GC405 (6S Gearbox with Transmission Code: GC405 and installed 01/24-)
porsche 2025 (992-2) manual gearbox cooling system for gear oil parts diagram

301-110 - Manual gearbox Cooling system for gear oil

Porsche 2025 (992-2) Manual gearbox Cooling system for gear oil Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 1
                          MPN: 9P1317188
                          HOSE (COMPLETE)
                          from £12.27
                          from £12.27
                          HOSE LINE Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 9P1317233A
                          COOLING AGENT SHUT-OFF VALVE
                          from £30.32
                          from £30.32
                          COOLING AGENT SHUT-OFF VALVE Genuine Porsche Part - New (to order)
                          # 3
                          MPN: 9P1317830
                          RETAINER FOR VALVE
                          from £7.66
                          from £7.66
                          SUPPORT Genuine Porsche Part - New (to order)
                          # 4
                          MPN: PAF008124
                          HEXAGON HEAD BOLT BM6X12
                          from £2.66
                          from £2.66
                          This part replaces part number 90038504101
                          HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                          # 5
                          MPN: N 91068201
                          Hexagon socket flat M4X10 head bolt
                          from £0.47
                          from £0.47
                          HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                          HEXAGON SOCKET FLAT HEAD BOLT Genuine Bentley Part - New (to order)
                          HEXALOBULAR SOCKETM4X10 Genuine Lamborghini - New In stock
                          # 6
                          MPN: 9P1317186A
                          HOSE (COMPLETE)
                          from £48.66
                          from £48.66
                          HOSE Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 9A712109303
                          CABLE HOLDER
                          from £2.47
                          from £2.47
                          CABLE HOLDER Genuine Porsche Part - New (to order)
                          # 8
                          MPN: 992317215B
                          VACUUM LINE
                          from £32.32
                          from £32.32
                          VACUUM LINE Genuine Porsche Part - New (to order)
                          # 9
                          MPN: 99711066672
                          ELBOW FITTING
                          from £6.87
                          from £6.87
                          ELBOW Genuine Porsche Part - New (to order)
                          # 10
                          MPN: 99959140201
                          CLIP 9,00
                          from £0.78
                          from £0.78
                          CLAMP Genuine Porsche Part - New (to order)
                          # 11
                          MPN: 99951300340
                          CABLE TIES 4,8-360
                          from £2.24
                          from £2.24
                          tie wrap - steering gear Genuine Porsche Part - New (to order)
                          # 12
                          MPN: 95860683851
                          CABLE TIES
                          from £2.67
                          from £2.67
                          TIE WRAP Genuine Porsche Part - New (to order)
