201-000 - FUEL TANK
Porsche 2002 (996 Turbo / GT2) FUEL TANK Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 99620102101
FUEL TANK
LHD
from £989.14
from £989.14
# 1
MPN: 99620102190
FUEL TANK
lhd (GT2)
from £1,343.66
from £1,343.66
# 1
MPN: 99620102201
FUEL TANK
RHD
from £989.14
from £989.14
# 1
MPN: 99620102290
FUEL TANK
rhd (GT2)
from £1,343.66
from £1,343.66
# 2
MPN: 99620162300
UNION NUT
from £3.58
from £3.58
# 3
MPN: 321919133
SEAL RING
Supersession
Supersession
# 4
MPN: 99662010700
FUEL PUMP - DISCONTINUED PART
LHD
# 4
MPN: 99662010701
fuel pump - No longer use the part here
LHD
# 4
MPN: 99662010702
fuel pump
LHD
Supersession
Supersession
# 4
MPN: 99662010800
FUEL PUMP - DISCONTINUED PART
RHD
# 4
MPN: 99662010801
fuel pump - No longer use the part here
RHD
# 4
MPN: 99662010802
fuel pump
RHD
Supersession
Supersession
# 4
MPN: 99662005790
FUEL PUMP - DISCONTINUED PART
(GT2)
# 4
MPN: 99662005791
fuel pump - No longer use the part here
(GT2)
# 4
MPN: 99662005792
fuel pump
(GT2)
Supersession
Supersession
# 5
MPN: 99662082702
fuel gauge - sender
LHD
Supersession
Supersession
# 5
MPN: 99662080800
fuel gauge - sender
lhd (GT2)
Supersession
Supersession
# 5
MPN: 99662083202
fuel gauge - sender
rhd (GT2)
Supersession
Supersession
# 5
MPN: 99662082802
fuel gauge - sender
RHD
Supersession
Supersession
# 6
MPN: 99620133101
PROTECTIVE PLATE FOR - FUEL TANK
LHD
from £54.65
from £54.65
# 6
MPN: 99620133100
PROTECTIVE PLATE FOR - FUEL TANK
lhd (GT2)
from £81.20
from £81.20
# 6
MPN: 99620133102
PROTECTIVE PLATE FOR - FUEL TANK
rhd (GT2)
from £86.72
from £86.72
# 6
MPN: 99620133103
PROTECTIVE PLATE FOR - FUEL TANK
RHD
from £42.39
from £42.39
# 7
MPN: 99620110503
STRAP
from £49.92
from £49.92
# 7
MPN: 99620110502
STRAP
(GT2)
# 8
MPN: 99620110603
STRAP
from £26.71
from £26.71
# 8
MPN: 99620110602
STRAP
(GT2)
# 9
MPN: 99620110701
STRAP
LHD
from £52.99
from £52.99
# 9
MPN: 99620110790
STRAP
lhd (GT2)
from £52.99
from £52.99
# 9
MPN: 99620110800
STRAP
rhd (GT2)
from £34.82
from £34.82
# 10
MPN: 90007547909
BOLT WITH WASHER - M 8 X 40
Supersession
Supersession
# 11
MPN: 99620104303
FILLER NECK
from £281.10
from £281.10
# 11
MPN: 99620104304
FILLER NECK
(PR:150 \\J..\\)
from £205.88
from £205.88
# 11
MPN: 99620104309
FILLER NECK
rhd (GT2)
from £273.65
from £273.65
# 12
MPN: 99620114301
Bleed valve
from £168.57
from £168.57
# 13
MPN: 90037803609
SCREW, HEX. HD. - M 6 X 12
Supersession
Supersession
# 14
MPN: 99620124103
cap with retaining strap for - fuel tank - with: - Clip
from £11.90
from £11.90
# -
-
RIVET
# 15
MPN: 191201557
SEAL RING
from £12.37
from £12.37
# 16
MPN: 99620175500
SUPPORT WASHER
from £8.95
from £8.95
# 17
MPN: 99620175300
GASKET
from £8.95
from £8.95
# 18
MPN: 99620175100
BRACKET FOR FILLER NECK
from £21.46
from £21.46
# 19
MPN: 99620161300
breather line
from £86.03
from £86.03
# 20
MPN: 99662011300
SUCTION PUMP
from £264.79
from £264.79
# 20
MPN: 99662011380
SUCTION PUMP
(GT2)
from £264.79
from £264.79
# 28
MPN: 99662084190
Display specimen - Tank gauge
(GT2)
from £132.64
from £132.64
# 30
MPN: 00004320689
MULTI-PURPOSE ADDITIVE - FOR OTTO ENGINE FUELS - DISCONTINUED PART
CHINA-100ml
# 30
MPN: 00004320902
MULTI-PURPOSE ADDITIVE - FOR OTTO ENGINE FUELS
CHINA-100ml
from £10.13
from £10.13
