porsche 2026 (992-2 gt3/rs/st) air conditioning rear refrigerant line parts diagram

814-510 - Air conditioning rear Refrigerant line

Porsche 2026 (992-2 GT3/RS/ST) Air conditioning rear Refrigerant line Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                    #
                    Part number
                    Description
                    Key
                    Price
                    # 1
                    MPN: 9GT816527A
                    REFRIGERANT LINE
                    from £293.25
                    from £293.25
                    REFRIGERANT LINE Genuine Porsche Part - New (to order)
                    # 2
                    MPN: 9GT816524A
                    REFRIGERANT LINE
                    from £287.19
                    from £287.19
                    REFRIGERANT LINE Genuine Porsche Part - New (to order)
                    # 3
                    MPN: 9P1816767
                    BRACKET D12/D18
                    from £2.83
                    from £2.83
                    BRACKET Genuine Porsche Part - New (to order)
                    BRACKET Genuine Porsche Part - Used In stock
                    # 4
                    MPN: 9GT816570A
                    BRACKET FOR REFRIGERANT PIPE
                    from £17.66
                    from £17.66
                    BRACKET FOR REFRIGERANT PIPE Genuine Porsche Part - New (to order)
                    # 5
                    MPN: 992820881
                    BRACKET FOR REFRIGERANT PIPE
                    from £6.72
                    from £6.72
                    BRACKET FOR REFRIGERANT PIPE Genuine Porsche Part - New (to order)
                    # 6
                    MPN: 992816593A
                    BRACKET
                    from £7.22
                    from £7.22
                    BRACKET Genuine Porsche Part - New (to order)
                    # 7
                    MPN: N 10742702
                    OVAL HEXAGON SOCKET HEAD BOLT M8X25 ALUMINIUM
                    from £0.95
                    from £0.95
                    OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                    # 8
                    MPN: 95557374901
                    O-RING
                    from £4.53
                    from £4.53
                    O-RING Genuine Porsche Part - New (to order)
                    # 9
                    MPN: 95557374902
                    O-RING
                    from £4.32
                    from £4.32
                    O-RING Genuine Porsche Part - New (to order)
