porsche 2021 (992-1 gt3/rs/st) crankcase housing parts diagram

101-100 - CRANKCASE HOUSING

Porsche 2021 (992-1 GT3/RS/ST) Crankcase housing Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                            #
                                                            Part number
                                                            Description
                                                            Key
                                                            Price
                                                            # 1
                                                            MPN: 0PB101040
                                                            CRANKCASE HOUSING INCLUDED THREADED PIN D >>- 21.03.2024 USE ONLY IN CONJUNCTION WITH: 0PB 105 791
                                                            Supersession
                                                            Supersession
                                                            Genuine Porsche Part (no longer available to order)
                                                            # 1
                                                            MPN: 0PB 101 040 A
                                                            CRANKCASE HOUSING INCLUDED THREADED PIN D - 22.03.2024>>- 25.08.2024 USE ONLY IN CONJUNCTION WITH: 0PB 105 791
                                                            Supersession
                                                            Supersession
                                                            Genuine Porsche Part (no longer available to order)
                                                            # 1
                                                            MPN: 0PB 101 040 B
                                                            CRANKCASE HOUSING INCLUDED THREADED PIN D - 26.08.2024>>USE ONLY IN CONJUNCTION WITH: 0PD 105 638 A
                                                            from £5,862.87
                                                            from £5,862.87
                                                            This part replaces part number 0PB 101 040 A - and 1 more. Click to view details
                                                            CRANKCASE HOUSING INCLUDED THREADED PIN D - 26.08.2024>>USE ONLY IN CONJUNCTION WITH: 0PD 105 638 A Genuine Porsche Part - New (to order)
                                                            # 2
                                                            MPN: PAF008257
                                                            THREADED PIN M10X80
                                                            from £4.57
                                                            from £4.57
                                                            THREADED PIN Genuine Porsche Part - New (to order)
                                                            # 3
                                                            MPN: PAF009399
                                                            THREADED PIN M10X140
                                                            from £5.11
                                                            from £5.11
                                                            THREADED PIN Genuine Porsche Part - New (to order)
                                                            # 4
                                                            MPN: PAF008668
                                                            dowel sleeve 13M6X13
                                                            from £4.76
                                                            from £4.76
                                                            DOWEL SLEEVE Genuine Porsche Part - New (to order)
                                                            # 5
                                                            MPN: 014301153B
                                                            DOWEL SLEEVE 13X16X13,5
                                                            from £4.11
                                                            from £4.11
                                                            SLEEVE - 13 X 16 X13,5 Genuine Porsche Part - New (to order)
                                                            # 6
                                                            MPN: PAF008319
                                                            sealing plug M10X1X11
                                                            from £4.83
                                                            from £4.83
                                                            THREADED PLUG Genuine Porsche Part - New (to order)
                                                            # 7
                                                            MPN: PAF108405
                                                            SEAL RING 10X13,5 COPPER
                                                            from £1.78
                                                            from £1.78
                                                            SEAL RING Genuine Porsche Part - New (to order)
                                                            # 8
                                                            MPN: PAF008323
                                                            SEALING PLUG M20X1,5X18
                                                            from £7.03
                                                            from £7.03
                                                            This part replaces part number 99906303901
                                                            THREADED PLUG Genuine Porsche Part - New (to order)
                                                            # 9
                                                            MPN: PAF108404
                                                            SEAL RING 20X24 COPPER
                                                            from £4.72
                                                            from £4.72
                                                            SEAL RING Genuine Porsche Part - New (to order)
                                                            # 10
                                                            MPN: PAF008311
                                                            SEALING PLUG M30X1,5
                                                            from £8.05
                                                            from £8.05
                                                            THREADED PLUG Genuine Porsche Part - New (to order)
                                                            # 11
                                                            MPN: PAF108402
                                                            SEAL RING 30X36 COPPER
                                                            from £2.86
                                                            from £2.86
                                                            SEAL RING Genuine Porsche Part - New (to order)
                                                            # 12
                                                            MPN: PAF009446
                                                            SEALING PLUG M26X1,5
                                                            from £7.62
                                                            from £7.62
                                                            SEALING PLUG Genuine Porsche Part - New (to order)
                                                            # 13
                                                            MPN: PAF043812
                                                            SEAL RING 26X32 ALUMINIUM
                                                            from £4.37
                                                            from £4.37
                                                            SEAL RING Genuine Porsche Part - New (to order)
                                                            # 14
                                                            MPN: 0PB101157
                                                            END CAP
                                                            from £9.05
                                                            from £9.05
                                                            LID Genuine Porsche Part - New (to order)
                                                            # 15
                                                            MPN: 0PB101157A
                                                            END CAP M8X35
                                                            from £9.05
                                                            from £9.05
                                                            SEALING CAP Genuine Porsche Part - New (to order)
                                                            # 16
                                                            MPN: PAF008270
                                                            O-RING 12,00X3,00
                                                            from £3.10
                                                            from £3.10
                                                            This part replaces part number 99970756840
                                                            O-RING Genuine Porsche Part - New (to order)
                                                            # 17
                                                            MPN: PAF008141
                                                            HEXAGON HEAD BOLT M8X120 D >>- 21.03.2024
                                                            from £3.18
                                                            from £3.18
                                                            HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                                            # 18
                                                            MPN: WHT001703
                                                            HEXAGON HEAD BOLT M8X35
                                                            from £3.35
                                                            from £3.35
                                                            This part replaces part number 90038504201
                                                            HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                                            # 19
                                                            MPN: 9A700813000
                                                            HEXAGON HEAD BOLT M6X40
                                                            from £0.91
                                                            from £0.91
                                                            This part replaces part number 90038504501
                                                            TORX SCREW Genuine Porsche Part - New (to order)
                                                            # 20
                                                            MPN: PAF008127
                                                            HEXAGON HEAD BOLT M6X25
                                                            from £0.84
                                                            from £0.84
                                                            HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                                            # 21
                                                            MPN: WHT008240
                                                            Bolt with washer M10X195 Included Sealing plate
                                                            Bolt with washer M10X195 Included Sealing plate
                                                            from £10.54
                                                            from £10.54
                                                            BOLT WITH WASHER Genuine Porsche Part - New (to order)
                                                            # 21
                                                            MPN: PAF008240
                                                            Bolt with washer M10X195 Included Sealing plate
                                                            from £9.83
                                                            from £9.83
                                                            BOLT WITH WASHER Genuine Porsche Part - New (to order)
                                                            # 22
                                                            MPN: PAF008235
                                                            SEALING PLATE 10.3X21X3
                                                            from £5.19
                                                            from £5.19
                                                            SEALING PLATE Genuine Porsche Part - New (to order)
                                                            # 23
                                                            MPN: 0PB101453
                                                            REDUCING PIECE
                                                            from £5.02
                                                            from £5.02
                                                            ADAPTER Genuine Porsche Part - New (to order)
                                                            # 24
                                                            MPN: 0PB905377B
                                                            KNOCK SENSOR
                                                            KNOCK SENSOR
                                                            from £106.88
                                                            from £106.88
                                                            KNOCK SENSOR Genuine Porsche Part - New (to order)
                                                            # 24
                                                            MPN: 0PB905377C
                                                            KNOCK SENSOR
                                                            from £108.38
                                                            from £108.38
                                                            KNOCK SENSOR Genuine Porsche Part - New (to order)
                                                            # 25
                                                            MPN: WHT001703
                                                            HEXAGON HEAD BOLT M8X35
                                                            from £3.35
                                                            from £3.35
                                                            This part replaces part number 90038504201
                                                            HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                                            # 26
                                                            MPN: 0PB131528
                                                            BRACKET INCLUDED CLIP
                                                            from £67.81
                                                            from £67.81
                                                            BRACKET Genuine Porsche Part - New (to order)
                                                            # 27
                                                            MPN: PAF906816
                                                            CORRUGATED TUBE CLIP
                                                            from £0.47
                                                            from £0.47
                                                            CORRUGATED TUBE CLIP Genuine Porsche Part - New (to order)
                                                            # 28
                                                            -
                                                            CHANGE-OVER VALVE SEE ILLUSTRATION: 107-400
                                                            # 29
                                                            MPN: PAF009480
                                                            THREADED INSERT M12X1,5
                                                            from £6.10
                                                            from £6.10
                                                            THREADED INSERT Genuine Porsche Part - New (to order)
                                                            # 30
                                                            MPN: 0PB906054
                                                            OIL TEMPERATURE AND OIL PRESSURE SENDER
                                                            from £98.00
                                                            from £98.00
                                                            OIL TEMPERATURE AND Genuine Porsche Part - New (to order)
                                                            # 31
                                                            MPN: 00004330533
                                                            SEALANT 75ML CRANKCASE HOUSING
                                                            from £45.65
                                                            from £45.65
                                                            SEALANT Genuine Porsche Part - New (to order)
