porsche 2017 (991-2 turbo) fuel tank parts diagram

201-000 - FUEL TANK

Porsche 2017 (991-2 Turbo) Fuel tank Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Key
                        Price
                        # 1
                        MPN: 99162083300
                        SENDER FOR FUEL GAUGE FUEL TANK
                        A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016)
                        from £179.34
                        from £179.34
                        FUEL GAUGE Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 99162083301
                        SENDER FOR FUEL GAUGE FUEL TANK
                        DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020)
                        from £231.18
                        from £231.18
                        FUEL GAUGE Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 99162083100
                        SENDER FOR FUEL GAUGE FUEL TANK
                        GT2 RS, DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020)
                        from £230.37
                        from £230.37
                        FUEL GAUGE Genuine Porsche Part - New (to order)
                        # 2
                        MPN: 99120162300
                        UNION NUT
                        from £8.26
                        from £8.26
                        UNION NUT Genuine Porsche Part - New (to order)
                        # 3
                        MPN: 99120142101
                        FLANGE D >>- MJ 2016
                        A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016)
                        from £228.27
                        from £228.27
                        FLANGE Genuine Porsche Part - New (to order)
                        # 3
                        MPN: 9P1201194A
                        FLANGE D - MJ 2017>>
                        DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020)
                        from £172.10
                        from £172.10
                        FLANGE Genuine Porsche Part - New (to order)
                        # 4
                        MPN: 99120173301
                        SEAL RING
                        from £9.51
                        from £9.51
                        SEAL RING Genuine Porsche Part - New In stock
                        # 5
                        MPN: 99162014500
                        FUEL PUMP ALSO USE: 1X 991 620 160 00
                        A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016) | DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020)
                        from £346.27
                        from £346.27
                        fuel pump Genuine Porsche Part - New (to order)
                        # 5
                        MPN: 9P1919087C
                        fuel pump
                        GT2 RS, DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020)
                        fuel pump Genuine Porsche Part - New (to order)
                        # 6
                        MPN: 1K0201557A
                        seal ring End cap
                        from £6.84
                        from £6.84
                        SEAL RING Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 99120102103
                        Fuel tank lhd
                        A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016) with, P098 (Left-hand drive version)
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 99120102105
                        Fuel tank lhd D >>- 10.06.2018
                        DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) with
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1201075E
                        FUEL TANK 64L D - 11.06.2018>>
                        DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | P098 (Left-hand drive version)
                        from £1,820.86
                        from £1,820.86
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1201075
                        FUEL TANK 64L D >>- 10.06.2018 GT2 RS
                        DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) | P098 (Left-hand drive version) | P without 082
                        from £1,437.11
                        from £1,437.11
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1201075C
                        FUEL TANK 64L D - 11.06.2018>>GT2 RS
                        DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) | P098 (Left-hand drive version) | P without 082
                        from £1,736.41
                        from £1,736.41
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1201075B
                        FUEL TANK 90L D >>- 10.06.2018 GT2 RS
                        DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) | P098 (Left-hand drive version) | P082 (Fuel tank, 90-litre)
                        from £1,541.49
                        from £1,541.49
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1201075F
                        FUEL TANK 90L D - 11.06.2018>>GT2 RS
                        DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) | P098 (Left-hand drive version) | P082 (Fuel tank, 90-litre)
                        from £2,038.62
                        from £2,038.62
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 99120102203
                        Fuel tank rhd
                        A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016) with, P099 (Right-hand drive version)
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 99120102205
                        FUEL TANK RHD D >>- 10.06.2018
                        DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) with, P099 (Right-hand drive version)
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1 201 076 A
                        Fuel tank rhd
                        DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020)
                        Fuel tank rhd Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1 201 076 D
                        Fuel tank rhd
                        DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020)
                        Fuel tank rhd Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1201076G
                        Fuel tank rhd
                        DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020)
                        from £1,900.59
                        from £1,900.59
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1201076B
                        FUEL TANK 64L D >>- 10.06.2018 GT2 RS
                        DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) | P099 (Right-hand drive version)
                        from £1,437.11
                        from £1,437.11
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 9P1201076E
                        FUEL TANK 64L D - 11.06.2018>>GT2 RS
                        DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) | P099 (Right-hand drive version)
                        from £1,852.08
                        from £1,852.08
                        FUEL TANK Genuine Porsche Part - New (to order)
                        # 8
                        MPN: 99120133102
                        UNDERSIDE PROTECTION
                        UNDERSIDE PROTECTION Genuine Porsche Part - New (to order)
                        # 9
                        MPN: 99120110701
                        TENSIONING STRAP
                        from £6.65
                        from £6.65
                        STRAP Genuine Porsche Part - New (to order)
                        # 9
                        MPN: 99120110701
                        TENSIONING STRAP
                        GT2 RS, DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) with, P082 (Fuel tank, 90-litre)
                        from £6.65
                        from £6.65
                        STRAP Genuine Porsche Part - New (to order)
                        # 10
                        MPN: N 0195307
                        Hex collared bolt M8X25
                        from £1.62
                        from £1.62
                        BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New In stock
                        HEXAGON FLANGE M8X25 Genuine Lamborghini - New In stock
                        # 11
                        MPN: 99120104410
                        FUEL FILLER NECK
                        A171 (3.8 Litre 6 Cyliner Engine (520 Horsepower / 383 Kilowatt with Engine Code: A171 and installed 05/2013-05/2016) with, P without 664
                        FILLER NECK Genuine Porsche Part - New (to order)
                        # 11
                        MPN: 99120104412
                        FUEL FILLER NECK
                        DABA (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DABA and installed 05/2016-05/2020) | DAB (3.8 Litre 6 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: DAB and installed 05/2017-05/2020) | DBCA (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBCA and installed 05/2016-05/2020) | DBC (3.8 Litre 6 Cyliner Engine (579 Horsepower / 426 Kilowatt with Engine Code: DBC and installed 05/2017-05/2020) with, P without 664
                        from £251.77
                        from £251.77
                        FILLER NECK Genuine Porsche Part - New (to order)
                        # 11
                        MPN: 99120104412
                        FUEL FILLER NECK
                        GT2 RS, DHNA (3.8 Litre 6 Cyliner Engine (700 Horsepower / 515 Kilowatt with Engine Code: DHNA and installed 05/2017-05/2020) with, P without 664, P082 (Fuel tank, 90-litre)
                        from £251.77
                        from £251.77
                        FILLER NECK Genuine Porsche Part - New (to order)
                        # 11
                        MPN: 99120104414
                        FUEL FILLER NECK D >>- 12.12.2019
                        from £131.76
                        from £131.76
                        FILLER NECK Genuine Porsche Part - New (to order)
                        # 11
                        MPN: 99120104416
                        FUEL FILLER NECK D - 13.12.2019>>
                        from £146.48
                        from £146.48
                        FUEL FILLER NECK Genuine Porsche Part - New (to order)
                        # 12
                        MPN: N 91096702
                        OVAL HEXAGON SOCKET HEAD BOLT M6X16
                        from £0.78
                        from £0.78
                        OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                        HEXALOBULAR SOCKETM6X16 Genuine Lamborghini - New In stock
                        # 13
                        MPN: 99120181200
                        HOSE
                        from £21.59
                        from £21.59
                        HOSE Genuine Porsche Part - New (to order)
                        # 13
                        MPN: 9P1201543
                        HOSE
                        from £24.93
                        from £24.93
                        HOSE Genuine Porsche Part - New (to order)
                        # 14
                        MPN: 99951274801
                        CLIP B43X12
                        from £2.47
                        from £2.47
                        CLAMP Genuine Porsche Part - New (to order)
                        # 15
                        MPN: 99120124101
                        CAP WITH RETAINING STRAP FOR FUEL TANK
                        P without XYB
                        from £16.26
                        from £16.26
                        FUEL TANK CAP Genuine Porsche Part - New (to order)
                        # 15
                        MPN: 00004400190
                        cap with retaining strap for aluminium fuel tank
                        cap with retaining strap for aluminium fuel tank
                        CAP WITH RETAINING STRAP FOR Genuine Porsche Part - New (to order)
                        # 15
                        MPN: 00004400191
                        cap with retaining strap for aluminium fuel tank
                        PXYB (Fuel tank cap in Aluminium Look)
                        from £130.00
                        from £130.00
                        TANK CAP IN ALUMINIUM LOOK Genuine Porsche Part - New (to order)
                        # 15
                        MPN: 9P1201550
                        cap with retaining strap for aluminium fuel tank
                        PXYB (Fuel tank cap in Aluminium Look)
                        from £55.92
                        from £55.92
                        CAP WITH RETAINING STRAP FOR Genuine Porsche Part - New (to order)
                        # 16
                        MPN: 99162016000
                        FUEL FILTER
                        from £307.90
                        from £307.90
                        FUEL FILTER Genuine Porsche Part - New (to order)
                        # 17
                        MPN: 99162012300
                        SUCTION JET PUMP
                        from £254.10
                        from £254.10
                        SUCTION PUMP Genuine Porsche Part - New (to order)
                        # 18
                        MPN: 00004320902
                        MULTI-PURPOSE ADDITIVE 100ML FOR OTTO ENGINE FUELS
                        from £10.04
                        from £10.04
                        MULTI-PURPOSE ADDITIVE - FOR OTTO ENGINE FUELS Genuine Porsche Part - New (to order)
