103-011 - CAMSHAFT - TIMING CHAIN - D - MJ 2002>>
Porsche 1999 (996) CAMSHAFT - TIMING CHAIN - D - MJ 2002>> Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# -
-
SEE TECHNICAL INFORMATION - NR. 2/04 - SEE MAIN GROUP 1 (ENGINE)
# 1
MPN: 99610503500
CAMSHAFT - CYLINDER - 1 - 3
INLET
from £796.14
from £796.14
# 1
MPN: 99610503540
CAMSHAFT - CYLINDER - 1 - 3
inlet (PR:X51)
from £1,003.08
from £1,003.08
# 2
MPN: 99610526205
CAMSHAFT - CYLINDER - 1 - 3 - NO LONGER USE THE PART HERE
OUTLET
# 2
MPN: 99610505900
CAMSHAFT - CYLINDER - 1 - 3
OUTLET
# 3
MPN: 99610503600
CAMSHAFT - CYLINDER - 4 - 6
INLET
from £945.55
from £945.55
# 3
MPN: 99610503640
CAMSHAFT - CYLINDER - 4 - 6
inlet (PR:X51)
from £1,003.08
from £1,003.08
# 4
MPN: 99610526405
CAMSHAFT - CYLINDER - 4 - 6 - NO LONGER USE THE PART HERE
OUTLET
# 4
MPN: 99610506000
CAMSHAFT - CYLINDER - 4 - 6
OUTLET
# 5
MPN: 99610504172
HYDRAULIC TAPPET
OUTLET
from £55.40
from £55.40
# 6
MPN: 99610525520
HYDRAULIC TAPPET
INLET
# 7
MPN: 99610516803
TRACK
# 12
MPN: 99610590102
INTERMEDIATE SHAFT
# 13
MPN: 99610502401
BEARING CAP
from £134.86
from £134.86
# 14
MPN: 99970739240
O-RING - 7 X 2
from £2.68
from £2.68
# 15
MPN: 99921715009
SCREW, HEX. HD. - M 6 X 20 - DISCONTINUED PART
# 15
MPN: 90038509301
SCREW, HEX. HD. - M 6 X 20
from £1.04
from £1.04
# 16
MPN: 90038001902
HEX. NUT - M 8 X 1
# 17
MPN: 99610517156
TIMING CHAIN
Supersession
Supersession
# 18
MPN: 99610516555
TENSIONER BLADE
from £32.07
from £32.07
# 19
MPN: 99610519500
LINING
from £20.67
from £20.67
# 20
MPN: 90023404001
FITT WASHER - 10 X 16 X 1,2
from £0.65
from £0.65
# 21
MPN: 90004100401
LOCK RING - 10 X 1
from £0.59
from £0.59
# 22
MPN: 99610516651
GUIDE RAIL
from £38.83
from £38.83
# 23
MPN: 90007548601
BOLT WITH WASHER - AM 6 X 40
from £12.08
from £12.08
# 24
MPN: 99610518600
TENSIONER - CHAIN
# 25
MPN: 99970734440
O-Ring - 18,77 X 1,78
from £10.50
from £10.50
# 26
MPN: 99610515200
TIMING CHAIN
# 27
MPN: 99610517854
SPROCKET - WITH: - CARRIER
from £159.07
from £159.07
# 29
MPN: 90037824209
SCREW, HEX. HD. - M 6 X 12 - DISCONTINUED PART
# 30
MPN: 99610515600
TENSIONER BLADE - CYLINDER - 1 - 3
from £32.96
from £32.96
# 30
MPN: 99610515800
TENSIONER BLADE - CYLINDER - 4 - 6
# 31
MPN: 99610516252
SCREW - M 6
# 32
MPN: 99970734640
O-RING - 15 X 3
Supersession
Supersession
# 33
MPN: 99610505401
GUIDE RAIL - CYLINDER - 1 - 3
from £60.31
from £60.31
# 33
MPN: 99610516400
GUIDE RAIL - CYLINDER - 4 - 6
from £31.96
from £31.96
# 34
MPN: 99610518800
TENSIONER - CHAIN
# 35
MPN: 99610518055
tensioner - chain - Discontinued part
# 35
MPN: 99610518056
TENSIONER - CHAIN
# 36
MPN: 99610519700
THRUST PIN
from £38.25
from £38.25
# 37
MPN: 90012314730
SEAL RING - A 27 X 32
from £1.10
from £1.10
# 39
MPN: 99610511201
GASKET - SEE MAIN GROUP 1 (ENGINE) - NR. 10/00
from £17.12
from £17.12
# 40
MPN: 99610530102
ACTUATOR - DISCONTINUED PART
# 40
MPN: 99610530103
actuator - valve - Discontinued part
# 40
MPN: 99610530104
actuator - valve
Supersession
Supersession
# -
-
O-Ring - 21,00 X 3,00
# -
-
BRACKET
# -
-
cable holder - Discontinued part
# -
-
CABLE HOLDER
# 41
MPN: 99610530302
ACTUATOR - DISCONTINUED PART
# 41
MPN: 99610530305
ACTUATOR - CAMSHAFT - DISCONTINUED PART
Supersession
Supersession
# -
-
DOWEL PIN - ACTUATOR - CAMSHAFT
# -
-
O-RING
# -
-
BRACKET F.THROTTLE CONTR.ELEM.
# 42
MPN: 99610528050
ring - No longer use the part here
# 42
MPN: 99610528051
RING
from £15.47
from £15.47
# 43
MPN: 99610420506
BUSHING - DISCONTINUED PART
# 43
MPN: 99610420507
BUSHING
from £69.14
from £69.14
# 44
MPN: 99610520300
WASHER
from £19.31
from £19.31
# 45
MPN: 99610505103
CAMSHAFT ADJUSTER UNIT - CAMSHAFT - CYLINDER - 1 - 3
INLET
# 45
MPN: 99610505201
CAMSHAFT ADJUSTER UNIT - CAMSHAFT - CYLINDER - 4 - 6
INLET
# 46
MPN: 99610526001
INTERMEDIATE PIECE
# 47
MPN: 99610525400
SCREW, HEX. HD.
# -
-
EXTREME-PRESSURE GREASE - 1 TUBE - 80 GR. - FOR - CAMSHAFT
