P1LR (Standard front disc brake) | P1LS (Standard front disc brake)
porsche 2026 (992-2 gt3/rs/st) disc brake gg front axle gt3 rs parts diagram

602-010 - Disc brake GG Front axle GT3 RS

Porsche 2026 (992-2 GT3/RS/ST) Disc brake GG Front axle GT3 RS Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 1
                      MPN: 9GT615301G
                      BRAKE DISC LEFT ALSO USE: 1X 9GT 615 302 G 1X 9GT 698 151 T 1X 9P1 698 995 D >>- 25.01.2023
                      P1LR (Standard front disc brake) | P1LS (Standard front disc brake)
                      from £717.96
                      from £717.96
                      BRAKE DISC Genuine Porsche Part - New (to order)
                      # 1
                      MPN: 9GT615301L
                      BRAKE DISC LEFT ALSO USE: 1X 9GT 615 302 L 1X 9GT 698 151 T 1X 9P1 698 995 D - 26.01.2023>>
                      P1LR (Standard front disc brake) | P1LS (Standard front disc brake)
                      from £835.94
                      from £835.94
                      BRAKE DISC Genuine Porsche Part - New (to order)
                      # 1
                      MPN: 9GT615302G
                      BRAKE DISC RIGHT ALSO USE: 1X 9GT 615 301 G 1X 9GT 698 151 T 1X 9P1 698 995 D >>- 25.01.2023
                      P1LR (Standard front disc brake) | P1LS (Standard front disc brake)
                      from £789.72
                      from £789.72
                      BRAKE DISC Genuine Porsche Part - New (to order)
                      # 1
                      MPN: 9GT615302L
                      BRAKE DISC RIGHT ALSO USE: 1X 9GT 615 301 L 1X 9GT 698 151 T 1X 9P1 698 995 D - 26.01.2023>>
                      P1LR (Standard front disc brake) | P1LS (Standard front disc brake)
                      from £835.94
                      from £835.94
                      BRAKE DISC Genuine Porsche Part - New (to order)
                      # 2
                      MPN: PAF009830
                      Hexagon socket head bolt, M6X8 self-locking
                      from £0.61
                      from £0.61
                      HEXAGON SOCKET HEAD BOLT, SELF-LOCKING Genuine Porsche Part - New (to order)
                      # 3
                      -
                      COVER PLATE SEE ILLUSTRATION: 401-050
                      # 5
                      MPN: 9GT615123J
                      CALIPER WITHOUT BRAKE PADS LEFT BLACK ALSO USE: 2X PAF 911 445 1X 9P1 698 995 1X 9GT 907 637
                      P1LS (Standard front disc brake)
                      from £1,233.02
                      from £1,233.02
                      CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                      # 5
                      MPN: 9GT615124J
                      CALIPER WITHOUT BRAKE PADS LEFT BLACK ALSO USE: 2X PAF 911 445 1X 9P1 698 995 1X 9GT 907 637
                      P1LS (Standard front disc brake)
                      from £1,267.45
                      from £1,267.45
                      CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                      # 5
                      MPN: 9GT615123K
                      CALIPER WITHOUT BRAKE PADS LEFT BLACK ALSO USE: 2X PAF 911 445 1X 9P1 698 995 1X 9GT 907 637
                      P1LR (Standard front disc brake) | P1LX (Front disc brake PCCB (EXC))
                      from £1,687.61
                      from £1,687.61
                      CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                      # 5
                      MPN: 9GT615124K
                      CALIPER WITHOUT BRAKE PADS RIGHT BLACK ALSO USE: 2X PAF 911 445 1X 9P1 698 995 1X 9GT 907 637
                      P1LR (Standard front disc brake) | P1LX (Front disc brake PCCB (EXC))
                      from £1,687.61
                      from £1,687.61
                      CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                      # 6
                      MPN: 9GT698151T
                      1 SET OF BRAKE PADS FOR DISK BRAKE ALSO USE: 1X PAF 911 445 1X 9P1 698 995 2X 9GT 907 637
                      from £572.24
                      from £572.24
                      1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
                      # 7
                      MPN: 9P1615701A
                      CONNECTING LINE LEFT FIXED CALLIPER
                      from £26.70
                      from £26.70
                      connecting line Genuine Porsche Part - New (to order)
                      # 7
                      MPN: 9P1615702
                      CONNECTING LINE RIGHT FIXED CALLIPER
                      from £26.70
                      from £26.70
                      connecting line Genuine Porsche Part - New (to order)
                      # 8
                      MPN: WHT008186
                      Socket head bolt M12X1,5X62
                      Socket head bolt M12X1,5X62
                      from £17.29
                      from £17.29
                      This part replaces part number 99906705409
                      SCREW, CHEESE HD Genuine Porsche Part - New (to order)
                      # 8
                      MPN: PAF911445
                      SOCKET HEAD BOLT WITH INNER M12X1,5X72 MULTIPOINT HEAD
                      from £6.36
                      from £6.36
                      SCREW Genuine Porsche Part - New (to order)
                      # 9
                      MPN: 9P1698995
                      1 SET SPRINGS
                      from £29.18
                      from £29.18
                      1 SET OF SPRINGS Genuine Porsche Part - New (to order)
                      # 10
                      MPN: 9GT907637
                      SENDER WIRE (PAD WEAR INDICATOR)
                      from £31.87
                      from £31.87
                      This part replaces part number 99160918180
                      SENDER WIRE PAD WEAR INDICATOR Genuine Porsche Part - New (to order)
                      # 11
                      MPN: 9P1698671D
                      1 SET PROTECTIVE CAPS 30 MM CONTAINS: 6 PCS
                      1 SET PROTECTIVE CAPS 30 MM CONTAINS: 6 PCS
                      from £13.50
                      from £13.50
                      1 set protective caps Genuine Porsche Part - New (to order)
                      # 11
                      MPN: 9P1698671A
                      1 SET PROTECTIVE CAPS 32 MM CONTAINS: 2 PARTS
                      from £13.66
                      from £13.66
                      1 set protective caps (4 pcs) Genuine Porsche Part - New (to order)
                      # 12
                      MPN: 211611483
                      DUST CAP CONTAINS: 20 PC
                      from £3.60
                      from £3.60
                      dust cap - D >> - MJ 1983 Genuine Porsche Part - New (to order)
                      DUST CAP Genuine Lamborghini - New (to order)
                      # 13
                      MPN: 8A0615273
                      1 SET BLEEDER VALVES WITH DUST CAP
                      from £9.05
                      from £9.05
                      BLEEDER VALVE Genuine Porsche Part - New (to order)
                      BLEEDER SCREW Genuine Lamborghini - New (to order)
                      # 14
                      MPN: 9P1615133A
                      CABLE HOLDER SENDER WIRE (PAD WEAR INDICATOR)
                      from £8.33
                      from £8.33
                      CABLE HOLDER Genuine Porsche Part - New (to order)
                      # 16
                      MPN: 00004330508
                      ASSEMBLY PASTE 1 TUBE 100 GRAM
                      from £17.99
                      from £17.99
                      This part replaces part number 00004302000
                      ASSEMBLY PASTE Genuine Porsche Part - New (to order)
