porsche 2026 (992-2 gt3/rs/st) a/c compressor r1234yf coolant parts diagram

814-200 - A/C compressor R1234yf coolant

Porsche 2026 (992-2 GT3/RS/ST) A/C compressor R1234yf coolant Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                    #
                    Part number
                    Description
                    Key
                    Price
                    # 1
                    MPN: 992260601GX
                    A/C COMPRESSOR EXCHANGE PARTS
                    from £879.61
                    from £879.61
                    A/C COMPRESSOR Genuine Porsche Part - New (to order)
                    # 2
                    MPN: PAF008143
                    HEXAGON HEAD BOLT M8X170
                    from £3.42
                    from £3.42
                    HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                    # 3
                    MPN: PAF008155
                    HEXAGON HEAD BOLT BM 8X90
                    from £2.29
                    from £2.29
                    This part replaces part number 90038510201
                    HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                    # 4
                    MPN: N 10414402
                    Socket head bolt with M8X28 hexagon socket head
                    from £1.62
                    from £1.62
                    BOLT, WITH HEX. SOCKET Genuine Porsche Part - New (to order)
                    HEXALOBULAR SOCKETM8X28-S10-N Genuine Lamborghini - New In stock
                    # 5
                    MPN: 9GT260350
                    SUCTION LINE
                    from £72.50
                    from £72.50
                    SUCTION LINE Genuine Porsche Part - New (to order)
                    # 6
                    MPN: 9GT260336
                    PRESSURE LINE
                    from £105.47
                    from £105.47
                    PRESSURE LINE Genuine Porsche Part - New (to order)
                    # 7
                    MPN: 9A757390000
                    COMPRESSOR OIL 250ML
                    from £71.73
                    from £71.73
                    COMPRESSOR OIL Genuine Porsche Part - New (to order)
                    # 8
                    MPN: 95557374903
                    O-RING 23,8X2,4
                    from £3.87
                    from £3.87
                    O-RING Genuine Porsche Part - New (to order)
                    # 9
                    MPN: 95557374901
                    O-RING 11X2,5
                    from £4.53
                    from £4.53
                    O-RING Genuine Porsche Part - New (to order)
