porsche 2019 (992-1) overroll protection roll bar parts diagram

811-550 - overroll protection roll bar

Porsche 2019 (992-1) overroll protection roll bar Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: 992880310B
                RETAINING FRAME ROLL-OVER PROTECTION SYSTEM (COMPLETE)
                RETAINING FRAME ROLL-OVER PROTECTION SYSTEM (COMPLETE)
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 1
                MPN: 992880310D
                RETAINING FRAME ROLL-OVER PROTECTION SYSTEM (COMPLETE)
                from £1,665.59
                from £1,665.59
                This part replaces part number 992880310B - and 1 more. Click to view details
                retaining frame Roll-Over protection System - complete Genuine Porsche Part - New (to order)
                # 2
                MPN: PAF008611
                CABLE HOLDER
                from £3.42
                from £3.42
                CABLE HOLDER Genuine Porsche Part - New (to order)
                # 3
                MPN: PAF008845
                INT. SERRATION FLANGE SCREW M10X60
                from £2.68
                from £2.68
                INT. SERRATION FLANGE SCREW Genuine Porsche Part - New (to order)
                # 4
                MPN: 9P1880421
                Brace left front retaining frame
                from £44.19
                from £44.19
                cross support Genuine Porsche Part - New (to order)
                # 4
                MPN: 9P1880422
                BRACE RIGHT FRONT RETAINING FRAME
                from £44.19
                from £44.19
                cross support Genuine Porsche Part - New (to order)
                # 5
                MPN: PAF008148
                SHOULDERED BOLT M8X30
                from £0.82
                from £0.82
                SHOULDERED BOLT Genuine Porsche Part - New (to order)
                # 6
                MPN: 992880993
                BRACE LEFT REAR RETAINING FRAME
                from £42.60
                from £42.60
                cross support Genuine Porsche Part - New (to order)
                # 6
                MPN: 992880994
                BRACE RIGHT REAR RETAINING FRAME
                from £42.60
                from £42.60
                cross support Genuine Porsche Part - New (to order)
                # 7
                MPN: N 10827301
                FLAT HEAD MULTI-POINT M10X40 SOCKET BOLT D >>- 31.10.2024
                from £0.97
                from £0.97
                Flat head multi-point Genuine Porsche Part - New (to order)
                12-POINT SOCKET Genuine Lamborghini - New (to order)
                # 7
                MPN: 9A700861500
                HEXAGON BOLT M10X40 D - 01.11.2024>>
                from £2.62
                from £2.62
                SCREW, HEX. HD Genuine Porsche Part - New In stock
                # 8
                MPN: 9P1880433
                BRACE REAR RETAINING FRAME
                from £17.67
                from £17.67
                cross support Genuine Porsche Part - New (to order)
