porsche 2022 (992-1 gt3/rs/st) roof a-pillar gt3rs parts diagram

801-460 - Roof A-pillar GT3RS

Porsche 2022 (992-1 GT3/RS/ST) Roof A-pillar GT3RS Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # -
                          -
                          FASTENERS CAVITY PRESERVATIVE AGENT AUXILIARY MATERIAL CONSUMABLES SEE ILLUSTRATION: 801-020
                          # 1
                          MPN: 9GT817018P G2X
                          OUTER ROOF PANEL CFK - PRIMED/MEDIUM GREY
                          PE1T (RS version) | PQV0 (Without TV/SAT/DAB reception) | PQV3 (Digital radio reception (DAB)) | PQV4, PQV6 (Digital radio reception (DAB)) | P04A (Basic)
                          from £8,192.18
                          from £8,192.18
                          OUTER ROOF PANEL GRUNDIERT/MITTELGRAU Genuine Porsche Part - New (to order)
                          # 1
                          MPN: 9GT817018Q G2X
                          OUTER ROOF PANEL CFK - PRIMED/MEDIUM GREY
                          PE1T (RS version) | PQU8 (SAT radio reception, USA) | P04A (Basic)
                          from £8,215.18
                          from £8,215.18
                          OUTER ROOF PANEL GRUNDIERT/MITTELGRAU Genuine Porsche Part - New (to order)
                          # 1
                          MPN: 9GT817018K A3G
                          OUTER ROOF PANEL CARBON - CARBON GLOSS BLACK
                          PE1T (RS version) | PQV0 (Without TV/SAT/DAB reception) | PQV3 (Digital radio reception (DAB)) | PQV4, PQV6 (Digital radio reception (DAB)) | P04I (Weissach package)
                          from £9,479.05
                          from £9,479.05
                          OUTER ROOF PANEL CARBON GLOSS BLACK Genuine Porsche Part - New (to order)
                          # 1
                          MPN: 9GT817018L A3G
                          OUTER ROOF PANEL CARBON - CARBON GLOSS BLACK
                          PE1T (RS version) | PQU8 (SAT radio reception, USA) | P04I (Weissach package)
                          from £9,479.05
                          from £9,479.05
                          OUTER ROOF PANEL CARBON GLOSS BLACK Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 9GT819443 OK1
                          AIR DUCT LEFT ROOF - MATT BLACK
                          from £314.31
                          from £314.31
                          AIR DUCT MATT BLACK Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 9GT819444 OK1
                          AIR DUCT RIGHT ROOF - MATT BLACK
                          from £314.31
                          from £314.31
                          AIR DUCT MATT BLACK Genuine Porsche Part - New (to order)
                          # 3
                          MPN: 9GT817871
                          ADHESIVE TAPE AIR DUCT
                          from £26.86
                          from £26.86
                          ADHESIVE TAPE Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 992806712 YGRV
                          CROSS MEMBER SCUTTLE - PRIMED
                          from £355.97
                          from £355.97
                          This part replaces part number 992806712 Y
                          CROSS MEMBER COWL primed Genuine Porsche Part - New (to order)
                          # 5
                          MPN: 992810183 YGRV
                          REINFORCEMENT FOR A-PILLAR LEFT - PRIMED
                          from £283.31
                          from £283.31
                          This part replaces part number 992810183 Y
                          REINFORCEMENT FOR A-PILLAR PRIMED Genuine Porsche Part - New (to order)
                          # 5
                          MPN: 992810184 YGRV
                          REINFORCEMENT FOR A-PILLAR RIGHT - PRIMED
                          from £283.31
                          from £283.31
                          This part replaces part number 992810184 Y
                          PRIMED Genuine Porsche Part - New (to order)
                          # 6
                          MPN: 992809177BYGRV
                          REINFORCEMENT FOR A-PILLAR LEFT INNER - PRIMED
                          from £415.58
                          from £415.58
                          REINFORCEMENT FOR A-PILLAR PRIMED Genuine Porsche Part - New (to order)
                          # 6
                          MPN: 992809178BYGRV
                          REINFORCEMENT FOR A-PILLAR RIGHT INNER - PRIMED
                          from £415.58
                          from £415.58
                          REINFORCEMENT FOR A-PILLAR PRIMED Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 992809199 YGRV
                          REINFORCEMENT FOR A-PILLAR LEFT ROOF FRAME - PRIMED
                          from £207.76
                          from £207.76
                          This part replaces part number 992809199 Y
                          REINFORCEMENT FOR A-PILLAR PRIMED Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 992809200 YGRV
                          REINFORCEMENT FOR A-PILLAR RIGHT ROOF FRAME - PRIMED
                          from £207.76
                          from £207.76
                          This part replaces part number 992809200 Y
                          PRIMED Genuine Porsche Part - New (to order)
                          # 8
                          MPN: 992817121 YGRV
                          TRANSVERSE ROOF RACK FRONT - PRIMED
                          from £204.26
                          from £204.26
                          This part replaces part number 992817121 Y
                          PRIMED Genuine Porsche Part - New (to order)
                          # 9
                          MPN: 992817287 YGRV
                          Transverse roof rack rear - primed
                          from £176.61
                          from £176.61
                          This part replaces part number 992817287 Y
                          PRIMED Genuine Porsche Part - New (to order)
                          # 10
                          MPN: 9P1817667 Y
                          SEAL LEFT ROOF MODULE
                          from £176.54
                          from £176.54
                          This part replaces part number 99156690100
                          GASKET Genuine Porsche Part - New (to order)
                          # 10
                          MPN: 9P1817668 Y
                          SEAL RIGHT ROOF MODULE
                          from £176.54
                          from £176.54
                          GASKET Genuine Porsche Part - New (to order)
                          # 11
                          MPN: 9P1817667
                          SEAL LEFT (INSTALLED AS STANDARD)
                          from £45.77
                          from £45.77
                          GASKET ROOF Genuine Porsche Part - New (to order)
                          # 11
                          MPN: 9P1817668
                          SEAL RIGHT (INSTALLED AS STANDARD)
                          from £45.77
                          from £45.77
                          GASKET ROOF Genuine Porsche Part - New (to order)
                          # 12
                          MPN: 9GT819039
                          TRIM LEFT FRONT A-PILLAR
                          from £23.04
                          from £23.04
                          TRIM Genuine Porsche Part - New (to order)
                          # 12
                          MPN: 9GT819039A
                          TRIM RIGHT FRONT A-PILLAR
                          from £23.04
                          from £23.04
                          TRIM Genuine Porsche Part - New (to order)
