porsche 2019 (992-1) starter alternator parts diagram

902-050 - Starter Alternator

Porsche 2019 (992-1) Starter Alternator Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Key
                        Price
                        # 1
                        MPN: 0PB911021
                        STARTER
                        STARTER
                        from £888.36
                        from £888.36
                        STARTER Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 0PB911021B
                        STARTER
                        STARTER
                        from £688.36
                        from £688.36
                        STARTER Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 0PB911021D
                        STARTER
                        from £652.38
                        from £652.38
                        STARTER Genuine Porsche Part - New (to order)
                        # 2
                        MPN: 9A700815900
                        TORX SCREW M10X35
                        from £4.52
                        from £4.52
                        TORX SCREW Genuine Porsche Part - New In stock
                        # 3
                        MPN: N 10609207
                        HEXAGON COLLAR NUT M8 LOCKNUT
                        from £0.47
                        from £0.47
                        This part replaces part number 90037700301
                        shouldered hex. nut Genuine Porsche Part - New (to order)
                        # 4
                        MPN: N 01508210
                        Hexagon collar nut M6 Hexagon nut
                        from £0.47
                        from £0.47
                        Genuine Porsche Part (no longer available to order)
                        HEXAGON FLANGE NUT M6 Genuine Lamborghini - New In stock
                        # 5
                        MPN: 0PB903018
                        ALTERNATOR D >>- MJ 2020
                        PD5S (6-cylinder SI engine 3.0 l/283 kW FSI BIT base engine is T6J)
                        from £1,105.68
                        from £1,105.68
                        ALTERNATOR Genuine Porsche Part - New (to order)
                        # 5
                        MPN: 0PB903018
                        ALTERNATOR D - MJ 2021>>
                        PD5S (6-cylinder SI engine 3.0 l/283 kW FSI BIT base engine is T6J) | PDW1 (6-cylinder SI engine 3.0 l/331 kW FSI BIT base engine is T87/T6J)
                        from £1,105.68
                        from £1,105.68
                        ALTERNATOR Genuine Porsche Part - New (to order)
                        # 6
                        MPN: 0PB903021
                        ALTERNATOR D >>- MJ 2020
                        PDW1 (6-cylinder SI engine 3.0 l/331 kW FSI BIT base engine is T87/T6J)
                        from £1,008.60
                        from £1,008.60
                        ALTERNATOR Genuine Porsche Part - New (to order)
                        # 6
                        MPN: 0PB903021 X
                        ALTERNATOR D >>- MJ 2020
                        PDW1 (6-cylinder SI engine 3.0 l/331 kW FSI BIT base engine is T87/T6J)
                        from £713.88
                        from £713.88
                        ALTERNATOR Genuine Porsche Part - New (to order)
                        # 7
                        MPN: PAF008155
                        HEXAGON HEAD BOLT BM8X90
                        from £2.29
                        from £2.29
                        This part replaces part number 90038510201
                        HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                        # 8
                        MPN: PAA971537
                        EARTH LINE ALTERNATOR
                        from £34.16
                        from £34.16
                        GROUND STRAP Genuine Porsche Part - New (to order)
                        # 9
                        MPN: PAF008145
                        HEXAGON HEAD BOLT M8
                        from £0.69
                        from £0.69
                        HEXAGON HEAD BOLT Genuine Porsche Part - New In stock
                        # 10
                        MPN: PAA971793
                        WIRING HARNESS FOR BATTERY +, STARTER AND ALTERNATOR D >>- MJ 2020
                        PDW1 (6-cylinder SI engine 3.0 l/331 kW FSI BIT base engine is T87/T6J)
                        from £102.19
                        from £102.19
                        harness for battery +, Genuine Porsche Part - New (to order)
                        # 10
                        MPN: PAA971793A
                        WIRING HARNESS FOR BATTERY +, STARTER AND ALTERNATOR D >>- MJ 2020
                        PD5S (6-cylinder SI engine 3.0 l/283 kW FSI BIT base engine is T6J) | PDW2 (6-cylinder SI engine 3.0 l/272 kW FSI BIT base engine is T87)
                        from £102.19
                        from £102.19
                        harness for battery +, Genuine Porsche Part - New (to order)
                        # 10
                        MPN: PAA971793A
                        WIRING HARNESS FOR BATTERY +, STARTER AND ALTERNATOR D - MJ 2021>>
                        PD5S (6-cylinder SI engine 3.0 l/283 kW FSI BIT base engine is T6J) | PDW2 (6-cylinder SI engine 3.0 l/272 kW FSI BIT base engine is T87) | PDW1 (6-cylinder SI engine 3.0 l/331 kW FSI BIT base engine is T87/T6J)
                        from £102.19
                        from £102.19
                        harness for battery +, Genuine Porsche Part - New (to order)
                        # 11
                        MPN: PAA971883
                        COVER CAP FOR STARTER
                        from £6.75
                        from £6.75
                        CAP Genuine Porsche Part - New (to order)
                        # 12
                        MPN: N 10609207
                        HEXAGON COLLAR NUT M8 LOCKNUT
                        from £0.47
                        from £0.47
                        This part replaces part number 90037700301
                        shouldered hex. nut Genuine Porsche Part - New (to order)
                        # 13
                        MPN: 992974524A
                        CABLE GUIDE WIRING HARNESS FOR BATTERY +, STARTER AND ALTERNATOR
                        from £31.45
                        from £31.45
                        WIRING CONDUIT Genuine Porsche Part - New (to order)
                        # 14
                        MPN: PAF008227
                        SOCKET HEAD BOLT M10X20
                        from £1.32
                        from £1.32
                        SCREW, CHEESE HD Genuine Porsche Part - New (to order)
                        # 15
                        MPN: 9A700812500
                        HEXAGON HEAD BOLT M6X16
                        from £0.82
                        from £0.82
                        This part replaces part number 90038500901
                        TORX SCREW Genuine Porsche Part - New (to order)
