P0K1 (Hybrid propulsion system)
porsche 2025 (992-2) injection system high pressure pump high-pressure injector parts diagram

107-050 - Injection system high pressure pump high-pressure injector

Porsche 2025 (992-2) Injection system high pressure pump high-pressure injector Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                #
                                                                Part number
                                                                Description
                                                                Key
                                                                Price
                                                                # 1
                                                                MPN: 0PD127503B
                                                                FUEL LINE LOW PRESSURE
                                                                from £193.15
                                                                from £193.15
                                                                FUEL LINE Genuine Porsche Part - New (to order)
                                                                # 2
                                                                MPN: 0PD 127 531
                                                                FUEL HOSE CYLINDERS 1-3
                                                                FUEL HOSE CYLINDERS 1-3 Genuine Porsche Part - New (to order)
                                                                # 3
                                                                MPN: 0PD 127 532
                                                                FUEL HOSE CYLINDERS 4-6
                                                                FUEL HOSE CYLINDERS 4-6 Genuine Porsche Part - New (to order)
                                                                # 4
                                                                MPN: N 91020301
                                                                SPRING BAND CLAMP 14,5X12 HOSE CLAMP
                                                                from £1.00
                                                                from £1.00
                                                                SPRING CLIP Genuine Porsche Part - New (to order)
                                                                SPRING BAND CLAMP Genuine Bentley Part - New (to order)
                                                                SPRING CLAMP Genuine Lamborghini - New (to order)
                                                                # 5
                                                                MPN: 0PD127411
                                                                BRACKET CYLINDERS 1-3 FUEL LINE
                                                                from £8.29
                                                                from £8.29
                                                                BRACKET Genuine Porsche Part - New (to order)
                                                                # 6
                                                                MPN: PAB906054C
                                                                Pressure sensor Low pressure
                                                                from £80.74
                                                                from £80.74
                                                                PRESSURE SENSOR Genuine Porsche Part - New (to order)
                                                                # 7
                                                                MPN: 9A700812500
                                                                HEXAGON HEAD BOLT M6X16
                                                                from £0.82
                                                                from £0.82
                                                                This part replaces part number 90038500901
                                                                TORX SCREW Genuine Porsche Part - New (to order)
                                                                # 8
                                                                MPN: PAF008923
                                                                flat round head bolt M6X14
                                                                from £0.85
                                                                from £0.85
                                                                This part replaces part number 99907360101
                                                                SCREW, ROUND HD Genuine Porsche Part - New (to order)
                                                                # 9
                                                                MPN: 0PD127025
                                                                high pressure pump
                                                                from £616.08
                                                                from £616.08
                                                                high pressure pump Genuine Porsche Part - New (to order)
                                                                # 10
                                                                MPN: PAF10468702
                                                                Oval-head screw M8X20
                                                                from £1.41
                                                                from £1.41
                                                                OVAL-HEAD SCREW Genuine Porsche Part - New (to order)
                                                                # 11
                                                                MPN: 0PD127501
                                                                FUEL LINE CYLINDERS 1-3 HIGH PRESSURE
                                                                from £128.77
                                                                from £128.77
                                                                FUEL LINE Genuine Porsche Part - New (to order)
                                                                # 12
                                                                MPN: 0PD127509A
                                                                FUEL LINE CYLINDERS 4-6 HIGH PRESSURE
                                                                from £128.77
                                                                from £128.77
                                                                FUEL LINE Genuine Porsche Part - New (to order)
                                                                # 13
                                                                MPN: 0PD128371A
                                                                Fuel collection pipe cylinders 1-3
                                                                from £657.51
                                                                from £657.51
                                                                FUEL COLLECTION PIPE Genuine Porsche Part - New (to order)
                                                                # 14
                                                                MPN: 0PD128372A
                                                                Fuel collection pipe cylinders 4-6
                                                                from £657.51
                                                                from £657.51
                                                                FUEL COLLECTION PIPE Genuine Porsche Part - New (to order)
                                                                # 15
                                                                MPN: PAF909485
                                                                SOCKET HEAD BOLT WITH INNER M8X85X41 MULTIPOINT HEAD
                                                                from £2.06
                                                                from £2.06
                                                                SCREW Genuine Porsche Part - New (to order)
                                                                # 16
                                                                MPN: PAF913163
                                                                FLAT HEAD MULTI-POINT M6X22 SOCKET BOLT
                                                                from £1.15
                                                                from £1.15
                                                                FLAT HEAD MULTI-POINT SOCKET BOLT Genuine Porsche Part - New (to order)
                                                                # 17
                                                                MPN: 0PB128626
                                                                Retaining Clip
                                                                from £3.96
                                                                from £3.96
                                                                Retaining Clip Genuine Porsche Part - New (to order)
                                                                # 18
                                                                MPN: 0PB127219
                                                                SPACER RING
                                                                from £1.50
                                                                from £1.50
                                                                SPACER RING Genuine Porsche Part - New (to order)
                                                                # 19
                                                                MPN: PAF006121
                                                                O-RING
                                                                from £2.67
                                                                from £2.67
                                                                O-RING Genuine Porsche Part - New (to order)
                                                                # 20
                                                                MPN: 0PB127291A
                                                                RETAINING RING
                                                                from £2.35
                                                                from £2.35
                                                                RETAINING RING Genuine Porsche Part - New (to order)
                                                                # 21
                                                                MPN: 0PB128071
                                                                THRUST RING
                                                                from £3.14
                                                                from £3.14
                                                                THRUST RING Genuine Porsche Part - New (to order)
                                                                # 22
                                                                MPN: 0PB127199
                                                                SECURING RING
                                                                from £1.90
                                                                from £1.90
                                                                LOCK RING Genuine Porsche Part - New (to order)
                                                                # 23
                                                                MPN: 0PB825411
                                                                SEAL
                                                                from £2.98
                                                                from £2.98
                                                                SEAL STRIP Genuine Porsche Part - New In stock
                                                                # 24
                                                                MPN: 0PB127269
                                                                SEAL
                                                                from £3.22
                                                                from £3.22
                                                                GASKET Genuine Porsche Part - New In stock
                                                                # 25
                                                                MPN: 0PB127404
                                                                SEAL RING
                                                                from £2.35
                                                                from £2.35
                                                                SEAL RING Genuine Porsche Part - New In stock
                                                                # 26
                                                                MPN: 0PB128615C
                                                                HIGH-PRESSURE INJECTOR
                                                                from £151.77
                                                                from £151.77
                                                                This part replaces part number 0PB128615 - and 2 more. Click to view details
                                                                HIGH-PRESSURE INJECTOR Genuine Porsche Part - New (to order)
                                                                # 27
                                                                MPN: 992906051B
                                                                PRESSURE SENSOR
                                                                from £146.85
                                                                from £146.85
                                                                PRESSURE SENSOR Genuine Porsche Part - New (to order)
                                                                # 28
                                                                MPN: 0PD103723
                                                                COVER CYLINDERS 1-3
                                                                from £11.88
                                                                from £11.88
                                                                COVER Genuine Porsche Part - New (to order)
                                                                # 29
                                                                MPN: N 91097301
                                                                Hexagon socket flat M6X45 head bolt
                                                                from £1.10
                                                                from £1.10
                                                                HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                                                                HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
                                                                # 30
                                                                MPN: PAF008923
                                                                flat round head bolt M6X14
                                                                from £0.85
                                                                from £0.85
                                                                This part replaces part number 99907360101
                                                                SCREW, ROUND HD Genuine Porsche Part - New (to order)
                                                                # 31
                                                                -
                                                                ** VERSION BEING PREPARED **
