porsche 2007 (997-1 gt3) valve control parts diagram

103-016 - VALVE CONTROL

Porsche 2007 (997-1 GT3) VALVE CONTROL Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                  #
                  Part number
                  Description
                  Key
                  Price
                  # 1
                  MPN: 99710502092
                  camshaft
                  Intake | Cyl. 4 - 6
                  from £1,322.77
                  from £1,322.77
                  camshaft Genuine Porsche Part - New (to order)
                  # 2
                  MPN: 99710510890
                  camshaft
                  Exhaust | Cyl. 4 - 6
                  from £1,746.87
                  from £1,746.87
                  camshaft Genuine Porsche Part - New (to order)
                  # 3
                  MPN: 99710501992
                  camshaft
                  Intake | Cyl. 1 - 3
                  from £1,225.82
                  from £1,225.82
                  camshaft Genuine Porsche Part - New (to order)
                  # 4
                  MPN: 99710510790
                  camshaft
                  Exhaust | Cyl. 1 - 3
                  from £1,746.87
                  from £1,746.87
                  camshaft Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 99710505191
                  ACTUATOR
                  camshaft | Intake | Discontinued part
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 99710505193
                  ACTUATOR
                  camshaft | Intake | Discontinued part
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 99710505195
                  ACTUATOR
                  camshaft | Intake
                  from £943.40
                  from £943.40
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 99710505192
                  ACTUATOR
                  camshaft | Intake (9777)
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 99710505193
                  ACTUATOR
                  camshaft | Intake | discontinued part (9774)
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 99710505195
                  ACTUATOR
                  camshaft | Intake (9774)
                  from £943.40
                  from £943.40
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 6
                  MPN: 98710525400
                  SCREW, HEX. HD.
                  M 12 X 1,5 X 130
                  from £11.61
                  from £11.61
                  SCREW, HEX. HD. - FOR - CAMSHAFT ADJUSTER UNIT Genuine Porsche Part - New (to order)
                  # 7
                  MPN: 99710505391
                  ACTUATOR
                  camshaft | Exhaust | Cyl. 1 - 3 | No longer use the part here
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 7
                  MPN: 99710505392
                  ACTUATOR
                  camshaft | Exhaust | Cyl. 1 - 3 (9777)
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 7
                  MPN: 99710505393
                  ACTUATOR
                  camshaft | Exhaust | Cyl. 1 - 3 (9774)
                  from £980.79
                  from £980.79
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 8
                  MPN: 99710505491
                  ACTUATOR
                  camshaft | Exhaust | Cyl. 4 - 6 | No longer use the part here
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 8
                  MPN: 99710505492
                  ACTUATOR
                  camshaft | Exhaust | Cyl. 4 - 6 (9777)
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 8
                  MPN: 99710505493
                  ACTUATOR
                  camshaft | Exhaust | Cyl. 4 - 6 | Discontinued part (9774)
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 8
                  MPN: 99710505494
                  ACTUATOR
                  camshaft | Exhaust | Cyl. 4 - 6 (9774)
                  from £983.65
                  from £983.65
                  ACTUATOR Genuine Porsche Part - New (to order)
                  # 9
                  MPN: 99710526070
                  INTERMEDIATE PIECE
                  CAMSHAFT ADJUSTER UNIT
                  from £27.80
                  from £27.80
                  INTERMEDIATE PIECE Genuine Porsche Part - New (to order)
                  # 10
                  MPN: 99710522790
                  DRIVING DISK
                  VACUUM PUMP
                  from £738.88
                  from £738.88
                  DRIVING DISK Genuine Porsche Part - New (to order)
                  # 11
                  MPN: 9A110507100
                  HYDRAULIC TAPPET
                  Supersession
                  Supersession
                  Genuine Porsche Part (no longer available to order)
                  # 12
                  MPN: 99710531790
                  SCREW, CHEESE HD.
                  M12 x 1,5 x 130
                  from £49.02
                  from £49.02
                  SCREW, CHEESE HD Genuine Porsche Part - New (to order)
                  # 13
                  MPN: 99610528090
                  RING
                  from £25.69
                  from £25.69
                  RING Genuine Porsche Part - New (to order)
                  # 14
                  MPN: 99710520370
                  WASHER FOR CAMSHAFT
                  from £27.56
                  from £27.56
                  WASHER FOR CAMSHAFT Genuine Porsche Part - New (to order)
                  # 15
                  MPN: 95910591490
                  INTERMEDIATE SHAFT
                  with: | Timing gear (9777)
                  from £2,463.00
                  from £2,463.00
                  INTERMEDIATE SHAFT Genuine Porsche Part - New (to order)
                  # 15
                  MPN: 95910591492
                  INTERMEDIATE SHAFT
                  with: | Timing gear (9774)
                  from £2,463.00
                  from £2,463.00
                  INTERMEDIATE SHAFT Genuine Porsche Part - New (to order)
                  # 16
                  MPN: 90004102601
                  LOCK RING
                  13 X 1
                  from £1.28
                  from £1.28
                  lock ring - D >> - MJ 1968 Genuine Porsche Part - New (to order)
                  # 17
                  MPN: 99310527552
                  INTERMEDIATE PIECE
                  M18 x 1,5
                  Supersession
                  Supersession
                  Genuine Porsche Part (no longer available to order)
                  # 18
                  MPN: 90004102501
                  LOCK RING
                  36 X 1,75
                  from £2.68
                  from £2.68
                  lock ring - 36 X 1,75 - D - MJ 1969>> Genuine Porsche Part - New (to order)
                  # 19
                  MPN: 99610113780
                  MOUNTING
                  Supersession
                  Supersession
                  This part replaces part number 99310113701
                  Genuine Porsche Part (no longer available to order)
                  # 20
                  MPN: 99610143570
                  BEARING SHELL
                  from £23.07
                  from £23.07
                  BEARING SHELL Genuine Porsche Part - New In stock
                  # 21
                  MPN: 99610516571
                  TENSIONER BLADE
                  (9777)
                  from £45.08
                  from £45.08
                  TENSIONER BLADE Genuine Porsche Part - New (to order)
                  # 21
                  MPN: 99710516590
                  TENSIONER BLADE
                  (9774)
                  from £143.70
                  from £143.70
                  TENSIONER BLADE Genuine Porsche Part - New (to order)
                  # 22
                  MPN: 96410517103
                  PIN
                  from £25.69
                  from £25.69
                  PIN Genuine Porsche Part - New (to order)
                  # 23
                  MPN: 90012313130
                  SEAL RING
                  16 x 20
                  from £2.29
                  from £2.29
                  SEAL RING - DISCONTINUED PART Genuine Porsche Part - New In stock
                  # 24
                  MPN: 99610516770
                  GUIDE RAIL
                  LEFT
                  from £46.66
                  from £46.66
                  GUIDE RAIL Genuine Porsche Part - New (to order)
                  # 24
                  MPN: 99610516670
                  GUIDE RAIL
                  RIGHT
                  from £46.66
                  from £46.66
                  GUIDE RAIL Genuine Porsche Part - New (to order)
                  # 25
                  MPN: 99610517570
                  BEARING PIN
                  from £12.91
                  from £12.91
                  BEARING PIN Genuine Porsche Part - New (to order)
                  # 26
                  MPN: 90012315230
                  SEAL RING
                  16 x 22
                  from £1.32
                  from £1.32
                  SEAL RING - A 16 X 22 Genuine Porsche Part - New In stock
                  # 27
                  MPN: 99710555190
                  TIMING CHAIN
                  from £88.68
                  from £88.68
                  TIMING CHAIN Genuine Porsche Part - New (to order)
                  # 28
                  MPN: 99610503775
                  GUIDE RAIL
                  LEFT
                  from £79.21
                  from £79.21
                  GUIDE RAIL Genuine Porsche Part - New (to order)
                  # 29
                  MPN: 99610503875
                  GUIDE RAIL
                  RIGHT
                  from £79.21
                  from £79.21
                  GUIDE RAIL Genuine Porsche Part - New (to order)
                  # 30
                  MPN: 90038507201
                  TORX SCREW
                  AM 6 X 25
                  Supersession
                  Supersession
                  Genuine Porsche Part (no longer available to order)
                  # 31
                  MPN: 99710521990
                  SLEEVE
                  camshaft | Cyl. 1 - 3
                  from £41.07
                  from £41.07
                  SLEEVE Genuine Porsche Part - New (to order)
                  # 32
                  MPN: 99710522090
                  SLEEVE
                  camshaft | Cyl. 4 - 6
                  from £41.07
                  from £41.07
                  SLEEVE Genuine Porsche Part - New (to order)
                  # 33
                  MPN: 00004302400
                  EXTREME-PRESSURE GREASE
                  1 tube | 80 GR. | for | camshaft
                  Supersession
                  Supersession
                  Genuine Porsche Part (no longer available to order)
                  # 34
                  MPN: 99907347201
                  SCREW, ROUND HD.
                  M 6 x 55 | for | carrier
                  from £3.38
                  from £3.38
                  SCREW, ROUND HD Genuine Porsche Part - New (to order)
