porsche 2026 (992-2 gt3/rs/st) injection system high pressure pump high-pressure injector parts diagram

107-000 - Injection system high pressure pump high-pressure injector

Porsche 2026 (992-2 GT3/RS/ST) Injection system high pressure pump high-pressure injector Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                  #
                                  Part number
                                  Description
                                  Key
                                  Price
                                  # 1
                                  MPN: 9GT128373
                                  FUEL COLLECTION PIPE
                                  from £625.14
                                  from £625.14
                                  Z VERTEILERLEISTE Genuine Porsche Part - New (to order)
                                  # 2
                                  MPN: 9GT128615A
                                  HIGH-PRESSURE INJECTOR ALSO USE: 9GT 198 037
                                  from £244.45
                                  from £244.45
                                  HIGH-PRESSURE INJECTOR Genuine Porsche Part - New (to order)
                                  # 3
                                  MPN: 9GT198037
                                  REPAIR SET HIGH-PRESSURE INJECTOR CONTAINS: SEAL 3X SUPPORT WASHER 1X BINDER 1X 0PB 129 083
                                  from £52.33
                                  from £52.33
                                  This part replaces part number 9A111090890
                                  REPAIR SET Genuine Porsche Part - New (to order)
                                  # 4
                                  MPN: 0PB129083
                                  Binder
                                  from £6.24
                                  from £6.24
                                  Binder Genuine Porsche Part - New (to order)
                                  # 5
                                  MPN: 0PB129305
                                  LINE HOLDER
                                  from £24.54
                                  from £24.54
                                  LINE HOLDER Genuine Porsche Part - New (to order)
                                  # 6
                                  MPN: N 90627102
                                  SPEED NUT, SELF-LOCKING M6X23.9X16.5 SPEED NUT
                                  from £2.19
                                  from £2.19
                                  SPEED NUT, SELF-LOCKING Genuine Porsche Part - New (to order)
                                  SNAP NUT CLAMP Genuine Lamborghini - New (to order)
                                  # 7
                                  MPN: 9GT127501
                                  Fuel line cylinders 1-3
                                  Fuel line cylinders 1-3
                                  from £125.33
                                  from £125.33
                                  FUEL LINE Genuine Porsche Part - New (to order)
                                  # 7
                                  MPN: 9GT127501A
                                  Fuel line cylinders 1-3
                                  GT3 RS, S/T
                                  from £169.49
                                  from £169.49
                                  FUEL LINE Genuine Porsche Part - New (to order)
                                  # 8
                                  MPN: 9GT127509
                                  Fuel line cylinders 4-6
                                  Fuel line cylinders 4-6
                                  from £116.24
                                  from £116.24
                                  FUEL LINE Genuine Porsche Part - New (to order)
                                  # 8
                                  MPN: 9GT127509A
                                  Fuel line cylinders 4-6
                                  GT3 RS, S/T
                                  from £169.49
                                  from £169.49
                                  FUEL LINE Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 9P1906051A
                                  PRESSURE SENSOR
                                  from £133.62
                                  from £133.62
                                  PRESSURE SENSOR Genuine Porsche Part - New (to order)
                                  # 10
                                  MPN: 9GT127023A
                                  high pressure pump cylinders 1-3 D >>- 29.03.2023
                                  from £687.76
                                  from £687.76
                                  high pressure pump Genuine Porsche Part - New (to order)
                                  # 10
                                  MPN: 9GT127023B
                                  HIGH PRESSURE PUMP CYLINDERS 1-3 D - 30.03.2023>>
                                  from £717.86
                                  from £717.86
                                  high pressure pump Genuine Porsche Part - New (to order)
                                  # 11
                                  MPN: 9GT127024A
                                  high pressure pump cylinders 4-6 D >>- 29.03.2023
                                  high pressure pump cylinders 4-6 D >>- 29.03.2023
                                  from £539.87
                                  from £539.87
                                  high pressure pump Genuine Porsche Part - New (to order)
                                  # 11
                                  MPN: 9GT127024B
                                  HIGH PRESSURE PUMP CYLINDERS 4-6 D - 30.03.2023>>
                                  from £717.86
                                  from £717.86
                                  high pressure pump Genuine Porsche Part - New (to order)
                                  # 12
                                  MPN: 0PB129119A
                                  SEAL RING HIGH PRESSURE PUMP
                                  from £8.22
                                  from £8.22
                                  SEAL RING Genuine Porsche Part - New (to order)
                                  # 13
                                  MPN: PAF10413408
                                  Oval-head screw M6X25
                                  from £0.87
                                  from £0.87
                                  OVAL-HEAD SCREW Genuine Porsche Part - New (to order)
                                  # 14
                                  -
                                  TAPPETS SEE ILLUSTRATION: 103-100
                                  # 15
                                  MPN: 0PB127503L
                                  FUEL LINE LOW PRESSURE D >>- 20.07.2022
                                  from £278.99
                                  from £278.99
                                  FUEL LINE Genuine Porsche Part - New (to order)
                                  # 15
                                  MPN: 0PB127503K
                                  FUEL LINE LOW PRESSURE D - 21.07.2022>>
                                  from £278.99
                                  from £278.99
                                  FUEL LINE Genuine Porsche Part - New (to order)
                                  # 15
                                  MPN: 0PB127503K
                                  FUEL LINE LOW PRESSURE
                                  GT3 RS, S/T
                                  from £278.99
                                  from £278.99
                                  FUEL LINE Genuine Porsche Part - New (to order)
                                  # 16
                                  MPN: PAC906051B
                                  Pressure sensor Low pressure
                                  from £83.58
                                  from £83.58
                                  PRESSURE SENSOR Genuine Porsche Part - New (to order)
                                  # 17
                                  MPN: PAF008126
                                  HEXAGON HEAD BOLT M6X20
                                  from £0.85
                                  from £0.85
                                  This part replaces part number 90038501901
                                  HEXAGON HEAD BOLT Genuine Porsche Part - New In stock
                                  # 18
                                  MPN: PAF008124
                                  HEXAGON HEAD BOLT M6X12
                                  from £2.66
                                  from £2.66
                                  This part replaces part number 90038504101
                                  HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                  # 19
                                  MPN: PAF008139
                                  HEXAGON HEAD BOLT M8X12
                                  from £0.91
                                  from £0.91
                                  HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                  # 20
                                  MPN: 00004320935
                                  SPECIAL LUBRICANT 400ML PRESSURE SENSOR DF 977 S AND FUEL LINE POS.7/8
                                  from £61.45
                                  from £61.45
                                  SPECIAL LUBRICANT Genuine Porsche Part - New (to order)
