porsche 2017 (991-2) oil pump parts diagram

104-000 - oil pump

Porsche 2017 (991-2) oil pump Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                #
                                Part number
                                Description
                                Key
                                Price
                                # 1
                                MPN: 0PB115103D
                                oil pump
                                oil pump
                                from £995.07
                                from £995.07
                                oil pump Genuine Porsche Part - New (to order)
                                # 1
                                MPN: 9A711510310
                                oil pump
                                from £690.19
                                from £690.19
                                oil pump Genuine Porsche Part - New (to order)
                                # 2
                                MPN: 0PB115189
                                SEAL FOR OIL PUMP
                                from £10.50
                                from £10.50
                                SEAL FOR OIL PUMP Genuine Porsche Part - New (to order)
                                # 3
                                MPN: 0PB115131
                                SEAL FOR OIL PUMP
                                from £3.99
                                from £3.99
                                SEAL FOR OIL PUMP Genuine Porsche Part - New (to order)
                                # 4
                                MPN: 99970754740
                                O-RING 28,00X3,0
                                from £2.29
                                from £2.29
                                O-RING Genuine Porsche Part - New (to order)
                                # 5
                                MPN: 0PB115169
                                INTAKE MANIFOLD
                                from £142.31
                                from £142.31
                                INTAKE MANIFOLD Genuine Porsche Part - New (to order)
                                # 6
                                MPN: 9A110522502
                                CHAIN SPROCKET OIL PUMP
                                from £29.18
                                from £29.18
                                SPROCKET Genuine Porsche Part - New (to order)
                                # 7
                                MPN: 99907338001
                                TORX SCREW M8X22-PA-
                                TORX SCREW Genuine Porsche Part - New (to order)
                                # 8
                                -
                                DRIVE CHAIN OIL PUMP SEE ILLUSTRATION: 103-015
                                # 9
                                MPN: 90038510802
                                TORX SCREW BM6X80
                                from £1.62
                                from £1.62
                                TORX SCREW Genuine Porsche Part - New (to order)
                                # 10
                                MPN: 90038504801
                                TORX SCREW M6X30
                                Supersession
                                Supersession
                                Genuine Porsche Part (no longer available to order)
                                # 11
                                MPN: 90038500901
                                HEXAGON HEAD BOLT BM6X16
                                Supersession
                                Supersession
                                Genuine Porsche Part (no longer available to order)
                                # 12
                                MPN: 0PB115703
                                OIL PIPE OIL PUMP CRANKCASE HOUSING ALSO USE: 1X 999 707 575 40
                                from £33.28
                                from £33.28
                                OIL PIPE Genuine Porsche Part - New (to order)
                                # 13
                                MPN: 99970757540
                                O-RING 20,00X3,00
                                from £4.52
                                from £4.52
                                O-RING Genuine Porsche Part - New In stock
                                # 14
                                MPN: 0PB115393B
                                CONTROL VALVE
                                from £79.19
                                from £79.19
                                CONTROL VALVE Genuine Porsche Part - New (to order)
                                # 15
                                MPN: 94610741360
                                SECURING CLIP SOLENOID VALVE OIL PUMP
                                safety clamp Genuine Porsche Part - New (to order)
                                # 15
                                MPN: 9A711504700
                                SECURING CLIP SOLENOID VALVE OIL PUMP
                                from £2.45
                                from £2.45
                                safety clamp Genuine Porsche Part - New (to order)
                                # 16
                                -
                                OIL SUMP-UPPER PART SEE ILLUSTRATION: 104-002
