porsche 2026 (992-2 gt3/rs/st) air conditioning front refrigerant line parts diagram

814-800 - Air conditioning front Refrigerant line

Porsche 2026 (992-2 GT3/RS/ST) Air conditioning front Refrigerant line Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 1
                          MPN: 992820411
                          A/C CONDENSER
                          from £366.32
                          from £366.32
                          air condtioner condenser Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 992820860
                          SEALING FRAME A/C CONDENSER
                          from £34.98
                          from £34.98
                          SEALING FRAME Genuine Porsche Part - New (to order)
                          # 3
                          MPN: 992816528C
                          REFRIGERANT LINE
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 4
                          MPN: 9GT816530
                          REFRIGERANT LINE CONDENSER
                          from £199.28
                          from £199.28
                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                          # 5
                          MPN: 992820761A
                          BRACKET FOR REFRIGERANT PIPE
                          from £8.72
                          from £8.72
                          This part replaces part number 992820761
                          BRACKET FOR REFRIGERANT PIPE Genuine Porsche Part - New (to order)
                          # 6
                          MPN: 971260197
                          BRACKET FOR REFRIGERANT PIPE
                          from £4.03
                          from £4.03
                          This part replaces part number 99157383700
                          BRACKET FOR REFRIGERANT PIPE Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 9P1816765
                          BRACKET FOR REFRIGERANT PIPE D10/D12
                          from £6.65
                          from £6.65
                          BRACKET FOR REFRIGERANT PIPE Genuine Porsche Part - New (to order)
                          # 8
                          MPN: PAF108488
                          COMBINATION HOLDER
                          from £4.82
                          from £4.82
                          COMBINATION HOLDER Genuine Porsche Part - New (to order)
                          # 9
                          MPN: N 10742702
                          OVAL HEXAGON SOCKET HEAD BOLT M8X25 ALUMINIUM
                          from £0.95
                          from £0.95
                          OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                          # 10
                          MPN: 95557374901
                          O-RING
                          from £4.53
                          from £4.53
                          O-RING Genuine Porsche Part - New (to order)
                          # 11
                          MPN: N 10414402
                          SOCKET HEAD BOLT WITH M8X28 HEXAGON SOCKET HEAD SOCKET HEAD BOLT
                          from £1.62
                          from £1.62
                          BOLT, WITH HEX. SOCKET Genuine Porsche Part - New (to order)
                          HEXALOBULAR SOCKETM8X28-S10-N Genuine Lamborghini - New In stock
                          # 12
                          MPN: PAF008437
                          HEXAGON BOLT 6X20
                          from £0.95
                          from £0.95
                          SCREW, HEX. HD Genuine Porsche Part - New (to order)
