porsche 2026 (992-2 gt3/rs/st) coolant cooling system front end parts diagram

105-300 - Coolant cooling system Front end

Porsche 2026 (992-2 GT3/RS/ST) Coolant cooling system Front end Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                  #
                                                  Part number
                                                  Description
                                                  Key
                                                  Price
                                                  # 1
                                                  MPN: 992121507
                                                  COOLANT PIPE FEED
                                                  from £88.39
                                                  from £88.39
                                                  water tube Genuine Porsche Part - New (to order)
                                                  water tube Genuine Porsche Part - Used In stock
                                                  # 2
                                                  MPN: 992121034
                                                  COOLANT PIPE RETURN
                                                  from £88.39
                                                  from £88.39
                                                  water tube Genuine Porsche Part - New (to order)
                                                  water tube Genuine Porsche Part - Used In stock
                                                  # 3
                                                  MPN: 992121106
                                                  Coolant hose feed
                                                  from £57.98
                                                  from £57.98
                                                  WATER HOSE Genuine Porsche Part - New (to order)
                                                  # 4
                                                  MPN: 992121105
                                                  COOLANT HOSE RETURN
                                                  from £57.98
                                                  from £57.98
                                                  WATER HOSE Genuine Porsche Part - New (to order)
                                                  # 5
                                                  MPN: 992121548
                                                  COOLANT HOSE
                                                  from £53.95
                                                  from £53.95
                                                  WATER HOSE Genuine Porsche Part - New (to order)
                                                  # 6
                                                  MPN: 992121098C
                                                  SPRING CLIP
                                                  from £1.28
                                                  from £1.28
                                                  SPRING CLIP Genuine Porsche Part - New (to order)
                                                  # 7
                                                  MPN: 992121240
                                                  BRACKET
                                                  from £7.26
                                                  from £7.26
                                                  BRACKET Genuine Porsche Part - New (to order)
                                                  # 8
                                                  MPN: 992121522A
                                                  BRACKET
                                                  from £6.23
                                                  from £6.23
                                                  BRACKET Genuine Porsche Part - New (to order)
                                                  BRACKET Genuine Porsche Part - Used In stock
                                                  # 9
                                                  MPN: 992121901G
                                                  DISTRIBUTOR TUBE LEFT
                                                  from £180.82
                                                  from £180.82
                                                  Distributor tube Genuine Porsche Part - New (to order)
                                                  # 9
                                                  MPN: 9GT121901
                                                  COOLANT PIPE LEFT
                                                  GT3RS
                                                  from £185.97
                                                  from £185.97
                                                  COOLANT PIPE Genuine Porsche Part - New (to order)
                                                  # 10
                                                  MPN: 992121902D
                                                  Distributor tube right
                                                  from £170.77
                                                  from £170.77
                                                  This part replaces part number 992121902C
                                                  Distributor tube Genuine Porsche Part - New (to order)
                                                  # 10
                                                  MPN: 9GT121902
                                                  COOLANT PIPE RIGHT
                                                  GT3RS
                                                  from £185.97
                                                  from £185.97
                                                  COOLANT PIPE Genuine Porsche Part - New (to order)
                                                  # 11
                                                  MPN: 992121232A
                                                  BRACKET
                                                  from £10.42
                                                  from £10.42
                                                  BRACKET Genuine Porsche Part - New (to order)
                                                  # 12
                                                  MPN: 992121235A
                                                  BRACKET
                                                  from £8.51
                                                  from £8.51
                                                  BRACKET Genuine Porsche Part - New (to order)
                                                  # 13
                                                  MPN: 992121241B
                                                  BRACKET
                                                  from £6.28
                                                  from £6.28
                                                  BRACKET Genuine Porsche Part - New (to order)
                                                  # 14
                                                  MPN: N 10717601
                                                  Hex collared bolt M6X32
                                                  from £1.34
                                                  from £1.34
                                                  BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                                  # 15
                                                  MPN: 9A700812500
                                                  HEXAGON HEAD BOLT M6X16
                                                  from £0.82
                                                  from £0.82
                                                  This part replaces part number 90038500901
                                                  TORX SCREW Genuine Porsche Part - New (to order)
                                                  # 16
                                                  MPN: 992121797A
                                                  Cross tube D >>- 02.02.2023
                                                  Cross tube D >>- 02.02.2023
                                                  from £58.53
                                                  from £58.53
                                                  CROSS TUBE Genuine Porsche Part - New (to order)
                                                  CROSS TUBE Genuine Porsche Part - Used In stock
                                                  # 16
                                                  MPN: 992121797B
                                                  Cross tube D - 03.02.2023>>
                                                  from £120.53
                                                  from £120.53
                                                  CROSS TUBE Genuine Porsche Part - New (to order)
                                                  # 17
                                                  MPN: 992121798A
                                                  Cross tube D >>- 02.02.2023
                                                  Cross tube D >>- 02.02.2023
                                                  from £106.41
                                                  from £106.41
                                                  CROSS TUBE Genuine Porsche Part - New (to order)
                                                  # 17
                                                  MPN: 992121798B
                                                  Cross tube D - 03.02.2023>>
                                                  from £120.53
                                                  from £120.53
                                                  This part replaces part number 992121798
                                                  CROSS TUBE Genuine Porsche Part - New (to order)
                                                  # 18
                                                  MPN: 992121545
                                                  COOLANT HOSE
                                                  from £29.28
                                                  from £29.28
                                                  WATER HOSE Genuine Porsche Part - New (to order)
                                                  WATER HOSE Genuine Porsche Part - Used In stock
                                                  # 19
                                                  MPN: 992121546
                                                  COOLANT HOSE
                                                  from £52.41
                                                  from £52.41
                                                  WATER HOSE Genuine Porsche Part - New (to order)
                                                  # 20
                                                  MPN: 992121233
                                                  BRACKET
                                                  from £8.51
                                                  from £8.51
                                                  BRACKET Genuine Porsche Part - New (to order)
                                                  # 21
                                                  MPN: 95860662320
                                                  TEMPERATURE SENSOR ALSO USE: 1X WHT 002 287 B
                                                  from £82.32
                                                  from £82.32
                                                  TEMPERATURE SENDER Genuine Porsche Part - New (to order)
                                                  # 22
                                                  MPN: WHT002287B
                                                  O-RING 5,6X2
                                                  from £2.76
                                                  from £2.76
                                                  O-RING Genuine Porsche Part - New (to order)
                                                  O-RING Genuine Lamborghini - New (to order)
                                                  # 23
                                                  MPN: N 10721401
                                                  oval hd. self-tapp fitt. screw TP6X16
                                                  from £0.47
                                                  from £0.47
                                                  TAPPING SCREW, FILL. HD Genuine Porsche Part - New In stock
                                                  SCREW TP6X16-Q Genuine Lamborghini - New In stock
                                                  # 24
                                                  MPN: 992121455B
                                                  breather line
                                                  from £28.06
                                                  from £28.06
                                                  breather line Genuine Porsche Part - New (to order)
                                                  # 24
                                                  MPN: 9GT121455
                                                  breather line
                                                  GT3RS
                                                  from £97.40
                                                  from £97.40
                                                  breather line Genuine Porsche Part - New (to order)
                                                  # 25
                                                  MPN: 992121456A
                                                  breather line
                                                  from £13.11
                                                  from £13.11
                                                  breather line Genuine Porsche Part - New (to order)
                                                  breather line Genuine Porsche Part - Used In stock
                                                  # 26
                                                  MPN: 992121129
                                                  BRACKET
                                                  from £4.12
                                                  from £4.12
                                                  This part replaces part number 99110651202
                                                  BRACKET Genuine Porsche Part - New (to order)
                                                  # 27
                                                  MPN: 9A712132604
                                                  Spring band clamp B44X12
                                                  from £2.18
                                                  from £2.18
                                                  SPRING CLIP Genuine Porsche Part - New (to order)
                                                  # 28
                                                  MPN: 9A7145917
                                                  Spring band clamp B36X12
                                                  from £1.58
                                                  from £1.58
                                                  SPRING BAND CLAMP Genuine Porsche Part - New (to order)
                                                  # 29
                                                  -
                                                  ** VERSION BEING PREPARED **
                                                  # 30
                                                  MPN: 9GT 121 476 A
                                                  Breather line 9GT121476A D >>- 20.07.2022
                                                  Breather line 9GT121476A D >>- 20.07.2022
                                                  Breather line 9GT121476A D >>- 20.07.2022 Genuine Porsche Part - New (to order)
                                                  # 30
                                                  MPN: 9GT121476C
                                                  BREATHER LINE D - 21.07.2022>>
                                                  from £108.55
                                                  from £108.55
                                                  breather line Genuine Porsche Part - New (to order)
                                                  # 30
                                                  MPN: 9GT121476C
                                                  breather line
                                                  GT3RS, S/T
                                                  from £108.55
                                                  from £108.55
                                                  breather line Genuine Porsche Part - New (to order)
