porsche 2023 (992-1 gt3/rs/st) drive shaft parts diagram

501-100 - DRIVE SHAFT

Porsche 2023 (992-1 GT3/RS/ST) Drive shaft Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Key
                        Price
                        # 1
                        MPN: 9GT501201
                        DRIVE SHAFT
                        DRIVE SHAFT
                        from £615.67
                        from £615.67
                        DRIVE SHAFT Genuine Porsche Part - New (to order)
                        DRIVE SHAFT Genuine Porsche Part - Used In stock
                        # 1
                        MPN: 9GT501201C
                        DRIVE SHAFT
                        from £1,273.99
                        from £1,273.99
                        DRIVE SHAFT Genuine Porsche Part - New (to order)
                        # 2
                        MPN: PAF009845
                        HOSE CLIP
                        from £1.67
                        from £1.67
                        HOSE CLIP Genuine Porsche Part - New (to order)
                        # 3
                        MPN: 9GT501135B
                        Bellows Drive shaft
                        from £36.63
                        from £36.63
                        BELLOWS Genuine Porsche Part - New In stock
                        # 4
                        MPN: 9GT501161
                        CONSTANT VELOCITY JOINT
                        from £347.85
                        from £347.85
                        CONSTANT VELOCITY JOINT Genuine Porsche Part - New In stock
                        # 5
                        MPN: PAF010131
                        SECURING RING 30X1,5
                        from £1.73
                        from £1.73
                        SECURING RING Genuine Porsche Part - New (to order)
                        # 6
                        MPN: 9GT501147
                        END CAP CONSTANT VELOCITY JOINT
                        from £19.30
                        from £19.30
                        END CAP Genuine Porsche Part - New In stock
                        # 7
                        MPN: 95533219121
                        SPACER
                        from £1.68
                        from £1.68
                        PLATE Genuine Porsche Part - New (to order)
                        # 8
                        MPN: WHT008727
                        SOCKET HEAD BOLT DRIVE SHAFT
                        from £2.62
                        from £2.62
                        This part replaces part number 99907351701
                        SCREW, CHEESE HD Genuine Porsche Part - New (to order)
                        # 9
                        MPN: WHT007021
                        HEX. NUT, SELF-LOCKING WITH M22X1.5 WASHER
                        from £6.65
                        from £6.65
                        HEX. NUT, SELF-LOCKING WITH WASHER, M22 X 1.5 Genuine Porsche Part - New (to order)
                        HEX. NUT, SELF-LOCKING WITH WASHER Genuine Bentley Part - New (to order)
                        # 10
                        MPN: 00004321008
                        sealant Drive shaft 1 tube 20 gram
                        from £58.37
                        from £58.37
                        This part replaces part number 00004320536
                        SEALANT Genuine Porsche Part - New In stock
                        # 11
                        MPN: 00004330508
                        ASSEMBLY PASTE 100 GRAM DRIVE SHAFT
                        from £17.99
                        from £17.99
                        This part replaces part number 00004302000
                        ASSEMBLY PASTE Genuine Porsche Part - New (to order)
                        # 12
                        MPN: 00004330545
                        HIGH TEMPERATURE GREASE 100 GRAM DRIVE SHAFT
                        from £24.80
                        from £24.80
                        This part replaces part number 00004311001
                        GREASE DRIVE SHAFT Genuine Porsche Part - New (to order)
