porsche 2019 (992-1) a/c condenser air guide housing parts diagram

814-300 - A/C condenser Air guide housing

Porsche 2019 (992-1) A/C condenser Air guide housing Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                  #
                  Part number
                  Description
                  Key
                  Price
                  # 1
                  MPN: 992820411
                  A/C CONDENSER
                  from £366.32
                  from £366.32
                  air condtioner condenser Genuine Porsche Part - New (to order)
                  # 2
                  MPN: 992820860
                  SEALING FRAME A/C CONDENSER
                  from £34.98
                  from £34.98
                  SEALING FRAME Genuine Porsche Part - New (to order)
                  # 3
                  MPN: 992815217 OK1
                  AIR GUIDE CENTER - MATT BLACK
                  from £110.93
                  from £110.93
                  This part replaces part number 992815217
                  AIR DUCT centre matt black Genuine Porsche Part - New (to order)
                  # 4
                  MPN: 992815217A OK1
                  AIR GUIDE CENTER - MATT BLACK
                  from £110.93
                  from £110.93
                  This part replaces part number 992815217A
                  MATT BLACK Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 992815216 OK1
                  Air guide right - Matt black
                  from £100.32
                  from £100.32
                  This part replaces part number 992815216
                  AIR DUCT right matt black Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 992815216C OK1
                  Air guide right - Matt black
                  from £100.32
                  from £100.32
                  AIR GUIDE MATT BLACK Genuine Porsche Part - New (to order)
                  # 6
                  MPN: 992815215 OK1
                  Air guide left - Matt black
                  from £100.32
                  from £100.32
                  This part replaces part number 992815215
                  AIR DUCT left matt black Genuine Porsche Part - New (to order)
                  # 6
                  MPN: 992815215C OK1
                  Air guide left - Matt black
                  from £100.32
                  from £100.32
                  AIR GUIDE MATT BLACK Genuine Porsche Part - New (to order)
                  # 7
                  MPN: PAF008437
                  HEXAGON BOLT 6X20
                  from £0.95
                  from £0.95
                  SCREW, HEX. HD Genuine Porsche Part - New (to order)
                  # 8
                  MPN: 9A7820535
                  EXTERNAL TEMPERATURE SENSOR
                  from £28.54
                  from £28.54
                  This part replaces part number 8Z0820535A
                  EXTERNAL TEMPERATURE SENSOR Genuine Porsche Part - New (to order)
