porsche 2020 (991-2 r/gt3/rs) door shell door lock parts diagram

804-000 - Door shell Door lock

Porsche 2020 (991-2 R/GT3/RS) Door shell Door lock Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                      #
                                      Part number
                                      Description
                                      Key
                                      Price
                                      # 1
                                      MPN: 99153191101GRV
                                      DOOR SHELL LEFT D >>- MJ 2017 - PRIMED
                                      from £969.34
                                      from £969.34
                                      This part replaces part number 99153191101
                                      PRIMED Genuine Porsche Part - New (to order)
                                      # 1
                                      MPN: 9P1831051B GRV
                                      DOOR SHELL LEFT D - MJ 2018>>- PRIMED
                                      from £680.86
                                      from £680.86
                                      This part replaces part number 9P1831051B
                                      PRIMED Genuine Porsche Part - New (to order)
                                      # 1
                                      MPN: 99153191201GRV
                                      DOOR SHELL RIGHT D >>- MJ 2017 - PRIMED
                                      from £1,035.58
                                      from £1,035.58
                                      This part replaces part number 99153191201
                                      PRIMED Genuine Porsche Part - New (to order)
                                      # 1
                                      MPN: 9P1831052B GRV
                                      DOOR SHELL RIGHT D - MJ 2018>>- PRIMED
                                      Supersession
                                      Supersession
                                      This part replaces part number 9P1831052B
                                      Genuine Porsche Part (no longer available to order)
                                      # 2
                                      MPN: 99153131900
                                      HINGE LEFT
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 2
                                      MPN: 99153132000
                                      HINGE RIGHT
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 3
                                      MPN: 99907319201
                                      SOCKET HEAD BOLT M8X33-ASP
                                      SCREW, CHEESE HD Genuine Porsche Part - New (to order)
                                      # 4
                                      MPN: 99153715100
                                      DOOR CATCH
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 5
                                      MPN: 991537631001E0
                                      COVER LEFT DOOR CATCH - BLACK
                                      This part replaces part number 99153763100
                                      Black Genuine Porsche Part - New (to order)
                                      # 5
                                      MPN: 991537632001E0
                                      COVER RIGHT DOOR CATCH - BLACK
                                      This part replaces part number 99153763200
                                      Black Genuine Porsche Part - New (to order)
                                      # 6
                                      MPN: 99907604201
                                      HEXAGON NUT M6-S-SC
                                      HEX. NUT Genuine Porsche Part - New (to order)
                                      # 7
                                      MPN: 99907313801
                                      flat round head bolt M8X25-PA
                                      from £0.91
                                      from £0.91
                                      screw, round hd. - M 8 X 25 Genuine Porsche Part - New (to order)
                                      # 8
                                      MPN: 95853794700
                                      COVER CAP HINGE
                                      from £0.85
                                      from £0.85
                                      CAP Genuine Porsche Part - New (to order)
                                      # 9
                                      MPN: N 91017401
                                      COUNTERSUNK MULTI-POINT M8X22 SOCKET HEAD BOLT
                                      from £0.78
                                      from £0.78
                                      SCREW, COUNTERSUNK HD. WITH POLYGON Genuine Porsche Part - New (to order)
                                      TRIPLE SQUARE OVALM8X22 Genuine Lamborghini - New (to order)
                                      # 10
                                      MPN: 3C0837767A
                                      STRIKER
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 11
                                      MPN: WHT003688
                                      FILLISTER HEAD BOLT (COMBI.) M8X16
                                      from £1.06
                                      from £1.06
                                      FILL. HD. SCREW (COMBI.) Genuine Porsche Part - New (to order)
                                      # 12
                                      MPN: 991537831001E0
                                      SUPPORT LEFT WING - BLACK
                                      from £15.85
                                      from £15.85
                                      This part replaces part number 99153783100
                                      Black Genuine Porsche Part - New (to order)
                                      # 12
                                      MPN: 991537832001E0
                                      SUPPORT RIGHT WING - BLACK
                                      from £15.85
                                      from £15.85
                                      This part replaces part number 99153783200
                                      Black Genuine Porsche Part - New (to order)
                                      # 13
                                      MPN: 99907332202
                                      FILLISTER HD. BOLT M6X20
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 14
                                      MPN: 9A7 837 215 03
                                      Door lock left lhd D >>- MJ 2015
                                      P098 (Left-hand drive version)
                                      Door lock left lhd D >>- MJ 2015 Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 9A783721505
                                      DOOR LOCK LEFT LHD D - MJ 2015>>
                                      P098 (Left-hand drive version)
                                      from £193.53
                                      from £193.53
                                      This part replaces part number 8J1837015C
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 9A783721506
                                      DOOR LOCK LEFT
                                      P072 (Version for Mexico) | P074 (PAP left-hand drive version) | P075 (Chinese version) | P094, P553 (Version for USA, Canada) | P486 (6-speed GT sports manual transmission)
                                      from £193.53
                                      from £193.53
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 9A783721605
                                      DOOR LOCK RIGHT LHD
                                      P098 (Left-hand drive version)
                                      from £180.82
                                      from £180.82
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 9A783721606
                                      DOOR LOCK RIGHT
                                      P072 (Version for Mexico) | P074 (PAP left-hand drive version) | P075 (Chinese version) | P094, P486 (6-speed GT sports manual transmission) | P553 (Version for USA, Canada) | P098 (Left-hand drive version)
                                      from £180.82
                                      from £180.82
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 9A783741505
                                      DOOR LOCK LEFT RHD
                                      P099 (Right-hand drive version) | P094
                                      from £180.82
                                      from £180.82
                                      This part replaces part number 8J2837015C
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 9A783741605
                                      DOOR LOCK RIGHT RHD
                                      P099 (Right-hand drive version) | P486 (6-speed GT sports manual transmission)
                                      from £193.53
                                      from £193.53
                                      This part replaces part number 8J2837016C - and 1 more. Click to view details
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 4G1837015
                                      DOOR LOCK LEFT
                                      P098 (Left-hand drive version) | P250 (PDK transmission (dual clutch))
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 4G1837015A
                                      DOOR LOCK LEFT
                                      P072 (Version for Mexico) | P250 (PDK transmission (dual clutch)) | P094, P553 (Version for USA, Canada)
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 4G2837016
                                      DOOR LOCK RIGHT
                                      P099 (Right-hand drive version) | P250 (PDK transmission (dual clutch))
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 4G2837016A
                                      DOOR LOCK RIGHT
                                      P094, P099 (Right-hand drive version) | P250 (PDK transmission (dual clutch))
                                      from £100.78
                                      from £100.78
                                      DOOR LATCH Genuine Porsche Part - New (to order)
                                      # 15
                                      MPN: 99153731900
                                      BOWDEN CABLE DOOR LOCK
                                      from £11.04
                                      from £11.04
                                      BOWDEN CABLE Genuine Porsche Part - New (to order)
                                      # 16
                                      MPN: 99153704501
                                      DOOR LOCK COVER LHD (DRIVERS SIDE)
                                      P098 (Left-hand drive version)
                                      from £6.82
                                      from £6.82
                                      DOOR LOCK COVER Genuine Porsche Part - New (to order)
                                      # 16
                                      MPN: 99153704601
                                      DOOR LOCK COVER RHD (DRIVERS SIDE)
                                      P099 (Right-hand drive version)
                                      from £6.82
                                      from £6.82
                                      DOOR LOCK COVER Genuine Porsche Part - New (to order)
                                      # 17
                                      MPN: N 01021813
                                      HEXAGON BOLT M6X25
                                      from £0.47
                                      from £0.47
                                      SCREW, HEX. HD Genuine Porsche Part - New (to order)
                                      # 18
                                      MPN: 99908421203
                                      HEXAGON NUT M6
                                      from £0.91
                                      from £0.91
                                      HEX. NUT Genuine Porsche Part - New (to order)
                                      # 19
                                      MPN: 9P1837111 1E0
                                      Cover Door frame - Black
                                      This part replaces part number 9P1837111
                                      Black Genuine Porsche Part - New (to order)
                                      # 20
                                      MPN: 9P1837111A 1E0
                                      COVER EMERGENCY OPERATION DOOR FRAME - BLACK
                                      from £4.67
                                      from £4.67
                                      This part replaces part number 9P1837111A
                                      Black Genuine Porsche Part - New (to order)
