porsche 2021 (992-1 gt3/rs/st) wishbone rear axle parts diagram

501-060 - Wishbone Rear axle

Porsche 2021 (992-1 GT3/RS/ST) Wishbone Rear axle Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                              #
                              Part number
                              Description
                              Key
                              Price
                              # 1
                              MPN: 9GT505397A
                              Wishbone upper Rear axle
                              from £293.90
                              from £293.90
                              WISHBONE Genuine Porsche Part - New (to order)
                              # 2
                              MPN: PAF009972
                              HEXAGON BOLT M12X1,5X95 REAR AXLE
                              from £8.72
                              from £8.72
                              HEXAGON BOLT Genuine Porsche Part - New (to order)
                              # 3
                              MPN: PAF909664
                              HEXAGON COLLAR NUT M12X1,5 SELF-LOCKING
                              from £1.78
                              from £1.78
                              This part replaces part number N 90966402
                              SHOULDERED HEX. NUT, Genuine Porsche Part - New (to order)
                              # 4
                              MPN: 9GT505477
                              BRACE LEFT SIDE PART
                              from £80.80
                              from £80.80
                              BRACE Genuine Porsche Part - New (to order)
                              BRACE Genuine Porsche Part - Used In stock
                              # 4
                              MPN: 9GT505478
                              BRACE RIGHT SIDE PART
                              from £80.80
                              from £80.80
                              BRACE Genuine Porsche Part - New (to order)
                              BRACE Genuine Porsche Part - Used In stock
                              # 5
                              MPN: 9GT505237A
                              TRAILING ARM UPPER REAR AXLE
                              from £263.72
                              from £263.72
                              TRAILING ARM Genuine Porsche Part - New (to order)
                              # 6
                              MPN: 9A700867700
                              HEXAGON BOLT M12X1,5X80
                              from £5.09
                              from £5.09
                              This part replaces part number 99907286801
                              SCREW, HEX. HD Genuine Porsche Part - New (to order)
                              # 7
                              MPN: 9GT616571A
                              LEVEL SENSOR LEFT REAR AXLE
                              from £229.09
                              from £229.09
                              LEVEL SENSOR Genuine Porsche Part - New (to order)
                              # 7
                              MPN: 9GT616572A
                              Level sensor right Rear axle
                              from £229.09
                              from £229.09
                              LEVEL SENSOR Genuine Porsche Part - New (to order)
                              # 8
                              MPN: N 10005306
                              hexagon head bolt (combi) M6X12 Bolt with washer
                              from £0.79
                              from £0.79
                              BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
                              HEXAGON HEAD BOLT (COMBI) Genuine Bentley Part - New (to order)
                              # 9
                              MPN: N 10717601
                              HEX COLLARED BOLT M6X32 HEXAGON BOLT
                              from £1.04
                              from £1.04
                              BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                              HEX COLLARED BOLT Genuine Bentley Part - New (to order)
                              # 10
                              MPN: PAF015082
                              HEXAGON COLLAR NUT M6
                              from £1.58
                              from £1.58
                              This part replaces part number N 01508210
                              shouldered hex. nut Genuine Porsche Part - New In stock
                              # 11
                              MPN: 9GT505223C
                              TRAILING ARM LOWER
                              from £465.44
                              from £465.44
                              TRAILING ARM Genuine Porsche Part - New (to order)
                              # 12
                              MPN: 9GT615457
                              AIR GUIDE LEFT
                              from £20.65
                              from £20.65
                              AIR GUIDE Genuine Porsche Part - New (to order)
                              AIR GUIDE Genuine Porsche Part - Used In stock
                              # 12
                              MPN: 9GT615458
                              AIR GUIDE RIGHT
                              from £37.54
                              from £37.54
                              AIR GUIDE Genuine Porsche Part - New (to order)
                              # 13
                              MPN: PAF107388
                              TORX M6X35 LENS FLANGE SCREW
                              from £1.62
                              from £1.62
                              SCREW Genuine Porsche Part - New (to order)
                              # 14
                              -
                              SUPPORT TRAILING ARM SEE ILLUSTRATION: 502-100
