porsche 2007 (997-1 gt3) air injection parts diagram

108-006 - AIR INJECTION

Porsche 2007 (997-1 GT3) AIR INJECTION Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Key
                        Price
                        # 1
                        MPN: 99760510402
                        Secondary Air Pump
                        from £810.33
                        from £810.33
                        Secondary Air Pump Genuine Porsche Part - New (to order)
                        # 2
                        MPN: 99711324090
                        BRACKET
                        from £162.30
                        from £162.30
                        BRACKET Genuine Porsche Part - New (to order)
                        # 3
                        MPN: 99711324990
                        CUT-OFF VALVE
                        Supersession
                        Supersession
                        Genuine Porsche Part (no longer available to order)
                        # 4
                        MPN: 99311325851
                        GASKET
                        from £7.07
                        from £7.07
                        GASKET Genuine Porsche Part - New (to order)
                        # 5
                        MPN: 90010201103
                        RING
                        from £9.98
                        from £9.98
                        RING Genuine Porsche Part - New (to order)
                        # 6
                        MPN: 99926102501
                        UNION BOLT
                        from £12.86
                        from £12.86
                        UNION BOLT Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 99711311790
                        connecting line
                        from £180.12
                        from £180.12
                        connecting line Genuine Porsche Part - New (to order)
                        # 8
                        MPN: 99970747240
                        O-RING
                        20 x 2,5
                        from £3.42
                        from £3.42
                        O-RING Genuine Porsche Part - New (to order)
                        # 9
                        MPN: 99951265809
                        HOSE CLAMP
                        27 x 12
                        from £2.29
                        from £2.29
                        HOSE CLAMP Genuine Porsche Part - New (to order)
                        # 10
                        MPN: 90006720701
                        BOLT WITH WASHER
                        M 6 X 20
                        from £1.10
                        from £1.10
                        BOLT WITH WASHER Genuine Porsche Part - New (to order)
                        # 11
                        MPN: 90006733101
                        SCREW
                        M 6 x 75
                        from £11.86
                        from £11.86
                        SCREW Genuine Porsche Part - New (to order)
                        # 12
                        MPN: 99711310191
                        BRACKET
                        from £285.10
                        from £285.10
                        BRACKET Genuine Porsche Part - New (to order)
                        # 13
                        MPN: 99711310791
                        AIR HOSE
                        from £91.73
                        from £91.73
                        AIR HOSE Genuine Porsche Part - New (to order)
                        # 14
                        MPN: 7L5951541
                        SCREW
                        M 6 X 50 | Discontinued part
                        SCREW Genuine Porsche Part - New (to order)
                        # 14
                        MPN: 95511332500
                        FILLISTER HD. SCREW
                        M 6 X 50
                        from £2.26
                        from £2.26
                        fillister hd. screw - M 6 X 50 Genuine Porsche Part - New (to order)
                        # 15
                        MPN: 99970386840
                        RUBBER ISOLATOR
                        from £7.97
                        from £7.97
                        RUBBER ISOLATOR Genuine Porsche Part - New (to order)
                        # 16
                        MPN: 99920907701
                        SPACER SLEEVE
                        from £5.33
                        from £5.33
                        SPACER SLEEVE Genuine Porsche Part - New (to order)
                        # 17
                        MPN: 90038501901
                        TORX SCREW
                        M 6 X 20
                        Supersession
                        Supersession
                        Genuine Porsche Part (no longer available to order)
                        # 19
                        MPN: 99951234601
                        HOSE CLAMP
                        16 - 27
                        from £2.29
                        from £2.29
                        HOSE CLAMP Genuine Porsche Part - New (to order)
