GC490 (6S Gearbox with Transmission Code: GC490 and installed 01/21-) | GC495 (6S Gearbox with Transmission Code: GC495 and installed 01/21-)
porsche 2023 (992-1 gt3/rs/st) manual gearbox coupling parts diagram

301-200 - Manual gearbox Coupling

Porsche 2023 (992-1 GT3/RS/ST) Manual gearbox Coupling Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: 9P1141117C
              COUPLING REPAIR SET
              GC490 (6S Gearbox with Transmission Code: GC490 and installed 01/21-)
              from £1,014.58
              from £1,014.58
              clutch Genuine Porsche Part - New (to order)
              # 1
              MPN: 9GT141015
              COUPLING REPAIR SET
              GC495 (6S Gearbox with Transmission Code: GC495 and installed 01/21-)
              from £3,727.25
              from £3,727.25
              COUPLING Genuine Porsche Part - New (to order)
              # 2
              MPN: PAF009242
              INT. SERRATION FLANGE SCREW BM8X19
              GC490 (6S Gearbox with Transmission Code: GC490 and installed 01/21-)
              from £6.88
              from £6.88
              This part replaces part number 99951010601
              INT. SERRATION FLANGE SCREW Genuine Porsche Part - New (to order)
              # 2
              MPN: PAF010315
              BOLT WITH WASHER M8X62
              GC495 (6S Gearbox with Transmission Code: GC495 and installed 01/21-)
              from £6.99
              from £6.99
              BOLT WITH WASHER Genuine Porsche Part - New (to order)
              # 3
              MPN: 012141165E
              RELEASE BEARING
              Supersession
              Supersession
              Genuine Porsche Part (no longer available to order)
              # 4
              MPN: 9P1141719
              CLUTCH OPERATING LEVER
              GC490 (6S Gearbox with Transmission Code: GC490 and installed 01/21-)
              from £39.67
              from £39.67
              CLUTCH OPERATING LEVER Genuine Porsche Part - New (to order)
              # 4
              MPN: 9GT141719
              CLUTCH OPERATING LEVER
              GC495 (6S Gearbox with Transmission Code: GC495 and installed 01/21-)
              from £54.00
              from £54.00
              CLUTCH OPERATING LEVER Genuine Porsche Part - New (to order)
              # 5
              MPN: 9P1141143
              SEAL RING
              from £1.96
              from £1.96
              SEAL RING Genuine Porsche Part - New In stock
              # 6
              MPN: 9P1141164
              CLIP
              from £11.68
              from £11.68
              CLAMP Genuine Porsche Part - New (to order)
              # 7
              MPN: 9P1141777
              BALL STUD
              GC490 (6S Gearbox with Transmission Code: GC490 and installed 01/21-)
              from £13.52
              from £13.52
              BALL PIN Genuine Porsche Part - New (to order)
              # 7
              MPN: 9GT141251
              BALL STUD
              GC495 (6S Gearbox with Transmission Code: GC495 and installed 01/21-)
              from £31.78
              from £31.78
              BALL STUD Genuine Porsche Part - New (to order)
              # 8
              MPN: 9P1141181
              GUIDE SLEEVE
              from £47.89
              from £47.89
              This part replaces part number 99611608701
              GUIDE SLEEVE Genuine Porsche Part - New (to order)
              # 9
              MPN: PAF106604
              SOCKET HEAD BOLT M8X22
              GC490 (6S Gearbox with Transmission Code: GC490 and installed 01/21-)
              from £2.86
              from £2.86
              SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
              # 9
              MPN: PAF106604
              SOCKET HEAD BOLT M8X22
              GC495 (6S Gearbox with Transmission Code: GC495 and installed 01/21-)
              from £2.86
              from £2.86
              SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
              # 10
              MPN: 00004330512
              GREASE 45 GRAMS COUPLING SLAVE CYLINDER MANUAL GEARBOX
              from £58.44
              from £58.44
              GREASE Genuine Porsche Part - New (to order)
              # 11
              -
              ** VERSION BEING PREPARED **
