order)
            # 15
            MPN: 99160913401
            WIRE SET RIGHT REAR REAR AXLE RIGHT
            P029 (Standard chassis)
            from £124.91
            from £124.91
            harness Genuine Porsche Part - New (to order)
            # 15
            MPN: 99160913301
            WIRE SET REAR REAR AXLE
            P030 (Sports suspension) | P031 (Sports chassis with PASM and PDCC) | P352 (Electronic damper control for PASM and PDCC) | P475 (PASM electronic damper control)
            from £124.91
            from £124.91
            harness Genuine Porsche Part - New (to order)
            # 15
            MPN: 99965306740
            FLAT CONNECTOR HOUSING SENSOR MODULE
            from £15.24
            from £15.24
            MALE BLADE TERMINAL HOUSING Genuine Porsche Part - New (to order)
            # 15
            -
            WIRE SET FRONT AXLE SEE ILLUSTRATION: 902-010
