porsche 2024 (992-2 gt3/rs/st) vacuum line parts diagram

604-050 - VACUUM LINE

Porsche 2024 (992-2 GT3/RS/ST) Vacuum line Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
      #
      Part number
      Description
      Price
      # 1
      MPN: 9GT611911J
      VACUUM LINE LEFT FRONT CONTAINS: PRESSURE SENSOR
      PA8G (GT3 version) | PL0L (Left-hand drive version)
      from £156.86
      from £156.86
      # 1
      MPN: 9GT611911H
      VACUUM LINE LEFT FRONT CONTAINS: PRESSURE SENSOR
      PA8G (GT3 version) | PL0R (Right-hand drive version)
      from £156.86
      from £156.86
      # 2
      MPN: 9GT611911K
      VACUUM LINE CENTER
      PA8G (GT3 version)
      from £31.48
      from £31.48
      # 3
      MPN: 95B616143
      BRACKET 4 POINT
      from £6.98
      from £6.98
      # 4
      MPN: 9GT611911L
      VACUUM LINE REAR CONTAINS ADDITIONAL POSITIONS: 5,6
      PA8G (GT3 version)
      from £57.85
      from £57.85
      # 5
      MPN: 99950774340
      CABLE HOLDER ** VERSION BEING PREPARED **
      PA8G (GT3 version)
      from £4.52
      from £4.52
      # 6
      MPN: N 10427801
      DOUBLE CLIP 16X10 LINE HOLDER ** VERSION BEING PREPARED **
      PA8G (GT3 version)
      from £2.12
      from £2.12
      # 7
      MPN: 9GT611449A
      HOSE BRACKET
      from £5.14
      from £5.14
