porsche 2017 (991-2 turbo) engine lifting tackle parts diagram

109-000 - ENGINE LIFTING TACKLE

Porsche 2017 (991-2 Turbo) Engine lifting tackle Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: 9A137501200
            ENGINE BRACKETS
            A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016)
            from £486.39
            from £486.39
            ENGINE CARRIER Genuine Porsche Part - New (to order)
            # 1
            MPN: 9A237505603
            ENGINE BRACKETS
            DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) | DBCB (3.8 Litre 6 Cyliner Engine (606 Horsepower / 446 Kilowatt with Engine Code: DBCB and installed 05/2017-05/2020) | DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020)
            from £280.31
            from £280.31
            ENGINE CARRIER Genuine Porsche Part - New (to order)
            # 2
            MPN: 9A137523610
            INTERMEDIATE FLANGE
            A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016) | DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020)
            from £76.43
            from £76.43
            INTERMEDIATE FLANGE Genuine Porsche Part - New (to order)
            # 2
            MPN: 9A137523611
            INTERMEDIATE FLANGE
            INTERMEDIATE FLANGE
            from £85.07
            from £85.07
            INTERMEDIATE FLANGE Genuine Porsche Part - New (to order)
            # 2
            MPN: 0PB199707
            INTERMEDIATE FLANGE
            DBCB (3.8 Litre 6 Cyliner Engine (606 Horsepower / 446 Kilowatt with Engine Code: DBCB and installed 05/2017-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) | DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020)
            from £118.96
            from £118.96
            INTERMEDIATE FLANGE Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A137524501
            SPACER SLEEVE INTERMEDIATE FLANGE
            A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016)
            from £9.49
            from £9.49
            SPACER SLEEVE Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A137524501
            SPACER SLEEVE INTERMEDIATE FLANGE D >>- 23.03.2017
            DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020)
            from £9.49
            from £9.49
            SPACER SLEEVE Genuine Porsche Part - New (to order)
            # 3
            MPN: 9A137524502
            spacer sleeve Intermediate flange D - 24.03.2017>>
            spacer sleeve Intermediate flange D - 24.03.2017>>
            from £11.79
            from £11.79
            SPACER SLEEVE Genuine Porsche Part - New (to order)
            # 3
            MPN: 9GT253185
            SPACER SLEEVE ENGINE BRACKETS D 2403217>>
            DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) | DBCB (3.8 Litre 6 Cyliner Engine (606 Horsepower / 446 Kilowatt with Engine Code: DBCB and installed 05/2017-05/2020) | DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020)
            from £18.72
            from £18.72
            SPACER SLEEVE Genuine Porsche Part - New (to order)
            # 4
            MPN: 90037828601
            HEXAGON BOLT M10X135
            from £4.16
            from £4.16
            SCREW, HEX. HD Genuine Porsche Part - New (to order)
            # 5
            MPN: 90037833201
            HEXAGON FLANGE SCREW M10X92
            HEXAGON FLANGE SCREW M10X92
            HEXAGON FLANGE SCREW Genuine Porsche Part - New (to order)
            # 5
            MPN: 9A700830700
            HEXAGON FLANGE SCREW M10X92
            from £2.47
            from £2.47
            HEXAGON FLANGE SCREW Genuine Porsche Part - New (to order)
            # 6
            MPN: N 10286110
            Hexagon collar nut M10 self-locking
            Hexagon collar nut M10 self-locking
            from £1.07
            from £1.07
            Genuine Porsche Part (no longer available to order)
            PREV.TORQUE TYPE M10 Genuine Lamborghini - New In stock
            # 6
            MPN: PAF102861
            Hexagon collar nut M10 self-locking
            from £1.62
            from £1.62
            This part replaces part number N 10286110
            HEXAGON COLLAR NUT SELF-LOCKING Genuine Porsche Part - New (to order)
            # 7
            MPN: 99137504901
            HYDRO-MOUNTING
            A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016) with, P without 140
            from £170.00
            from £170.00
            HYDRO-MOUNTING Genuine Porsche Part - New (to order)
            # 7
            MPN: 99137504902
            HYDRO-MOUNTING
            A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016) with, P without 140
            from £170.00
            from £170.00
            HYDRO-MOUNTING Genuine Porsche Part - New (to order)
            # 7
            MPN: 99137504904
            HYDRO-MOUNTING
            DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) with, P without 140
            from £171.79
            from £171.79
            HYDRO-MOUNTING Genuine Porsche Part - New (to order)
            # 7
            MPN: 99137505908
            HYDRO-MOUNTING
            HYDRO-MOUNTING
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 7
            MPN: 99137505909
            HYDRO-MOUNTING
            A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016) with, P140 (Dynamic engine mounts (PADM))
            Supersession
            Supersession
            This part replaces part number 99137505908
            Genuine Porsche Part (no longer available to order)
            # 7
            MPN: 99137505922
            HYDRO-MOUNTING ALSO USE: 2X 991 375 261 00 D >>- 01.09.2016
            DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBCB (3.8 Litre 6 Cyliner Engine (606 Horsepower / 446 Kilowatt with Engine Code: DBCB and installed 05/2017-05/2020)
            HYDRO-MOUNTING Genuine Porsche Part - New (to order)
            # 7
            MPN: 99137505924
            hydro-mounting D - 02.09.2016>>
            hydro-mounting D - 02.09.2016>>
            from £1,197.75
            from £1,197.75
            HYDRO-MOUNTING Genuine Porsche Part - New In stock
            # 7
            MPN: 99137505925
            hydro-mounting D - 02.09.2016>>
            DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | P140 (Dynamic engine mounts (PADM))
            from £836.27
            from £836.27
            This part replaces part number 99137505924 which we have in stock
            HYDRAULIC MOUNT Genuine Porsche Part - New (to order)
            # 7
            MPN: 99137505986
            HYDRO-MOUNTING D >>- 18.07.2018
            HYDRO-MOUNTING D >>- 18.07.2018
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 7
            MPN: 99137505987
            hydro-mounting D >>- 18.07.2018 (use in pairs only)
            hydro-mounting D >>- 18.07.2018 (use in pairs only)
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 7
            MPN: 99137505991
            hydro-mounting D >>- 18.07.2018 (use in pairs only)
            GT2 RS, DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) | P140 (Dynamic engine mounts (PADM))
            from £982.75
            from £982.75
            HYDRO-MOUNTING Genuine Porsche Part - New (to order)
            # 7
            MPN: 99137505987
            hydro-mounting D - 19.07.2018>>
            hydro-mounting D - 19.07.2018>>
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 7
            MPN: 99137505991
            hydro-mounting D - 19.07.2018>>
            GT2 RS, DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) | P140 (Dynamic engine mounts (PADM))
            from £982.75
            from £982.75
            HYDRO-MOUNTING Genuine Porsche Part - New (to order)
            # 8
            MPN: N 90848405
            HEXAGON NUT M12X1,5
            from £2.53
            from £2.53
            HEX. NUT Genuine Porsche Part - New (to order)
            # 9
            MPN: 90038516701
            HEXAGON HEAD BOLT M8X35
            P without 140
            from £0.95
            from £0.95
            HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
            # 10
            MPN: 90038516801
            HEXAGON HEAD BOLT M8X65
            P140 (Dynamic engine mounts (PADM))
            from £1.39
            from £1.39
            HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
            # 11
            MPN: 9A110225101
            HEAT INSULATION
            from £23.97
            from £23.97
            heat deflector Genuine Porsche Part - New (to order)
            # 12
            MPN: N 10098811
            BOLT, HEX. HD. (COMBI.) M6X16 SELF-LOCKING
            from £0.69
            from £0.69
            BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
            # 13
            MPN: 90006011201
            THREADED PIN M10X80
            from £4.52
            from £4.52
            STUD Genuine Porsche Part - New (to order)
            # 14
            MPN: 90006011301
            THREADED PIN M10X140
            THREADED PIN M10X140
            from £5.74
            from £5.74
            STUD Genuine Porsche Part - New (to order)
            # 14
            MPN: PAF009399
            THREADED PIN M10X140
            from £5.11
            from £5.11
            THREADED PIN Genuine Porsche Part - New (to order)
            # 15
            MPN: 99137526100
            SHIM HYDRO-MOUNTING D >>- 01.09.2016
            DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020)
            from £8.77
            from £8.77
            SPACER WASHER Genuine Porsche Part - New (to order)
