PG1F (8-speed automatic transmission) | PG1G (8-speed automatic transmission for four-wheel drive)
porsche 2019 (992-1) brake pedal for 8-speed automatic gearbox parts diagram

702-100 - Brake pedal for 8-speed automatic gearbox

Porsche 2019 (992-1) Brake pedal for 8-speed automatic gearbox Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: 992723115
              BRACKET
              PL0L (Left-hand drive)
              from £86.86
              from £86.86
              BRACKET Genuine Porsche Part - New (to order)
              # 1
              MPN: 992721115B
              BRACKET
              PL0R (Right-hand drive)
              from £72.01
              from £72.01
              BRACKET Genuine Porsche Part - New (to order)
              # 2
              MPN: N 90761103
              Hexagon collar nut M8 self-locking
              PL0L (Left-hand drive)
              from £1.26
              from £1.26
              SHOULDERED HEX. NUT, Genuine Porsche Part - New (to order)
              PREV.TORQUE TYPE Genuine Lamborghini - New (to order)
              # 2
              MPN: N 90761103
              Hexagon collar nut M8 self-locking
              PL0R (Right-hand drive)
              from £1.26
              from £1.26
              SHOULDERED HEX. NUT, Genuine Porsche Part - New (to order)
              PREV.TORQUE TYPE Genuine Lamborghini - New (to order)
              # 3
              MPN: N 02300314
              HEXAGON NUT, SELF-LOCKING M8
              from £1.26
              from £1.26
              HEX. NUT, SELF-LOCKING Genuine Porsche Part - New (to order)
              # 4
              -
              SEAL FIREWALL INCLUDED IN POSITION: 1
              # 5
              MPN: 992723139A
              BRAKE PEDAL CONTAINS ADDITIONAL POSITIONS: 11
              PL0L (Left-hand drive)
              from £126.01
              from £126.01
              BRAKE PEDAL Genuine Porsche Part - New (to order)
              # 5
              MPN: 992723141A
              BRAKE PEDAL
              PL0R (Right-hand drive)
              from £126.01
              from £126.01
              BRAKE PEDAL Genuine Porsche Part - New (to order)
              # 6
              MPN: 992721325
              BEARING SHAFT NO REPLACEMENT PART
              PIN Genuine Porsche Part - New (to order)
              # 7
              MPN: 9P1721173A
              PEDAL CAP
              PVF0 (Foot pedal unitstandard) | PVF2 (pedal cluster)
              from £103.97
              from £103.97
              PEDAL CAP Genuine Porsche Part - New (to order)
              # 8
              MPN: N 90887402
              FUSE PIN
              from £2.49
              from £2.49
              LOCK WASHER Genuine Porsche Part - New In stock
              # 9
              MPN: N 10642101
              Hex collared bolt M8X25
              from £0.66
              from £0.66
              BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
              HEXAGON FLANGE M8X25 Genuine Lamborghini - New In stock
              # 10
              MPN: 992723380A
              BUNGS
              PL0L (Left-hand drive)
              from £2.02
              from £2.02
              PLUG Genuine Porsche Part - New (to order)
              # 11
              MPN: 992721165
              SUPPORT
              from £5.60
              from £5.60
              SUPPORT Genuine Porsche Part - New (to order)
